Cisco 300-101 Online Practice Questions and Exam Preparation

Cisco 300-101 Online Questions & Answers

• Question 911:

  Which Cisco Express Forwarding table or tables hold forwarding information?

  A. FIB table only
  B. adjacency tables only
  C. FIB and adjacency tables only
  D. FIB,RIB, and adjacency tables
  C. FIB and adjacency tables only

• Question 912:

  Which prefix is matched by the command ip prefix-list name permit 10.8.0.0/16 ge 24 le 24?

  A. 10.9.1.0/24
  B. 10.8.0.0/24
  C. 10.8.0.0/16
  D. 10.8.0.0/23
  B. 10.8.0.0/24

• Question 913:

  What happens when an IPv6 enabled router running 6to4 must send a packet to a remote destination and the next hop is the address of 2002::/16?

  A. The IPv6 packet has its header removed and replaced with an IPv4 header
  B. The IPv6 packet is encapsulated in an IPv4 packet using an IPv4 protocol type of 41
  C. The IPv6 packet is dropped because that destination is unable to route IPv6 packets
  D. The packet is tagged with an IPv6 header and the IPv6 prefix is included
  B. The IPv6 packet is encapsulated in an IPv4 packet using an IPv4 protocol type of 41

• Question 914:

  When a packet is denied by an IPv6 traffic filter, which additional action does the device perform?

  A. It scans the rest of the ACL for a permit entry matching the destination
  B. It generates a TCP Fin bit and sends it to the source
  C. A creates a null route for the destination and adds it to the route table
  D. It generates an ICMP unreachable message for the frame.
  D. It generates an ICMP unreachable message for the frame.

• Question 915:

  Which type of address does OSPFv3 use to form neighbor adjacencies and to send LSAs?

  A. unicast IPv6 addresses
  B. link-local addresses
  C. multicast address FF02::5
  D. unicast IPv4 addresses
  C. multicast address FF02::5

• Question 916:

  On which two types of interface is Frame Relay switching supported? (Choose two.)

  A. serial interfaces
  B. Ethernet interfaces
  C. fiber interfaces
  D. ISDN interfaces
  E. auxiliary interfaces
  A. serial interfaces
  D. ISDN interfaces

• Question 917:

  Technologies used in preparing Service Provider IPv6? (Choose two.)

  A. 6ND
  B. 6RD
  C. 6VPE
  D. VRF-Lite
  E. DS-Lite
  F. Dual-stackA
  B. 6RD
  E. DS-Lite

• Question 918:

  What is the purpose of configuring the router as a PPPoE client?

  A. to provide VPN access over L2TP
  B. to enable PPP session from the router to the termination device at the headend for metro Ethernet connectivity
  C. for DSL connectivity and removing the need for the end-user PC to run the PPPoE client software
  D. for connecting the router to a cable modem, which bridges the Ethernet frames from the router to the cable modem termination system
  C. for DSL connectivity and removing the need for the end-user PC to run the PPPoE client software

• Question 919:

  Drag and Drop

  Select and Place:





• Question 920:

  area 1 range 10.1.0.0 255.255.0.0 summary address 10.1.0.0 255.255.0000 What is the effect of those two commands?

  A. area 1 range -> command applied to summarize internal OSPF routes (ABR) Summary address -> command applied to summarize external OSPF routes (ASBR)
  B. PlaceHolder
  C. PlaceHolder
  D. PlaceHolder
  A. area 1 range -> command applied to summarize internal OSPF routes (ABR) Summary address -> command applied to summarize external OSPF routes (ASBR)
