Cisco 300-101 Online Practice Questions and Exam Preparation

Cisco 300-101 Online Questions & Answers

• Question 331:

  A network engineer recently deployed Easy Virtual Networking in the enterprise network. Which feature improves shared services support?

  A. edge interfacing
  B. tunnel feedback
  C. route replication
  D. route redistribution
  C. route replication

• Question 332:

  When using VLSM, which command must be in the EIGRP configuration for neighbor adjacency to work correctly?

  A. no shutdown
  B. no auto-summary
  C. shutdown
  D. ip summary
  B. no auto-summary

• Question 333:

  Which PPP authentication method sends authentication information in cleartext?

  A. MS CHAP
  B. CDPCP
  C. CHAP
  D. PAP
  D. PAP

• Question 334:

  Router A and Router B are configured with IPv6 addressing and basic routing capabilities using oSPFv3.The networks that are advertised from Router A do not show up in Router B's routing table. After debugging IPv6 packets, the message "not a router" is found in the output. Why is the routing information not being learned by Router B?

  A. OSPFv3 timers were adjusted for fast convergence
  B. The networks were not advertised properly under the OSPFv3 process.
  C. An IPv6 traffic filter is blocking the networks from being learned via the Router B interface that is connected to Router A.
  D. IPv6 unicast routing is not enabled on Router A or Router B.
  D. IPv6 unicast routing is not enabled on Router A or Router B.

• Question 335:

  Which problem can be caused by latency on a UDP stream?

  A. The device that sends the stream is forced to hold data in the buffer for a longer period of time.
  B. The overall throughput of the stream is decreased.
  C. The device that receives the stream is forced to hold data in the buffer for a longer period of time.
  D. The devices at each end of the stream are forced to negotiate a smaller window size.
  C. The device that receives the stream is forced to hold data in the buffer for a longer period of time.

• Question 336:

  What is the output of the "show ntp associations" command?

  A. Authentication mode
  B. Facility configured
  C. Shows the NTP synchronized servers configured on the device
  D. Security key config
  C. Shows the NTP synchronized servers configured on the device

• Question 337:

  Question about NTP Authentication?

  A. NTP trusted key authorises the entity
  B. NTP Authentication Key ID enables NTP on the interface
  C. PlaceHolder
  D. PlaceHolder
  A. NTP trusted key authorises the entity

• Question 338:

  Which two features are added in MSCHAP Version 2 (choose two)

  A. Backwards-compatibility with MSCHAP version 1
  B. Using the MD5 hash for stronger security
  C. Ability to change an expired password
  D. using 3 way handshakes for authentication
  E. mutual authentication between peers
  C. Ability to change an expired password
  E. mutual authentication between peers

• Question 339:

  Which value does GRE tunnel use to identify the end points or destination

  A. IP ADDRESS
  B. MAC ADDRESS
  C. DLCI
  D. TUNNEL
  A. IP ADDRESS

• Question 340:

  Refer to the exhibit. A network engineer executes the show ipv6 ospf database command and is presented with the output that is shown. Which flooding scope is referenced in the link-state type?



  A. link-local
  B. area
  C. As (OSPF domain)
  D. reserved
  B. area
