Cisco 300-180 Online Practice Questions and Exam Preparation

Cisco 300-180 Online Questions & Answers

• Question 211:

  To ensure that DCBX can be run on a switch, which other feature must be enabled?

  A. Cisco Discovery Protocol
  B. LLDP
  C. Fibre Channel
  D. IEEE 802.1ad
  B. LLDP

• Question 212:

  Refer to the exhibit.



  You are configuring a Cisco APIC for access. Which task is being performed in the exhibit?

  A. configuring APIC management EpG
  B. creating the LDAP logjn domain
  C. creating the LDAP provider
  D. creating the LDAP provider group
  C. creating the LDAP provider

• Question 213:

  You are installing Microsoft Windows Server 2008 R2 on a Cisco UCS C210 M2 server, and the installer does not see local storage on the LSI MegaRAID SAS 9260-4i controller that is installed. Which statement explains the issue?

  A. The driver is not included in the installer DVD. Press F6 to load the LSI RAID driver from CD or virtual media.
  B. The virtual disk is not created and online.
  C. The LSI 9260-4i is only supported by Red Hat Enterprise Linux and VMware vSphere 4.0 and later.
  D. The installer DVD for Microsoft Windows Server 2008 R2 did not include the LSI driver until SP2.
  B. The virtual disk is not created and online.

• Question 214:

  Which configuration command is critical in order for OTV edge devices to maintain an overlay adjacency with their local peers in a multihomed site via the join interfaces across the Layer 3 network domain?

  A. otv site-vlan
  B. otv extend-vlan
  C. otv use-adjacency-server unicast-only
  D. otv site-identifier
  D. otv site-identifier

• Question 215:

  Which statement is true regarding STP?

  A. When the spanning-tree topology is calculated based on default parameters, the path between the source and destination end stations in a switched network might not be ideal.
  B. The path between the source and the destination end stations is always ideal with the default spanning-tree parameter.
  C. The path between the source and the destination end stations is determined by the speed of the link; the slowest link speed will become the root port during the election.
  D. The path between the source and the destination end stations is determined by the lowest MAC address; the lowest MAC address will become the root port during the election.
  A. When the spanning-tree topology is calculated based on default parameters, the path between the source and destination end stations in a switched network might not be ideal.

• Question 216:

  What is the correct sequence to export tech support data from the Cisco IMC GUI interface?

  A. Admin tab > Utilities > Export Technical Support to TFTP
  B. Utilities tab > Utilities > Export Technical Support to TFTP
  C. Server tab > Utilities > Export Technical Support to TFTP
  D. Communications tab > Utilities > Export Technical Support to TFTP
  E. Support tab > Utilities > Export Technical Support to TFTP
  F. Help tab > Utilities > Export Technical Support to TFTP
  A. Admin tab > Utilities > Export Technical Support to TFTP

• Question 217:

  A customer is configuring SAN pin groups in a Cisco UCS domain. The customer notices that pinning is not working and traffic from the vHBA is not passing over the Fibre Channel uplink port. Which of these must be done for pinning to work correctly?

  A. Include the SAN pin group in a vHBA policy and then include the vHBA policy in the service profile that is assigned to that server.
  B. Include the SAN policy in the Cisco UCS Manager to match with pin groups on the fabric interconnect.
  C. The customer must have Cisco UCS Manager version 2.0 or above.
  D. Fibre Channel switch mode needs to be configured first.
  A. Include the SAN pin group in a vHBA policy and then include the vHBA policy in the service profile that is assigned to that server.

• Question 218:

  The installation of a new OTV network connecting two data centers via a service provider LAN has failed verification steps. Which statement explains why certain types of data are not being successfully transferred across the OTV network?

  A. The number of extended VLANs across all configured overlays may be greater than 256.
  B. The number of MAC addresses on either edge device may exceed 4000.
  C. The additional 42-byte OTV overhead, along with the DF bit being set, may cause the service provider to drop packets based on their 1500 MTU settings.
  D. Having more than two edge devices per site is not supported.
  C. The additional 42-byte OTV overhead, along with the DF bit being set, may cause the service provider to drop packets based on their 1500 MTU settings.

• Question 219:

  A customer would like to create an Ethernet traffic monitoring session on a Cisco UCS server to troubleshoot network connectivity. The customer has entered the following commands via CLI: UCS-A# scope eth-traffic-mon UCS-A /eth-traffic-mon # scope fabric a UCS-A /eth-traffic-mon/fabric # create eth-mon-session EthMonitor33 UCS-A /eth-traffic-mon/fabric/eth-mon-session* # create dest-interface 2 12 UCS-A /eth-traffic-mon/fabric/eth-mon-session/dest-interface* # set speed 20gbps UCS-A /eth-traffic-mon/fabric/eth-mon-session/dest-interface* # commit-buffer UCS-A /eth-traffic-mon/fabric/eth-mon-session/dest-interface # Which outcome will this command sequence produce?

  A. It will create an Ethernet traffic monitoring session to copy and forward traffic to the destination port at slot 2, port 12, will set the admin speed to 20 Gb/s, and will commit the transaction.
  B. It will create an Ethernet traffic monitoring session to copy and forward traffic to the destination port at slot 2, port 33, will set the admin speed to 20 Gb/s, and will commit the transaction.
  C. It will create an Ethernet traffic monitoring session to copy and forward traffic to the destination port at slot 33, port 12, will set the admin speed to 20 Gb/s, and will commit the transaction.
  D. It will create an Ethernet traffic monitoring session to copy and forward traffic to the destination port at slot 2, port 12, will set the admin speed to 10 Gb/s, and will commit the transaction.
  A. It will create an Ethernet traffic monitoring session to copy and forward traffic to the destination port at slot 2, port 12, will set the admin speed to 20 Gb/s, and will commit the transaction.

• Question 220:

  You upgrade Cisco UCS Director. When you power on the Cisco UCS Director VM, the websock service fails to start. Which action do you take to resolve the issue?

  A. Resynchronize the NTP time and time zone information on each node.
  B. Import the correct SSL certificates.
  C. After you power on the VM, press Alt-F1 to refresh the VMware console.
  D. Ensure that the websock service starts automatically after an upgrade.
  B. Import the correct SSL certificates.
