HP HP2-T25 Online Practice Questions and Exam Preparation

HP HP2-T25 Online Questions & Answers

• Question 11:

  You need to replace one of the processors in a dual processor ProLiant Server. Which processor should become the primary processor?

  A. the server will choose it automatically on next power-on.
  B. the new processor
  C. the processor with the highest stepping D. the processor with the lowest stepping
  A. the server will choose it automatically on next power-on.

  ---

  Note:

  *

  Processor on the primary processor memory board

  The processors and memory are located in the drawer accessible from the front of the server. It is not necessary to extend or remove the server from the rack to install or replace processors and memory.

  *

  Processor on the secondary processor memory board

  The processors and memory are located in the drawer accessible from the front of the server. It is not necessary to extend or remove the server from the rack to install or replace processors and memory

• Question 12:

  An engineer will be installing an HP R7000 UPS and an Extended Runtime Module (ERM) in an existing HP 10642 G2 rack. This rack contains 10 DL380e Gen8 servers mounted 1U upward.

  How should the engineer perform this installation?

  A. Remove the two lowest mounted DL380e Gen8 servers and mount the R7000 at the bottom of the 10642G2 rack. Mount the two removed DL3-80e Gen8 servers at the top of the 10642 G2 rack.
  B. Remove the lowest DL380e Gen8 servers and mount the R7000 and the ERM at the lowest position in the rack. Mount the removed DL380e Gen8 servers at a higher position in the 10642 G2 rack.
  C. Mount the R7000 UPS at 10U in the 10642 G2 rack with the ERM on top of the R7000 UPS.
  D. Mount theR7000atthe highest position possible in the 10642 G2 rack with the ERM just below the UPS.
  E. Mount the ERM at the highest position possible in the 10642 G2 rack with the R7000 UPS just below the ERM.
  C. Mount the R7000 UPS at 10U in the 10642 G2 rack with the ERM on top of the R7000 UPS.

• Question 13:

  A processor failed and was replaced in an HP Integrity rx2800 i2 server. Which UEFI command should be used to verify that the new processor is active and, if needed, may be used to activate it?

  A. cpuconfig
  B. info cpu
  C. activate cpu
  D. dump fru
  A. cpuconfig

  ---

  After replacing the processor and heat sink module use the cpuconfig from UEFI to verify the that the processor socket has been reconfigured.

• Question 14:

  Which hardware-based system security feature can securely store information, such as passwords and encryption keys, and can be used to authenticate the platform?

  A. TPM
  B. DHCP
  C. RBSU
  D. ORCA
  A. TPM

  ---

  The TPM (Trusted Platform Module) is a hardware-based system security feature that can securely store information, such as passwords and encryption keys, which can be used to authenticate the platform.

• Question 15:

  HP Support asked you to load diagnostics from a SmartStart CD to evaluate a DL360 G6 server. The customer removed the DVD drive and installed the optional disk backplane to add more disk drive. With no DVD drive available, how can you load the diagnostics?

  A. Remove the additional disks and replace the DVD drive until service is completed.
  B. Nothing can be done without a CD/DVD drive installed on the server.
  C. Make a bootable USB key drive with the SmartStart ISO image on it.
  D. Make multiple floppy disks from a the SmartStart image for floppies,
  C. Make a bootable USB key drive with the SmartStart ISO image on it.

  ---

  The HP USB Key Utility is a Microsoft Windows application that permits the contents of the HP SmartStart CD or Firmware Maintenance CD to be copied to a USB Drive Key, allowing these applications to run directly from the USB Drive Key instead of the CD-ROM media.

• Question 16:

  A support engineer needs to replace drives on a ProLiant Gen8 server and must securely erase customer data. How can this be achieved?

  A. Run the HP System Erase Utility to reset all settings.
  B. Run the HP System Erase Utility to reset RBSU.
  C. Run a third-party disk shredding tool.
  D. Run the HP System Erase Utility to reset all disks.
  D. Run the HP System Erase Utility to reset all disks.

  ---

  Compaq System Erase Utility This SoftPaq creates one System Erase Utility diskette. This utility will enable the user to erase CMOS Factory Time/Date, CMOS checksum, EISA NVRAM (including environment variables), partitions on all hard drives, and the Compaq SMART and SMART-2 Array controller configuration.

• Question 17:

  What is used on a Windows server for InfiniBand firmware management?

  A. VCA
  B. SMH
  C. HP SUM
  D. MFT
  D. MFT

  ---

  The Mellanox Firmware Tools (MFT) package is a set of firmware management tools for a single InfiniBand node. MFT can be used for:

  Generating a standard or customized Mellanox firmware image Querying for firmware information Burning a firmware image to a single InfiniBand node

• Question 18:

  What is the first step when creating a NIC team using NCU?

  A. Select team members.
  B. Configure the team IP address.
  C. Set IP of each NIC to be used in the team.
  D. Choose team type.
  A. Select team members.

  ---

  1.

  The HP Network Configuration Utility Properties window will look like the one provided below.

  2.

  Select 2 NICs by clicking on it and then click Team button.



  Note:

  *

  NIC Teaming (Network Teaming) means you are grouping two or more physical NICs and it will act as a single NIC. You may call it as a Virtual NIC. Minimum number of NICs which can be grouped (Teamed) is Two and the maximum number of NICs which you can group is Eight.

  *

  To create NIC Teaming in Windows 2008/2003 Operating System, we need to use the HP Network Configuration Utility (NCU).

• Question 19:

  A customer has a DL380p Gen8 base unit with 1 CPU, 4 x 16 GB RDIMM with 24 total DIMM slots. Which memory option is valid?

  A. Remove the existing memory and populate all memory slots with UDIMMS memory.
  B. Populate the remaining 20 memory slots with additional RDIMM memory.
  C. Populate another 8 memory slots with additional RDIMM memory.
  D. Populate the remaining 20 memory slots with additional UDIMM memory.
  C. Populate another 8 memory slots with additional RDIMM memory.

  ---

  / Rules for populating processors and DIMM slots

  *

  Install DIMMs only if the corresponding processor is installed.

  *

  If only one processor is installed in a two-processor system, only half of the DIMM slots are available.

  / DL380p can use one or two processors.

  Note:

  *

  ProLiant Gen8 servers support four different DIMM types Unbuffered with ECC Memory (UDIMMs), Registered Memory (RDIMMs), Load Reduced Memory (LRDIMMs), and HyperCloudMemory (HDIMMs).

  *

  ProLiant Gen8 servers, we recommend populating all memory channels whenever possible. This ensures the best memory performance.

• Question 20:

  Which statement is correct?

  A. The mandatory CSR guideline applies to customers who upgrade their warranty support to carepack or contract maintenance.
  B. The mandatory CSR guideline does not apply to customers who upgrade their warranty support to carepack or contract maintenance.
  C. Mandatory and optional CSR guidelines only apply to a product with a warranty service level agreement.
  D. The optional CSR guideline does not apply to customers who upgrade their warranty support to carepack or contract maintenance.
  B. The mandatory CSR guideline does not apply to customers who upgrade their warranty support to carepack or contract maintenance.

  ---

  Currently, HP identifies two types of Customer Self Repair parts - 'Mandatory' and 'Optional'. 'Mandatory' requires standard warranty customers to perform part replacement or pay for HP service. Self repair is optional for customers with an HP Care Pack or support agreement. 'Optional' allows the customer to perform part replacement or have HP service personnel perform it at no additional charge during the product warranty period.
