Microsoft 70-680 Online Practice Questions and Exam Preparation

Microsoft 70-680 Online Questions & Answers

• Question 221:

  Your company network contains 20 client computers that run Windows 7 Enterprise. The network does not have a DNS server and is using IPv6 only.

  Users are complaining they are unable to see others' computers on the network.

  You notice that the settings of the network are configured as shown in the exhibit. (Click the Exhibit button.)

  You need to ensure that users can see all computers on the network in Windows Explorer.

  What should you do on each computer?

  A. Turn on Public folder sharing.
  B. From a command prompt, run the net view command.
  C. Turn on Network discovery.
  D. Run Windows Network Diagnostics.
  E. From a command prompt, run the net config command
  C. Turn on Network discovery.

• Question 222:

  Your company network has a single-domain Active Directory forest. The forest functional level is set to Windows Server 2008 R2. All computers are members of the domain. You plan to deploy Windows BitLocker Drive Encryption (BitLocker)

  on portable computers that have Windows 7 Enterprise installed.

  You need to be able to automatically back up recovery passwords for BitLocker-protected disk volumes on the portable computers.

  What should you do before you start encrypting the disk volumes with BitLocker?

  A. Run the cscript Get-TPMOwnerlnfo.vbs script on the client computers.
  B. Select the Turn on BitLocker backup to Active Directory option in local policy on the portable computers.
  C. Run the cscript Get-BitLockerRecoverylnfo.vbs script on the portable computers.
  D. Run the Idifde -i -v -f BitLockerTPMSchemaExtension.ldf -c script on a domain controller.
  B. Select the Turn on BitLocker backup to Active Directory option in local policy on the portable computers.

• Question 223:

  You want to create a 20-GB native VHD called Systemvhd in a folder called Windows 7 on an external U hard disk with the drive designation G:.

  Which command do you use?

  A. create vdisk file=g:\windows7\systemvhd maximum=20000
  B. create vdisk file=g:\windows7\systemvhd.vhd maximum=20000
  C. create vdisk file=g:\windows7\systemvhd.vhd maximum=20
  D. create vdisk file=g:\windows7\systemvhd maximum=20
  B. create vdisk file=g:\windows7\systemvhd.vhd maximum=20000

• Question 224:

  You administer portable computers that have Windows 7 Professional installed. All computers have wireless network interface cards (Wi-Fi). You plug a new wireless wide area network (WWAN) device to your computer. The WWAN device

  that connects to a 3G network provides Internet access.

  Other portable computers equipped only with Wi-Fi cannot access Internet resources.

  You need to configure Internet access for the portable computers by using a wireless ad-hoc network configured on your computer.

  What should you do? (To answer, drag the appropriate target computer or computers to the correct configuration step or steps in the answer area. An answer choice can be used once, more than once, or not at all.)

  Select and Place:





• Question 225:

  You have a computer that runs Windows 7. The computer contains one hard disk. The hard disk is configured as shown in the following table.



  You install a new 250-GB hard disk in the computer.

  You need to ensure that all the files on the computer are available if a single disk fails.

  What should you do?

  A. Create a mount point on C and D and then create a striped volume.
  B. Create a mount point on C and D and then create two striped volumes.
  C. Convert both disks to dynamic disks and then create a mirrored volume.
  D. Convert both disks to dynamic disks and then create two mirrored volumes.
  D. Convert both disks to dynamic disks and then create two mirrored volumes.

  ---

  Creating a Mirrored Volume (RAID-1)

  A mirrored or RAID-1 volume provides availability and fault tolerance but does not improve performance. It uses two disks (or two portions on separate disks) that are the same size. Any changes made to the first disk of a mirror set are also

  made to its mirror disk. If the first disk fails, the mirror is broken and the second disk is used until the first is repaired or replaced. The mirror is then re-created, and the information on the working disk is mirrored on the repaired disk. The

  disadvantage of RAID-1 is that you need (for example) two 200-GB disks to hold 200 GB of data. The advantage is that you can mirror a system disk containing your operating system.

  You create a mirrored volume using a very similar procedure to the one that creates a striped volume, except that you right-click the first disk of your mirror and click New Mirrored Volume to start the appropriate wizard. You then select the

  second disk. The second disk needs to have a portion of unallocated space that is at least as large as the disk you want to mirror. The drive letter for a mirrored volume is the same as the drive letter of the first disk. You can also use the

  Diskpart tool to create a mirrored volume. At the DISKPART> prompt you first use the select disk command to select the first disk. You then enter a command with the syntax add disk=to specify the mirror disk.

• Question 226:

  Your company network includes client computers that have Windows 7 installed. All client computers have NetBIOS disabled.

  You need to view the status of all TCP/UDP ports.

  Which command should you run?

  A. nbtstat -n
  B. ipconfig /all
  C. netstat -an
  D. ipconfig /displaydns
  C. netstat -an

• Question 227:

  You work in an international company which is named Wiikigo. Before entering this company, you have two years of experience in the IT field, as well as experience implementing and administering any Windows client operating system in a

  networked environment. You are professional in installing, upgrading and migrating to Windows 7, deploying Windows 7, and configuring Hardware and Applications and son on. You have a computer that runs Windows 7.

  You run Runas and specify the /savecred parameter to start an application.

  The stored password needs to be deleted.

  What action should you perform?

  A. The Windows credentials should be modified from Credential Manager.
  B. The Authorization Manager options should be modified from Authorization Manager.
  C. Del should be run and the /p parameter should be specified.
  D. Runas should be run and the /noprofile parameter should be specified.
  A. The Windows credentials should be modified from Credential Manager.

• Question 228:

  A user is attempting to connect to a secure remote Microsoft SQL database on a computer running Windows 7 Professional. The computer communicates on port 1433.

  A rule in Windows Firewall with Advanced Security allows communication. The user cannot connect to the database on the currently defined protocol due to an error in protocol type.

  You need to ensure that users can connect to the database.

  Which setting should you choose? (To answer, select the appropriate setting in the work area.)

  Hot Area:





• Question 229:

  You are configuring static IPv4 addresses for two computers, Perth and Brisbane, on an isolated private wired subnet. You configure Perth with the IPv4 address 172.16.10. 140 and the subnet mask 255.255.255.0. You configure Brisbane with the IPv4 address 172.16.10. 210 and the subnet mask 255.255.255.0. You enter ping 172.16.10.140 on Brisbane, but the command times out. Similarly, entering ping 172.16.10.210 on Perth fails to locate the Brisbane computer's IPv4 address.

  What is the likely reason for this lack of connectivity?

  A. DNS service is not available on the subnet.
  B. The computers should have different subnet masks.
  C. You have not specified a default gateway.
  D. You need to permit ICMPv4 traffic through the firewalls of both computers.
  D. You need to permit ICMPv4 traffic through the firewalls of both computers.

• Question 230:

  You work for Contoso. Ltd. as part of a Windows 7 deployment team.

  You create a new Windows Preinstallation Environment image. The image file is located at N:\images\winpe_x86 and is named WinPE.wim. An unsigned driver is located at N:\Drivers\Driverl.inf.

  You need to include the driver in the WinPE.wim image.

  Which four actions should you perform in sequence? (To answer, move the appropriate four actions from the list of actions to the answer area and arrange them in the correct order.)

  Select and Place:





  ---

  Ref: http://technet.microsoft.com/en-us/library/cc749350(v=WS.10).aspx http://technet.microsoft.com/en-us/library/cc709665(v=WS.10).aspx
