3102 Online Practice Questions and Verified Answers

Question 1 Single choice

Which statement is true with regard to SIP Monitoring being enabled on a SIP Entity?

A
Session Manager will monitor the status of that SIP Entity by sending SIP OPTIONS requests.
B
SIP Entity will monitor the status of Session Manager by sending SIP OPTIONS requests.
C
Session Manager will monitor the status of that SIP Entity by sending SIP SUBSCRIBE requests.
D
Session Manager will monitor the status of that SIP Entity by sending SIP NOTIFY requests.
E
System Manager will monitor the status of that SIP Entity by sending SIP OPTIONS requests.

Show answer and explanation

Correct answer: A

Question 2 Multiple choice

A technician wants to schedule a bulk operation to take place at a convenient time in the future.

What are two methods for scheduling bulk operations? (Choose two.)

A
# Sh exportUpmUsers.sh -u admin -p adminl23 -t 2013:05:01:12:00:00
B
# sh exportUpmUsers.sh -u admin -p adminl23 -d 2013:05:01:12:00:00
C
Navigate to Users > User Management, click 'More Options' and select 'Import Users'. Choose
'schedule' in the options.
D
Navigate to Users > User Management, click 'More Options' and select 'Export Users'. Choose
'schedule' in the options.

Show answer and explanation

Correct answers: C, D

Question 3 Multiple choice

A Configuration Manager instance has been set up by an inexperienced administrator. A SIP entity in the network is failing on a regular basis and Session Manager sometimes does not detect the failure for up to 30minutes.

Which two Session Manager Configuration fields could have been set incorrectly? (Choose two)

A
Proactive cycle time.
B
Reactive cycle time.
C
Timer period
D
Override port and transport with DNS SRV

Show answer and explanation

Correct answers: A, D

Question 4 Single choice

Review the output of the command shown in the exhibit.

Which command is used to generate these results and what does it tell you?

A
swversion displays the Session Manager Release information.
B
statapp displays the current status of the Session Manager services.
C
initDRS displays the Session Manager Node registration and data replication.
D
traceSM displays a ladder trace of the SIP requests going in and out of the Session Manager.
E
smconfig displays the network information and status the Session Manager.

Show answer and explanation

Correct answer: E

Question 5 Single choice

While performing routine maintenance a technician has had to re-install System Platform.

Which statement describes what must be done next?

A
The SMGR Template must be installed.
B
The SMGR Template must be installed, followed by the utilities domain (in that order),
C
The utilities domain must be installed, followed by the SMGR Template (In that order),
D
The Dom-0 must be installed, followed that order) by the utilities domain and then the SMGR Template (in that order).

Show answer and explanation

Correct answer: A

Question 6 Single choice

What is validated when the Transport Layer Security (TLS) handshake and mutual TLS authentication is performed between the SIP entity and Session Manager?

A
entity link
B
entity name
C
domain
D
certificate

Show answer and explanation

Correct answer: D

Question 7 Single choice

While reviewing the session Manager logs, you notice a log entry that describes that state of an entity
"down". Later, you check the logs and notice another log entry that reports the same entity is "partially up".

Which troubleshooting procedure will help you to isolate and identify the Entity problem?

A
Run traceSM to capture SIP INVITE message from the entity to determine if there is a display in the network.
B
Run SIP monitoring diagnostics along with ICMP ping to the Entity to verify its connectivity.
C
Run traceSM100 to capture SIP MONITOR message from the entity to determine if there is a delay in the network.
D
Run SIP Entity Performance on the Entity to determine id SIP OPTIONS messages are being blocked on the network.

Show answer and explanation

Correct answer: A

Question 8 Single choice

Review the output of the command shown in the exhibit.

Which command is used to generate these results and what does it tell you?

A
swversion displays the Session Manager release information.
B
statapp displays the current status of the Session Manager services.
C
smconfig displays the network information and status of the Session Manager.
D
traceSM displays a ladder trace of the SIP requests going in and out of the Session Manage.
E
initDRS displays the Session Manager node registration and data replication.

Show answer and explanation

Correct answer: B

Question 9 Multiple choice

Which two statements about Managed Bandwidth are true? (Choose two.)

A
If the Managed Bandwidth field is blank for a location no Call Admission Control is done for that location.
B
If the Managed Bandwidth field has a value. Session Manager keeps track of the bandwidth in use based on the calls coming out of and going to that specific location and denies new calls when the bandwidth in use reaches the limit.
C
If the Managed Bandwidth field is blank for a location, the default Call Admission Control is done for that location. Session Manager keeps track of the bandwidth in use based on the calls coming out of and going to that specific location and denies new calls when the bandwidth in use reaches the limit.
D
If the Managed Bandwidth field has a value. Session Manager keeps track of the bandwidth in use based on the calls coming out of and going to that specific location and drops old calls when the bandwidth in use reaches the limit.
E
If the Managed Bandwidth field has a value, Session Manager keeps track of the bandwidth in use based on the calls coming out of and going to that specific location and sends an alarm to an administrator when new calls reach the bandwidth the limit.

Show answer and explanation

Correct answers: A, B

Question 10 Single choice

During a post-installation check of System Manager and Session Manager you discover that the Session lager replica node is stuck at "Synchronizing". You run the initTM command in Session Manager but the replication status does not change.

Which step will be effective in resolving the problem?

A
Reset the enrollment password.
B
Run traceSM to monitor the synchronization events and restart the Security Module.
C
Delete the Session Manager Replica node in System Manager, verify the enrollment password is valid
In System Manager and run the initTM command again in Session Manager.
D
Verify the enrollment password is valid in System Manager and run the initTM command again in Session Manager.

Show answer and explanation

Correct answer: D
