HP HP2-T25 Online Practice Questions and Exam Preparation

HP HP2-T25 Online Questions & Answers

• Question 61:

  Which statements are correct about SIM 7.0 Agentless Management? (Select two.)

  A. HP SIM communicates with the CPU and collects essential data for the OS.
  B. Agentless Management Service runs on the host to provide software information directly to the iLO Management Engine.
  C. HP SIM communicates with the iLO Management Engine to collect hardware data.
  D. Agentless Management is provided by the CPU.
  B. Agentless Management Service runs on the host to provide software information directly to the iLO Management Engine.
  C. HP SIM communicates with the iLO Management Engine to collect hardware data.

  ---

  Overview of HP Agentless Management ProLiant Gen8 servers include the iLO Management Engine, which provides HP Agentless Management. HP Agentless Management runs independently from the OS and collects data on core server components. You can view the data that the iLO Management Engine collects through either the web-based iLO 4 Graphical User Interface (GUI), the iLO XML scripting interface or through a remote management application, like HP SIM 7.0.

  To provide the complete HP Agentless Management solution, you can add the optional HP Agentless Management Service. The HP Agentless Management Service runs on the OS and gathers information that the iLO Management Engine does not obtain when an OS is running. The HP Agentless Management Service is a lightweight service that only communicates with the iLO Management Engine. It does not require an SNMP stack to be running on the host OS and it does not have an external interface. The HP Agentless Management Service provides the information it gathers to the iLO Management Engine. You can view the data that the HP Agentless Management Service and the iLO Management Engine collect through the iLO 4 GUI or HP SIM 7.0,

• Question 62:

  After starting HP Insight Diagnostics, you want see how the selected tests are progressing. Which tab should you select?

  A. Survey
  B. Status
  C. Test
  D. Diagnose
  E. Help
  F. Log
  B. Status

  ---

  Status Tab

  The Status tab displays the status of the selected tests. The type of test executed (Quick , Complete , or Custom ) is also displayed. The main progress bar displays the percent complete of the current set of tests. While testing is in progress,

  a Cancel Testing button is displayed for use if you want to cancel the test.

  After testing has completed, the Cancel Testing button is replaced with a Retest button. The Retest button will retest the last set of tests executed. This enables you to re-run the set of tests without having to re- enter the data in the Test tab.

  The Status tab also shows:

  *

  The devices being tested

  *

  The test status (running, passed, or failed) of each device being tested

  *

  The overall test progress of all devices being tested

  *

  The test progress for each device being tested

  *

  The elapsed test times for each device being tested

• Question 63:

  Match the correct UPS description with each picture.

  Hot Area:





• Question 64:

  After the system board of an HP Integrity rx2800 i2 is replaced, which tool is used to set the mode of the SAS controller?

  A. IOCONFIG
  B. SAUTIL
  C. ORCA
  D. SAUPDATE
  D. SAUPDATE

  ---

  Using the saupdate command

  The saupdate command is used to query or change the mode of the Smart Array P410i and Smart Array P411 controllers to HBA or RAID.

• Question 65:

  An engineer installed an iPDU solution in a rack. While verifying the installation, the engineer discovers that the iPDU firmware is not up to date. Which method should the engineer use to update the iPDU firmware?

  A. Use the HP Power Device Flash utility.
  B. Connect a PC to the serial port of the iPDU display module and run the iPDU software update utility.
  C. Use the onboard iPDU FTP utility.
  D. Use the iPDU embedded web interface through the Setup tab.
  B. Connect a PC to the serial port of the iPDU display module and run the iPDU software update utility.

  ---



  8. DB-9 for firmware updates

• Question 66:

  What is the best way to exercise replaced DAS components in a server?

  A. Run HP Insight Diagnostics online, selecting Diagnose.
  B. Run ADU.
  C. Run the hard disk test in BIOS.
  D. Run HP Insight Diagnostics offline, selecting Custom Test.
  D. Run HP Insight Diagnostics offline, selecting Custom Test.

  ---

  * (not A) Using the Test tab (HP Insight Diagnostics Offline Edition only) *



  Note: direct attached storage (DAS) References:

• Question 67:

  What should be installed on a ProLiant Gen8 Server to display operating system information within the iLO GUI?

  A. Agentless Management Service
  B. HP Management Agents
  C. System Management Home Page
  D. ProLiant Support Pack
  A. Agentless Management Service

  ---

  *

  Agentless Management Service runs on the host to provide software information directly to the iLO Management Engine.

  *

  Overview of HP Agentless Management ProLiant Gen8 servers include the iLO Management Engine, which provides HP Agentless Management. HP Agentless Management runs independently from the OS and collects data on core server components. You can view the data that the iLO Management Engine collects through either the web-based iLO 4 Graphical User Interface (GUI), the iLO XML scripting interface or through a remote management application, like HP SIM 7.0.

• Question 68:

  An HP ProLiant DL 380 G7 server has a failure indicating that memory slot DIMM 1 has errors. To troubleshoot the problem, you exchange the memory modules in slots 1 and 2 with each other. LED next to slot 1 is lit. What should you do?

  A. Run the ECC memory test in the diagnostics to correct the errors.
  B. Replace the system board and rerun the memory diagnostics.
  C. Replace the memory module in slot 1 because it is definitely bad.
  D. Replace both memory modules in slots 1 and 2.
  A. Run the ECC memory test in the diagnostics to correct the errors.

• Question 69:

  What is achieved on ProLiant Gen8 Servers by including temperature sensors on stand-up components within the server (3D Sea of Sensors)?

  A. Cooling fans on stand-up components only run at 50% utilization.
  B. It provides more precise and more efficient cooling.
  C. It requires half the number of fans than in previous server models.
  D. Dedicated cooling fans are included on all stand-up components.
  B. It provides more precise and more efficient cooling.

  ---

  HP Sea of Sensors 3D Introduced with ProLiant G6 servers, HP Sea of Sensors provides the data to precisely control the server fans and directly cool specific components, while not overcooling other components. This can reduce fan power consumption up to dozens of watts per server. HP Sea of Sensors 3D in ProLiant Gen8 servers extends the use of sensors to select PCI Express option cards, FlexibleNetwork Adapters, and FlexFabric Adapters to get a three-dimensional temperature profile in the server. This additional data enables more precise and efficient cooling of ProLiant Gen8 servers. The data is included in the always-on diagnostic information of the HP Active Health System.

• Question 70:

  Which tool provides the most inclusive information about a server?

  A. insight Diagnostics online survey
  B. OS and application logs
  C. Insight Diagnostics offline survey
  D. HPS Report
  C. Insight Diagnostics offline survey

  ---

  Note:

  *

  HP Insight Diagnostics is a proactive server management tool, available in both Online and Offline editions. Insight Diagnostics provides diagnostics and troubleshooting capabilities to assist IT administrators who verify server installations, troubleshoot problems, and perform repair validation.

  *

  HP Insight Diagnostics contains the following primary tabs: Survey Diagnose Test (available in Offline Edition only) Status Log Help
