Cisco CCNP 350-601 Questions & Answers

• Question 31:

  The Cisco Nexus switch Generic Online Diagnostics policy for a PortLoopback test requires 10 consecutive failures to error disable the port. The customer wants to change it to 5 consecutive failures.

  Which configuration applies the changes for module 1 only?

  A. Nexus(config)# event manager applet custom-PortLoopback override __PortLoopback Nexus(config-applet)# event gold mod all test PortLoopback testing-type bootup consecutive-failure 5 Nexus(config-applet)# action 1 publish-event

  B. Nexus(config)# event manager applet custom-PortLoopback override __PortLoopback Nexus(config-applet)# event gold mod 1 test PortLoopback testing-type bootup consecutive-failure 5 Nexus(config-applet)# action 1 publish-event

  C. Nexus(config)# event manager applet custom-PortLoopback override __PortLoopback Nexus(config-applet)# event gold mod all test PortLoopback testing-type monitoring consecutive-failure 5 Nexus(config-applet)# action 1 policy-default

  D. Nexus(config)# event manager applet custom-PortLoopback override __PortLoopback Nexus(config-applet)# event gold mod 1 test PortLoopback testing-type monitoring consecutive-failure 5 Nexus(config-applet)# action 1 policy-default

  Correct Answer: D

  "mod all" is incorrect. "mod 1test" is incorrect. "publish event" is incorrect. "mod 1 test" is correct. It is with "policy-default".

  Reference:

  https://www.ciscolive.com/c/dam/r/ciscolive/us/docs/2017/pdf/BRKDCN-3234.pdf

• Question 32:

  A Cisco UCS C-Series server is installed at a data center. The server should be managed by the Cisco UCS Manager by using a single cable for management and data traffic.

  Which configuration should be applied after the physical connection is established?

  A. UCS-A# scope server 1 UCS-A /server# scope cimc UCS-A /server/cimc # scope mgmt-conn sideband UCS-A /server/cimc # mgmt-conn-state enabled UCS-A /server/cimc/mgmt-conn* # commit-buffer

  B. UCS-A# scope chassis 1 UCS-A /chassis# scope cimc UCS-A /chassis/cimc # scope mgmt-conn sideband UCS-A /chassis/cimc/mgmt-conn # mgmt-conn-state enabled UCS-A /chassis/cimc/mgmt-conn* # commit-buffer

  C. UCS-A# scope chassis 1 UCS-A /chassis# scope cimc UCS-A /chassis /cimc # set mgmt-conn-state enabled UCS-A /chassis /cimc/mgmt-conn* # commit-buffer

  D. UCS-A# scope server 1 UCS-A /server# scope cimc UCS-A /server/cimc # scope mgmt-conn sideband UCS-A /server/cimc/mgmt-conn #set mgmt-conn-state enabled UCS-A /server/cimc/mgmt-conn* # commit-buffer

  Correct Answer: D

  UCS-A# scope server 1 UCS-A /server # scope cimc UCS-A /server/cimc # scope mgm UCS-A /server/cimc # scope mgmt-conn UCS-A /server/cimc # scope mgmt-conn sideband UCS-A /server/cimc/mgmt-conn # set mgmt-conn-state enabled UCS-A /server/cimc/mgmt-conn* # commit-buffer UCS-A /server/cimc/mgmt-conn

  https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/c-series_integration/ucsm3-1/b_C-Series-Integration_UCSM3-1/b_C-Series-Integration_UCSM3-1_chapter_010.html

• Question 33:

  The FCoE technology is used in a data center and the MDS switches are configured as Fibre Channel Forwarders. What configuration should be applied to an MDS switch in order to be used as the best switch to connect by the CNAs in the fabric?

  A. fcoe fcf-priority 1024

  B. fcoe fcf-priority 512

  C. fcoe fcf-priority 0

  D. no fcoe fcf-priority

  Correct Answer: C

  https://www.cisco.com/c/en/us/td/docs/switches/datacenter/nexus5000/sw/fcoe/521n11/b_5k_FCoE_Config_521N11/b_5k_FCoE_Config_521N11_chapter_011.pdf

• Question 34:

  An engineer must create a backup file of the entire Cisco UCS system before the maintenance window starts. The backup file must include these attributes:

  1.

  all logical configuration settings such as service profiles. VLANs. and VSANs

  2.

  all Cisco UCS usernames. roles, and locales

  3.

  all Cisco UCS system settings

  Which backup type must be selected to achieve this goal?

  A. All Configuration

  B. Full State

  C. System Configuration

  D. Logical Configuration

  Correct Answer: A

• Question 35:

  What are two requirements when planning a Cisco HyperFlex All Flash standard cluster installation using three HX240c M5 servers? (Choose Two)

  A. If the Jumbo MTU option in the HyperFlex installer is enabled, then jumbo frames do not have to be enabled on the upstream switches.

  B. The hypervisors must be installed to Cisco FlexFlash SD cards.

  C. If the Jumbo MTU option in the HyperFlex installer is enabled, then jumbo frames must also be enabled on the upstream switches.

  D. The cluster deployment type must support a mix of HDD and SSD.

  E. The servers must be discovered, unassociated, and connected to each fabric interconnect.

  Correct Answer: CE

  https://www.cisco.com/c/en/us/td/docs/hyperconverged_systems/HyperFlex_HX_DataPlatf ormSoftware/AdminGuide/3_5/b_HyperFlexSystems_AdministrationGuide_3_5/b_HyperFlexSystems_AdministrationGuide_3_5_chapter_01111.html

• Question 36:

  Which three firmware packages are included in the Cisco UCS C-Series Rack-Mount UCS-Managed Server Software bundle? (Choose three.)

  A. CIMC

  B. board controller

  C. system

  D. third-party

  E. BIOS

  F. adapter

  Correct Answer: AEF

• Question 37:

  A network engineer must configure a Cisco MDS switch to use the local user database for console access if all AAA servers are unreachable. Which configuration should be applied to complete this task?

  A. aaa authentication login default fallback error local

  B. aaa authentication login default local

  C. aaa authentication login console local

  D. aaa authentication login console fallback error local

  Correct Answer: D

• Question 38:

  Refer to the exhibit.



  What is the result of implementing the configuration?

  A. RADIUS traffic is sourced from the VLAN 200 interface.

  B. The RADIUS server timeout value is 15 milliseconds.

  C. Only the RADIUS server is used for authentication.

  D. Users specify the RADIUS server when they log in.

  Correct Answer: C

• Question 39:

  Which server policy is used to install new Cisco IMC software on a server?

  A. host firmware policy

  B. hypervisor firmware policy

  C. BIOS software policy

  D. Cisco IMC software policy

  Correct Answer: A

  https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/ucs-manager/CLI-User-Guides/Firmware-Mgmt/4-0/b_UCSM_CLI_Firmware_Management_Guide_4-0/ b_UCSM_CLI_Firmware_Management_Guide_4-0_chapter_01.html# You can use host firmware packages by defining a host firmware policy as an attribute of a service profile template, which is an updating template. Any change made to the service profile template is automatically made to its instantiated service profiles. Subsequently, the servers associated with the service profiles are also upgraded in parallel with the firmware version.



• Question 40:

  A network engineer must determine the cooling requirements for a Cisco UCS C-Series Rack Server. The server with PCIe cards is configured with a fan configuration policy. Which configuration should be used for the fan policy of the server?



  A. Option A

  B. Option B

  C. Option C

  D. Option D

  Correct Answer: A
