Cisco 300-101 Online Practice Questions and Exam Preparation

Cisco 300-101 Online Questions & Answers

• Question 881:

  Which password takes precedence if you configure multiple passwords for Telnet connections to a Cisco IOS device?

  A. Console line password
  B. Enable secret password
  C. Enable password
  D. Aux line password
  B. Enable secret password

• Question 882:

  Engineer has to enable RIP on a link. Where he will issue the command?

  A. Ipv6
  B. Global
  C. Router sub command
  D. Interface sub command
  C. Router sub command

• Question 883:

  Which traffic does the following configuration allow? ipv6 access-list cisco permit ipv6 host 2001:DB8:0:4::32 any eq ssh line vty 0 4 ipv6 access-class cisco in

  A. all traffic to vty 0 4 from source 2001:DB8:0:4::32
  B. only ssh traffic to vty 0 4 from source all
  C. only ssh traffic to vty 0 4 from source 2001:DB8:0:4::32
  D. all traffic to vty 0 4 from source all
  C. only ssh traffic to vty 0 4 from source 2001:DB8:0:4::32

• Question 884:

  Refer to the exhibit. A new TAC engineer came to you for advice. A GRE over IPsec tunnel was configured, but the tunnel is not coming up. What did the TAC engineer configure incorrectly?



  A. The crypto map is not configured correctly
  B. The crypto ACL is not configured correctly.
  C. The crypto map is not applied to the correct interface.
  D. The OSPF network is not configured correctly.
  B. The crypto ACL is not configured correctly.

• Question 885:

  Which task must you perform to enable a device to redistribute IBGP routes into OSPF?

  A. Configure the redistribute bgp command globally.
  B. Configure the bgp redistribute-internal command under the OSPF routing process only.
  C. Configure the bgp redistribute-internal command under both the BGP routing process and the OSPF routing process.
  D. Configure the bgp redistribute-internal command under the BGP routing process only.
  D. Configure the bgp redistribute-internal command under the BGP routing process only.

• Question 886:

  A router receives a routing advertisement for the same prefix and subnet from four different routing protocols. Which advertisement is installed in the routing table?

  A. RIP
  B. OSPF
  C. iBGP
  D. EIGRP
  D. EIGRP

• Question 887:

  Which two protocols can cause TCP starvation?(choose two)

  A. TFTP
  B. SNMP
  C. SMTP
  D. HTTPS
  E. FTP
  A. TFTP
  B. SNMP

• Question 888:



  Based on the configuration information shown above, which of the following are true? (Choose two)

  A. will redistribute only clasfull routes
  B. routes will be redistributed as E2
  C. routes will be redistributed as N2
  D. will redistribute all eigrp routes
  A. will redistribute only clasfull routes
  B. routes will be redistributed as E2

• Question 889:

  Which type of message does a device configured with the eigrp stub command send in response to EIGRP queries?

  A. invalid request
  B. unavailable
  C. stuck in active
  D. stub-only
  E. reject
  F. inaccessible
  F. inaccessible

• Question 890:

  You have been asked to evaluate an OSPF network setup in a test lab and to answer questions a customer has about its operation. The customer has disabled your access to the show running- config command.

  A. The R1-R3 link needs the neighbor command for the adjacency to stay up
  B. The R2-R3 link OSPF timer values are 30, 120, 120
  C. The R1-R3 link OSPF timer values should be 10,40,40
  D. R3 is responsible for flooding LSUs to all the routers on the network.
  B. The R2-R3 link OSPF timer values are 30, 120, 120
