Huawei H12-211 Online Practice Questions and Exam Preparation

Huawei H12-211 Online Questions & Answers

• Question 661:

  As shown in the figure, the correct description about this network topology is ().



  A. There are 6 collision domains in this network.
  B. There are 2 broadcast domains in this network.
  C. There is 1 conflict domain in this network
  D. There are 6 broadcast domains in this network
  B. There are 2 broadcast domains in this network.

• Question 662:

  As shown in the figure, RTA is a DTE device connected to a frame relay switch. If RTA uses dynamic mapping to establish a PVC connection, which of the following These commands do not need to be configured on the RTA? (multiple choice)



  A. [RTA-Serial1/0/1] ip address 172.16.1.124
  B. [RTA-Serial1/0/1]link-protocol fr
  C. [RTA-Serial1/0/1]fr interface-type dte
  D. [RTA-Serial1/0/1]fr inarp
  C. [RTA-Serial1/0/1]fr interface-type dte
  D. [RTA-Serial1/0/1]fr inarp

• Question 663:

  Which of the following network types does OSPF support? (Multiple Choice)

  A. Point-to-Point.
  B. Broadcast.
  C. Non-Broadcast Multi-Access.
  D. Point-to-Multipoint.
  A. Point-to-Point.
  B. Broadcast.
  C. Non-Broadcast Multi-Access.
  D. Point-to-Multipoint.

• Question 664:

  Which of the following statements are true about ICMP messages? (Multiple Choice) A. ICMP messages can record time, including the original time, packet receiving time, and packet sending time.

  B. ICMP messages are encapsulated in IP packets but not at the transport layer.
  C. ICMP messages include error messages, control messages, request/response messages, and update messages.
  D. ICMP does not support redirection.
  E. ICMP messages cannot be used to detect a path's MTU.
  B. ICMP messages are encapsulated in IP packets but not at the transport layer.
  C. ICMP messages include error messages, control messages, request/response messages, and update messages.

• Question 665:

  When a network administrator configures STP in the network, BPDU begin to be sent by switch. Which of the following statements regarding the BPDU frame are correct?

  A. A BPDU uses the IEEE 802.3 standard frame type
  B. A BPDU uses the Ethernet II standard frame type
  C. The BPDU frame's control field is 3
  D. The destination MAC address field of a BPDU frame is a broadcast address
  A. A BPDU uses the IEEE 802.3 standard frame type

• Question 666:

  The network administrator wishes to transmit data between two end stations. The network interface cards of both devices operates at 100Mbps however one supports half duplex while the other uses full duplex mode. What will occur as a result?

  A. The end stations cannot communicate.
  B. The end stations can communicate, but data may be lost during transmission of large amounts of traffic.
  C. The end stations will operate normally
  D. The end stations can communicate, but speed is different during transmission of large amounts of traffic.
  B. The end stations can communicate, but data may be lost during transmission of large amounts of traffic.

• Question 667:

  When the specified interface is running in RIPv2 multicast mode, the following statement is correct (). (multiple choice)

  A. Receive only RIPv2 multicast packets.
  B. Do not receive RIPv1 broadcast packets.
  C. Receive RIPv1 broadcast messages
  D. Receive RIPv1 multicast packets
  A. Receive only RIPv2 multicast packets.
  B. Do not receive RIPv1 broadcast packets.

• Question 668:

  Refer to the graphic. The link between RTA and RTB is encapsulated using PPP. The IP addresses of serial 1/0/1 of RTA and serial 1/0/1 of RTB are in different network segments. Which following is correct? (Choose two)

  A. RTA can ping 10.1.1.2 successfully
  B. RTA cannot ping 10.1.1.2
  C. The route entry 10.1.1.0/24 exists in the routing-table of RTA
  D. The route entry 10.1.1.2/32 exists in the routing-table of RTA
  A. RTA can ping 10.1.1.2 successfully
  D. The route entry 10.1.1.2/32 exists in the routing-table of RTA

• Question 669:

  Which of the following information must be configured for a DHCPv6 relay agent?

  A. DHCPv6 address pool
  B. DNS server address
  C. IPv6 address of the DHCPv6 server
  D. DHCPv6 DUID
  C. IPv6 address of the DHCPv6 server

• Question 670:

  Two end stations in a point-to-point network perform address resolution. Which of the following statements is correct?

  A. The destination address of an ARP request from each station will be a unicast MAC address.
  B. The destination address of an ARP request from each station will be a broadcast IP address.
  C. The destination address of an ARP reply from each station will be a unicast MAC address
  D. The destination address of an ARP reply from each station will be a broadcast MAC address.
  C. The destination address of an ARP reply from each station will be a unicast MAC address
