Cisco CCNP 300-615 Questions & Answers

• Question 1:

  A Cisco ACI environment consists of three Cisco APICs, two spine switches, and four leaf switches. The engineer erases and reboots all APICs first, then leaf and spine switches individually, and then completes the Initial Setup dialog on the

  APIC1 CIMC KVM console. When the engineer logs in to the APIC1 web GUI, the engineer notices that there are no directly connected leaf switches being discovered under Fabric > Inventory > Fabric Membership.

  What is the cause of the issue?

  A. The leaf nodes were not erased properly, which caused a fabric parameters mismatch with the APIC1.

  B. Rebooting the APICs and the leaf and spine switches after wiping them is not required.

  C. The engineer did not enter the TEP Pool value during the Initial Setup dialog on APIC1.

  D. The same Fabric Name value should be used before and after wiping all devices.

  Correct Answer: C

• Question 2:

  Refer to the exhibit.



  A Cisco UCS Fabric Interconnect fails during the upgrade process. The working images of the fabric interconnect are stored on the bootflash. Which set of commands recovers the fabric interconnect?

  A. loader> dir loader> boot ucs-6300-k9-kickstart.5.0.2.N1.3.02d56.bin switch(boot)# init system switch(boot)# reload switch(boot)# load ucs-6300-k9-system.5.0.2.N1.3.02d56.bin

  B. loader> dir loader> boot ucs-6300-k9-kickstart.5.0.2.N1.3.02d56.bin switch(boot)# copy ucs-manager-k9.1.4.1k.bin nuova-sim-mgmt-nsg.0.1.001.bin switch(boot)# boot ucs-6300-k9-system.5.0.2.N1.3.02d56.bin

  C. loader> dir loader> boot ucs-6300-k9-kickstart.5.0.2.N1.3.02d56.bin switch(boot)# init system switch(boot)# reload switch(boot)# boot ucs-6300-k9-system.5.0.2.N1.3.02d56.bin

  D. loader> dir loader> boot ucs-6300-k9-kickstart.5.0.2.N1.3.02d56.bin switch(boot)# copy ucs-manager-k9.1.4.1k.bin nuova-sim-mgmt-nsg.0.1.001.bin switch(boot)# load ucs-6300-k9-system.5.0.2.N1.3.02d56.bin

  Correct Answer: D

• Question 3:

  Refer to the exhibit.



  The VXLAN fabric is deployed with this configuration:

  1.

  The VLAN 50 interface has no IP address on VTEP1 and VTEP4

  2.

  The VLAN 100 interface has no IP address on VTEP2 and VTEP3

  3.

  The nve1 interface is configured on all VTEPs

  Host A experiences timeouts when attempting to ping host B. Which set of actions allows host A to reach host B?

  A. On VTEP1, associate VNI 50000 to Test_Telco VRF On VTEP4, associate VNI 50000 to Test_Telco VRF

  B. On VTEP2, associate VNI 30000 to Test_Telco VRF On VTEP4, associate VNI 20000 to Test_Telco VRF

  C. On VTEP1, associate VNI 30000 to Test_Telco VRF On VTEP4, associate VNI 20000 to Test Telco VRF

  D. On VTEP2, associate VNI 55000 to Test_Telco VRF On VTEP4, associate VNI 50000 to Test_Telco VRF

  Correct Answer: A

• Question 4:

  Refer to the exhibit.



  28614: Feb 11 12:31:47.318 OTC: HSRP: V111 Grp 11 Hello out 10.10.10.2 Active pri 100 vIP 10.10.10.128615: Feb 11 12:31:48.568 UTC: HSRP: V111 Grp 11 Hello in 10.10.10.3 Active pri 110 vIP 10.10.10.128616: Feb 11 12:31:48.568 OTC: HSRP: v111 GrP 11 Auth failed for Hello pkt from 10.10.10.3, No key for this key ID28617: Feb 11 12:31:48.568 UTC: *HSRP-4-BADAUTH: Bad authentication from 10.10.10.3, group 11, remote state Active

  A network engineer notices a sudden interruption to the HSRP adjacency between the switches. The packet loss is reported on the servers for which the default gateway is set as the virtual IP of the HSRP. All servers on the VLAN can exchange ping messages. Which configuration set must be applied on the HSRP peers to resolve the adjacency issue?

  A. key 0accept-lifetime 00:00:00 Oct 01 2018 23:59:59 Sep 01 2020

  B. key 0send-lifetime 00:00:00 Oct 01 2018 23:59:59 Sep 01 2020

  C. key 1send-lifetime 00:00:00 Jun 01 2018 23:59:59 Sep 01 2022

  D. key 1accept-lifetime 00:00:00 Jun 01 2018 23:59:59 Sep 01 2020

  Correct Answer: D

• Question 5:

  Refer to the exhibit.



  An engineer must save the running configuration to startup-config and generate a syslog message indicating that the configuration was modified, but an error was received. Which action resolves the issue?

  A. Change the syslog action number to 1.

  B. Use the extended command copy running-config startup-config.

  C. Add event-default as a second action of the EEM script.

  D. Save the configuration using a user with network-admin role.

  Correct Answer: C

• Question 6:

  An engineer configures FCoE between a set of ESXi hosts and a Cisco Nexus 5000 Series Switch. The Converged Network Adapter of the host fails to receive the response from the Cisco Nexus device. Also, the VFC interface is in a down state and the FIP adapter fails to receive 802.1q tagged frames. The host interface is configured for VLAN trunking. Which action resolves the issue?

  A. Activate the reception of Xoff pause frames from the server

  B. Configure the UF link as a spanning-tree edge port

  C. Enable the active STP port state on the bound Ethernet interface

  D. Set the bound Ethernet trunk interface to non-FCoE native VLAN

  Correct Answer: D

• Question 7:

  Refer to the exhibit.



  The cURL command fails to complete. Which action resolves the problem?

  A. Remove ".json\" from the URL.

  B. Include -p "password" in the command.

  C. Change ".json" to ".xml" at the end of the URL.

  D. Add -H "X-Auth-Token" to the command.

  Correct Answer: D

• Question 8:

  Refer to the exhibit.



  The FCoE traffic fails to traverse the vfc2 interface. The VSAN 102 is configured for vfc2. Which action resolves the issue?

  A. Enable LLDP on the interface vfc2

  B. Activate DCBX on the N9K switch

  C. Activate DCBX on the interface e101/1/2

  D. Enable LLDP on the neighbor switch

  Correct Answer: D

• Question 9:

  Refer to the exhibit.



  A network engineer upgrades the firmware of a Cisco Fabric Interconnect from boot flash. During the process, the fabric interconnect reboots and displays the message shown in the exhibit. Which action resolves the issue?

  A. Remove the service pack and upgrade through the auto-install procedure

  B. Reset the I/O module and install the firmware image from the boot flash

  C. Boot the kickstart image from boot flash and load the system image

  D. Reload the switch and boot the kickstart image from the TFTP server

  Correct Answer: D

• Question 10:

  An FSM failed during an uparade with the auto-install feature enabled. The engineer must remove the service pack from the subordinate fabric interconnect (FI) to recover the Fls. Which set of commands resolves the issue?

  A. UCS-A# scope fabric-interconnect b UCS-A# /fabric-interconnect # remove service-pack security UCS-A# /fabric-interconnect* # commit-buffer

  B. UCS-A# scope org UCS-A /org # scope fw-infra-pack default UCS-A /org/fw-infra-pack # set infra-bundle-version "" UCS-A /org/fw-infra-pack* # commit-buffer

  C. UCS-A# scope org UCS-A /org # scope fw-infra-pack default UCS-A /org/fw-infra-pack # set infra-bundle-version "" UCS-A# /fabric-interconnect # remove service-pack security UCS-A# /fabric-interconnect* # commit-buffer

  D. UCS-A# scope fabric-interconnect b UCS-A# /fabric-interconnect # remove service-pack UCS-A# /fabric-interconnect* # commit-buffer

  Correct Answer: A
