Juniper JN0-360 Online Practice Questions and Exam Preparation

Juniper JN0-360 Online Questions & Answers

• Question 501:

  Which type of router can provide connectivity between areas in an IS-IS domain?

  A. a Level 1 router with adjacencies within a single area
  B. a Level 2 router with adjacencies in more than one area
  C. an area border router with adjacencies in more than one area
  D. a Level 2 router with adjacencies in a single area
  B. a Level 2 router with adjacencies in more than one area

• Question 502:

  What are three components of the tag portion of an 802.1Q-tagged Ethernet frame? (Choose three.)

  A. Tag Protocol Identifier
  B. maximum transmission unit
  C. canonical format indicator
  D. unique VLAN identifier
  E. frame check sequence
  A. Tag Protocol Identifier
  C. canonical format indicator
  D. unique VLAN identifier

• Question 503:

  An established RSVP-signaled LSP suffers a link failure. What is one action taken by the local RSVP-enabled router?

  A. A ResvTear message is sent downstream.
  B. A ResvErr message is sent upstream.
  C. A ResvErr message is sent downstream.
  D. A ResvTear message is sent upstream.
  A. A ResvTear message is sent downstream.

• Question 504:

  What are three IS-IS PDU types? (Choose three.)

  A. type length value
  B. link-state
  C. partial sequence number
  D. database description
  E. complete sequence number
  B. link-state
  C. partial sequence number
  E. complete sequence number

• Question 505:

  What are three ways that graceful Routing Engine switchover provides redundancy? (Choose three.)

  A. by preserving interface and kernel information
  B. by reducing time of RE failover
  C. by preserving the data plane information
  D. by preserving the control plane information
  E. by not restarting the PFE
  A. by preserving interface and kernel information
  B. by reducing time of RE failover
  E. by not restarting the PFE

• Question 506:

  Click the Exhibit.



  Referring to the exhibit, what is the result of applying this policy?

  A. The 172.18.1.0/24 prefix will be redistributed into OSPF as an internal route.
  B. The 172.18.1.1/32 prefix will be redistributed into OSPF as an external route.
  C. The 172.18.1.0/24 prefix will be redistributed into OSPF as an external route.
  D. The 172.18.1.1/32 prefix will be redistributed into OSPF as an internal route.
  C. The 172.18.1.0/24 prefix will be redistributed into OSPF as an external route.

• Question 507:

  In an IS-IS network, which device represents the pseudo-node?

  A. a designated intermediate system
  B. an area border router
  C. a router with an IS-IS export policy
  D. a router connected to the backbone
  A. a designated intermediate system

• Question 508:

  You are logged into a router and have navigated to the [edit routing-options] level of the hierarchy. You have been asked to create a static route that will use 43 18 7 1 as its primary next-hop and 76 1310 2 as its secondary next-hop. Which command correctly configures this setup?

  A. set static route 0/0 76.13.10.2 qualified-next-hop 43.18.7.1 pref 10
  B. set static route 0/0 next-hop 43.18.7.1 secondary-next-hop 76.13.10.2 preference 10
  C. set static route 0/0 next-hop [76.13.10.2 10.10.10.5] pref 10
  D. set static route 0/0 next-hop 43.18.7.1 qualified-next-hop 76.13.10.2 preference 10
  D. set static route 0/0 next-hop 43.18.7.1 qualified-next-hop 76.13.10.2 preference 10

• Question 509:

  Your network is using the Junos default MPLS settings. Which label operation is performed by penultimate router?

  A. pop
  B. push
  C. replace
  D. swap
  A. pop

• Question 510:

  You have entered the show ospf route command and see routes with a metric type of EXT2. What does this indicate?

  A. These routes are OSPF interarea routes.
  B. These routes have been redistributed into OSPF and are using a Type 2 metric.
  C. These routes are preferred over the same routes with an EXT1 metric.
  D. These routes are OSPF intra-area routes.
  B. These routes have been redistributed into OSPF and are using a Type 2 metric.
