Question 1 Single choice

One of the benefits of the Ethernet Routing switch (ERS) 8300 switch is its ability to provide power-over-Ethernet (PoE). When implementing PoE on the ERS 8300 there are certain power supply requirements to consider. The 8301AC produces 1140W and 1770W and the 8302AC produces 850W and 1400W depending on the input voltage for both cases.

If there are eight 8648TX-PWR modules in a chassis, each needing 200W for Powered Devices (PI)) which power supply configuration is recommended?

  1. A

    One 8301AC power supply with 240VAC input voltage

  2. B

    Two 8302AC power supplies with 120VAC input voltage

  3. C

    Three 83CAC power supplies with 240VAC input voltage

  4. D

    Two 8301AC and one 8302Ac for redundancy with 240VAC input voltage

Show answer and explanation

Correct answer: C

Question 2 Single choice

A technician is setting up switch clustering using Split Multi-Link Trunking (SMLT).

Which link is configured between the SMLT cluster switches?

  1. A

    Inter-Switch Trunk (IST)

  2. B

    Multi link Trunk (MLT)

  3. C

    Split Multi Link Trunk (SMLT)

  4. D

    LAG Trunk

Show answer and explanation

Correct answer: A

Question 3 Single choice

Routed Split Multi-Link Trunking (RSMLT) is a way to ensure that traffic can be routed off the VLAN adding router redundancy.
On which Ethernet Routing Switch (ERS) configuration component is RSMLT configured?

  1. A

    an OSPF protocol

  2. B

    a core switch port

  3. C

    a VLAN

  4. D

    an MLT

Show answer and explanation

Correct answer: C

Question 4 Single choice

Consider the following port conditions on an Ethernet Routing Switch (ERS) 8648GTRS 10/100/1000 Ethernet I/O module: Left LED green Right LED flashing

What is the status of the port?

  1. A

    The link speed is 100 Mbp, and the port is disabled.

  2. B

    The link speed is 1000 Mbps, and the port is disabled.

  3. C

    The link speed is 100 Mbps, and the port is passing traffic.

  4. D

    The link speed is 1000 Mbps, and the port is passing traffic.

Show answer and explanation

Correct answer: D

Question 5 Multiple choice

A technician is configuring an Ethernet Routing Switch (ERS) 5520-24T for the edge of the Converged Campus network. in band communication to edge switch is a customer design requirement.

Which two VLANS are acceptable VLANs to use for the switch/stack IP addresses? (Choose two)

  1. A

    default

  2. B

    voice

  3. C

    data

  4. D

    management

Show answer and explanation

Correct answers: C, D

Question 6 Multiple choice

You are configuring a QoS Policy on an ERS RS or 8800 module to police the ingress data rate on a port with the following ACLI command on the interface level: qos if-policer police-rate 10000.

What other two ACLI commands are required on the edge interface? (Choose two.)

  1. A

    (config)#interface qos enable.

  2. B

    (config-if)#enable-diffserv enable.

  3. C

    (config-if)#access-diffserv enable.

  4. D

    (config-if)#no core-diffserv enable.

Show answer and explanation

Correct answers: B, C

Question 7 Single choice

A technician is configuring 802.1Q tagging, Virtual Link Aggregation Control Protocol (VLACP) with short timeout, and untagged frames to be discarded.

Which part of the network is being configured?

  1. A

    IST

  2. B

    The out-of-band management port

  3. C

    The edge access ports

  4. D

    The uplinks

Show answer and explanation

Correct answer: D

Question 8 Multiple choice

A switch with Simple Loop Prevention Protocol (SLPP) did not detect a loop.

What are two reasons this occurred? (Choose two)

  1. A

    SLPP was not globally enabled

  2. B

    A premier License for SLPP is needed.

  3. C

    the VLAN where the loop originated to the SLPP transmitting list was not added.

  4. D

    Extended CP limit on the transmitting port was not configured.

Show answer and explanation

Correct answers: A, C

Question 9 Multiple choice

Simple Loop Prevention Protocol (SLPP) detects VLAN based network loops.

Which two statements about SLPP functionality are correct? (Choose two.)

  1. A

    Spanning tree packets on a per VI AN basis allow SLPP to detect VI AN based network loops.

  2. B

    SLPP packets on a peer VLAN basis allow SLPP to detect VLAN based network loops.

  3. C

    The port is shut clown when a loop is detected.

  4. D

    The port on the edge switch of the link is disabled when a loop is detected.

Show answer and explanation

Correct answers: B, C

Question 10 Multiple choice

IPFIX protocol used for the export of flow information from traffic observed on a switch.

Which three statements are true for the functioning of the IPIX protocol? (Choose three)

  1. A

    The IPIX exporter handles sending packets to the collectors.

  2. B

    ACls can be used to configure IPFIX on a per port/slot basis.

  3. C

    The IPMX information cannot be exported to a 3rd-party application.

  4. D

    IPFIX requires dual CPUs installed for the ERS 8000.

Show answer and explanation

Correct answers: A, B
