Cisco 300-101 Online Practice Questions and Exam Preparation

Cisco 300-101 Online Questions & Answers

• Question 151:

  A network engineer applies the command ip tcp adjust-mss under interface configuration mode. What is the result?

  A. The probability of SYN packet truncation is increased.
  B. The UDP session is inversely affected.
  C. The probability of dropped or segmented TCP packets is decreased.
  D. The optimum MTU value for the interface is set.
  C. The probability of dropped or segmented TCP packets is decreased.

• Question 152:

  In which form does PAP authentication send the username and password across the link?

  A. Encrypted
  B. Password protected
  C. Clear text
  D. Hashed
  C. Clear text

• Question 153:

  You have been asked to evaluate how EIGRP is functioning in a customer network.



  Traffic from R1 to R61 s Loopback address is load shared between R1-R2-R4-R6 and R1-R3- R5-R6 paths. What is the ratio of traffic over each path?

  A. 1:1
  B. 1:5
  C. 6:8
  D. 19:80
  D. 19:80

• Question 154:

  In which scenario can asymmetric routing occur?

  A. active/active firewall setup
  B. single path in and out of the network.
  C. active/standby firewall setup
  D. redundant routers running VRRP
  D. redundant routers running VRRP

• Question 155:

  A network engineer is configuring two dedicated Internet connections within the Internet module. One connection is the primary connection to all wired business communications, while the other is the primary connection for all customer wireless traffic. If one of the links goes down, the affected traffic needs to be redirected to the redundant link. Which current technology should be deployed to monitor the scenario?

  A. IP SLA
  B. MMC
  C. IP SAA
  D. PBR
  A. IP SLA

• Question 156:

  Which NetFlow component is applied to an interface and collects information about flows?

  A. flow monitor
  B. flow exporter
  C. flow sampler
  D. flow collector
  A. flow monitor

• Question 157:

  Which of the following are characteristics of TACACS+? (Choose two.)

  A. Uses UDP
  B. Encrypts an entire packet
  C. Offers robust accounting
  D. Cisco-proprietary
  B. Encrypts an entire packet
  D. Cisco-proprietary

• Question 158:

  Which technology was originally developed for routers to handle fragmentation in the path between end points?

  A. PMTUD
  B. MSS
  C. windowing
  D. TCP
  E. global synchronization
  A. PMTUD

• Question 159:

  How does an EVN provide end-to-end virtualization

  A. It tags traffic with an 802.1q at the edge interface
  B. it tags traffic with an 802.1q at the trunk interface
  C. it tags traffic with a virtual network tag at the edge interface
  D. it tags traffic with a virtual network tag at the trunk interface
  D. it tags traffic with a virtual network tag at the trunk interface

• Question 160:

  At which layer does Cisco Express Forwarding use adjacency tables to populate addressing information?

  A. Layer4
  B. Layer 2
  C. Layer 1
  D. Layer 3
  B. Layer 2
