• Question 71:

  While installing an R7000 UPS, an engineer is asked to mount a ground bonding wire to the R7000. Referring to the exhibit, what is the intended ground wire connection point?



  A. item 7
  B. item 9
  C. item 10
  D. item 11
  E. item 12
  F. item 16
  B. item 9

  ---

  Rear View:

  1.

  Load segment 1 circuit breaker (controls L6-30R receptacle Item 3)

  2.

  Load segment 2 circuit breaker (controls L6-30R receptacle Item 15)

  3.

  Large output NEMA L6-30R receptacle or IEC-60309 32A receptacle on short cords associated with load segment 1

  4.

  Cord retention clip attachment locations

  5.

  Load segment 1 circuit breaker (controls the C19 receptacles, but does not control the large output receptacle)

  6.

  3 x IEC C19 receptacles on load segment 1

  7.

  HP UPS Network Module

  8.

  Input power line cord with NEMA CS8265C plug or IEC- 309-32A plug

  9.

  Ground bonding screw

  10.

  Serial communications port

  11.

  USB communications port

  12.

  REPO port

  13.

  3 x IEC C19 receptacles on load segment 2



• Question 72:

  Which key must you press to access the Intelligence Provisioning Maintenance Menu?

  A. F9
  B. F10
  C. F11
  D. F12
  B. F10

  ---

  Boot options

  Near the end of the boot process, the boot options screen is displayed. This screen is visible for several seconds before the system attempts to boot from a supported boot device. During this time, user can do the following:

  Access RBSU by pressing the F9 key.

  Access Intelligent Provisioning Maintenance Menu by pressing the F10 key.

  Access the boot menu by pressing the F11 key.

  Force a PXE Network boot by pressing the F12 key.

• Question 73:

  Once the HPSReport generation program completes, what is the next step in the support process?

  A. Use a third-party compression tool to create a file to email to HP support.
  B. Send the created file to HP support with the original problem statement in the subject field.
  C. Send the created file to HP support with the appropriate case number in the subject field.
  D. Send an email to HP support to advise them that the file has been created.
  B. Send the created file to HP support with the original problem statement in the subject field.

• Question 74:

  Your customer's HP Integrity rx2800 i2 server fails to complete self-test. What can you check to find the root cause of the problem? (Select two.)

  A. Active Health Logs
  B. System Insight Display LEDs
  C. Forward Progress Logs
  D. Early Video Progress Indicators
  E. UEFI Shell info all output
  A. Active Health Logs
  B. System Insight Display LEDs

• Question 75:

  Which RAID level allows the data to be striped across multiple RAIDs? (Select two.)

  A. RAID 0
  B. RAID 1
  C. RAID 5
  D. RAID 50
  E. RAID 60
  D. RAID 50
  E. RAID 60

  ---

  D: RAID level 50 is a combination of RAID level 5 and RAID level 0. RAID 50 includes both parity and disk striping across multiple drives. RAID 50 is best implemented across two RAID 5 arrays with data striped across both disk arrays. RAID

  50 breaks the data into smaller blocks, and then stripes the blocks to each RAID 5 raid set. RAID 5 breaks up data into smaller blocks, calculates parity by performing and Exclusive OR on the blocks, and then writes the blocks of data and

  parity to each drive in the array. The size of each block is determined by the stripe size parameter, which is set when the RAID is created.

  E: A RAID 60 combines the straight block-level striping of RAID 0 with the distributed double parity of RAID

  6. That is, a RAID 0 array striped across RAID 6 elements. It requires at least eight disks.

  Incorrect:

  Not A: It is striped, but not across multiple RAIDs.

  Not B: Mirror not a stripe.

  Not C: Just a single raid.

• Question 76:

  When installing a rack in a data center, which way should the racks face?

  A. Install front to back facing a hot aisle.
  B. Install back to front facing a hot aisle.
  C. Install front to front facing a cold aisle.
  D. Install front to back facing a cold aisle.
  D. Install front to back facing a cold aisle.

  ---

  Thermal considerations If multiple rows of rack mounted equipment are installed, the facility may take advantage of the front-to- back airflow by arranging racks front-to-front and back-to-back. Conditioned air registers may then be oriented along the "front" aisles and the return air registers in the "back" aisles. Such an arrangement will utilize the aisle space as air plenums and will increase the efficiency of the air conditioning.
