Cisco 350-080 Online Practice Questions and Exam Preparation

Cisco 350-080 Online Questions & Answers

• Question 211:

  In a FabricPath topology, each device is identified by a switch ID, and all Layer 2 forwarding tables are built based on the reachability of the switch ID. Which protocol is used to assign the switch ID?

  A. No protocol is used. The switch ID is always assigned manually.
  B. The Dynamic Resource Allocation Protocol is used to assign the switch ID.
  C. The Switch ID Assignment Protocol is used to assign the switch ID.
  D. The switch ID is assigned based on the system ID of the device.
  B. The Dynamic Resource Allocation Protocol is used to assign the switch ID.

• Question 212:

  Which two actions must occur to disable the LAN traffic on an FCoE link to a host? (Choose two.)

  A. interface Ethernet 1/1 shutdown lan
  B. The switch sends a LAN logical link status message to the CNA host.
  C. interface vfc11 shutdown lan
  D. The switch send a PFC command to the CNA host.
  E. interface Ethernet 1/1 vlan 10 disable
  A. interface Ethernet 1/1 shutdown lan
  B. The switch sends a LAN logical link status message to the CNA host.

• Question 213:

  Which two FEX connection modes are correct? (Choose two.)

  A. hard-pinning mode
  B. soft-pinning mode
  C. port channel mode
  D. physical-pinning mode
  E. vlan pinning mode
  A. hard-pinning mode
  C. port channel mode

• Question 214:

  Overlay Transport Virtualization (OTV) provides an overlay that enables Layer 2 connectivity between separate Layer 2 domains, while keeping these domains independent and preserving the fault isolation, resiliency, and load-balancing benefits of an IP-based interconnection.

  Which statements are true about OTV Adjacency Server? (Choose two.)

  A. Adjacency Server is required when OTV is deployed with unicast-only transport.
  B. Adjacency Server is required when OTV is deployed with multicast-enabled transport.
  C. Each OTV device wishing to join a specific OTV logical overlay needs to first register with the Adjacency Server.
  D. Each OTV device trying to join a specific OTV logical overlay needs to be configured as an Adjacency Server.
  A. Adjacency Server is required when OTV is deployed with unicast-only transport.
  C. Each OTV device wishing to join a specific OTV logical overlay needs to first register with the Adjacency Server.

• Question 215:

  Given a Cisco Unified Computing System, which is a valid port type in end-host mode?

  A. Trunk
  B. Physical
  C. Uplink
  D. Switch
  E. End host
  C. Uplink

• Question 216:

  Which two Fibre Channel features are not supported in Cisco Nexus 5500 and Nexus 5000 platforms? (Choose two.)

  A. port security
  B. fabric binding
  C. IVR
  D. port tracking
  E. FICON
  C. IVR
  E. FICON

• Question 217:

  Which two options describe virtualized multi-tenancy? (Choose two.)

  A. dedicated infrastructure for each tenant
  B. shares a common infrastructure between tenants
  C. agreement between tenants with rules about sharing DC resources
  D. tenants using virtualization technologies to separate from each other
  E. data centers using virtualization technologies to separate tenants
  B. shares a common infrastructure between tenants
  E. data centers using virtualization technologies to separate tenants

• Question 218:

  A network administrator has installed an N7K-F248-25XP module into an existing chassis. The module is powered on, but the interfaces are all in VDC0. What is the reason for this?

  A. The chassis needs an EPLD upgrade to support the new module type.
  B. The default VDC cannot support F2 modules.
  C. The interfaces must be allocated into a VDC for F2 modules only.
  D. The module has failed GOLD diagnostics, and the switch has isolated the ports to protect the integrity of the system.
  C. The interfaces must be allocated into a VDC for F2 modules only.

• Question 219:

  Refer to the exhibit.



  Which two statements about the diagram are true? (Choose two.)

  A. Cisco UCS Manager is set to FC switching mode.
  B. Cisco UCS Manager is set to FC end-host mode.
  C. The topology is not supported.
  D. The uplinks from each FI can carry multiple VSANs.
  E. The uplinks from each FI can carry a single VSAN only.
  B. Cisco UCS Manager is set to FC end-host mode.
  D. The uplinks from each FI can carry multiple VSANs.

• Question 220:

  What are the two parallel SCSI specifications? (Choose two.)

  A. Up to 25 m bus length
  B. Only one device per SCSI bus
  C. Up to 16 devices per SCSI bus
  D. Half-duplex operation
  E. Full-duplex operation
  A. Up to 25 m bus length
  C. Up to 16 devices per SCSI bus
