Huawei H12-211 Online Practice Questions and Exam Preparation

Huawei H12-211 Online Questions & Answers

• Question 711:

  The Access port strips out the VLAN ID when it receives the same data frame with the same VLAN ID and PVID. Then forward directly.

  A. Correct
  B. Error
  B. Error

• Question 712:

  As shown in the figure, the RTA sends a PADI message to the server A as a PPPOE client. Which of the following transmission methods will the PADI message use?



  A. Unicast
  B. Multicast
  C. Broadcast
  D. Anycast
  C. Broadcast

• Question 713:

  Which of the following can be displayed on the Versatile Routing Platform (VRP) to indicate that GE port 2 on subcard 0 in slot 3 of a router?

  A. interface GigabitEthernet 3/2/0
  B. interface GigabitEthernet 3/0/2
  C. interface Ethernet 3/0/2
  D. interface XGigabitEthernet 3/0/2
  B. interface GigabitEthernet 3/0/2

• Question 714:

  A host in a private network needs to access the Internet. To achieve this requirement, the administrator should do the following on the edge router of the network. What configuration? (multiple choice)

  A. NAT Easy IP
  B. DHCP
  C. STP
  D. Default route
  A. NAT Easy IP
  D. Default route

• Question 715:

  The administrator cannot use telnet to manage the AR2200. The administrator is able to verify connectivity to the router and has been informed that other administrators have no difficulties using telnet. Which statements describe the possible reasons for this problem? (Choose two)



  A. The user's status has been blocked
  B. The user's priviledge level has been changed to 0.
  C. The user has been deleted.
  D. The telnet service in the AR2200 router has been disabled.
  A. The user's status has been blocked
  C. The user has been deleted.

• Question 716:

  10.0.1.0/24 O_ASE 150 2 D 10.0.23.3 Serial2/0/0

  Refer to the display output. Which of the following statements regarding route shown are true? (Choose two)

  A. The address 10.0.23.3 has been configured on the peer's serial 2/0/0 interface.
  B. The route preference has been changed by the adminstrator.
  C. The metric for the route 10.0.1.0 indicates that two hops are needed.
  D. The route has been learned via the OSPF protocol.
  A. The address 10.0.23.3 has been configured on the peer's serial 2/0/0 interface.
  D. The route has been learned via the OSPF protocol.

• Question 717:

  Ping 10.0.0.2: 56 data bytes, press CTRL_C to break Reply from 10.0.0.2: bytes=800 Sequence=1 ttl=255 time=2 ms Reply from 10.0.0.2: bytes=800 Sequence=2 ttl=255 time=10 ms --- 10.0.0.2 ping statistics --- 2 packet(s) transmitted 2 packet(s) received 0.00% packet loss round-trip min/avg/max = 2/6/10 ms A network administrator uses the ping command to test connectivity to the destination 10.0.0.2 on a Huawei AR series router. Which statement regarding the output is correct?

  A. The network administrator used the command ping -c 2 -s 800 10.0.0.2
  B. The network administrator used the command ping -a 2 -v 800 10.0.0.2
  C. The path between the source and destination is not OK.
  D. The network administrator changed the default TTL value.
  A. The network administrator used the command ping -c 2 -s 800 10.0.0.2
