Juniper JN0-360 Online Practice Questions and Exam Preparation

Juniper JN0-360 Online Questions & Answers

• Question 201:

  Click the Exhibit button.



  Referring to the exhibit, what is required to establish an IS-IS adjacency between these two routers?

  A. The interface connecting the two routers must be configured as a Level 2 interface.
  B. Both routers will require wide metrics to be enabled.
  C. The interface connecting the two routers must be configured as a Level 1 interface.
  D. Router A must be configured as the designated intermediate system (DIS).
  A. The interface connecting the two routers must be configured as a Level 2 interface.

• Question 202:

  By default, which Junos routing table stores RSVP egress router information?

  A. inet.1
  B. inet.2
  C. inet.3
  D. inet.4
  C. inet.3

• Question 203:

  In which two environments would BGP add value? (Choose two)

  A. an enterprise environment with a single upstream connection
  B. an enterprise environment with multiple upstream connections
  C. a service provider environment
  D. a home office environment
  B. an enterprise environment with multiple upstream connections
  C. a service provider environment

• Question 204:

  You asked to deploy a large-scale IS-IS network with multiple areas. In this scenario, which two statements are true? (Choose two.)

  A. The area IDs must be the same for Level 2 routers to from an adjacency.
  B. Level1 routers can from an adjacency with any other Level 1 router.
  C. Level1 routers can from an adjacency with any other Level 2 router.
  D. The area IDs must be the same for Level1 routers to from an adjacency.
  B. Level1 routers can from an adjacency with any other Level 1 router.
  D. The area IDs must be the same for Level1 routers to from an adjacency.

• Question 205:

  Click the Exhibit button



  You work for the regional Internet service provider shown in the exhibit You have a partial BGP table and are receiving a 10 100/16 route from your upstream ISP You have been asked to configure a default route that can be sent to your downstream customer This route should forward customer traffic toward your upstream Tier 11SP as long as the 10.100/16 route is present.

  What would accomplish this goal?

  A. Create and announce an aggregate default route
  B. Create and announce a static default route with a next-hop of discard
  C. Create and announce a static default route with a next-hop of reject
  D. Create and announce a generated default route
  E. Create an advertise-map with exist-map
  E. Create an advertise-map with exist-map

• Question 206:

  What are two benefits of using an OSPF designated router (DR)? (Choose two.)

  A. Reduces the size of the link-state database.
  B. Reduces LSA flooding on a broadcast segment.
  C. Reduces LSA flooding throughout an OSPF area.
  D. Reduces router resources used.
  B. Reduces LSA flooding on a broadcast segment.
  D. Reduces router resources used.

• Question 207:

  Which command will display the number of IS-IS packets sent and received on a Junos device?

  A. show isis packets
  B. show isis spf log
  C. show isis statistics
  D. show isis exchanges
  C. show isis statistics

• Question 208:

  Click the Exhibit.



  On an MX Series device, you must enable routing between VLANs 100,200, and the Internet ge-5/1/0, and ge-5/1/2 are bundled into interface ae3. Ge-5/1/4, and ge-5/1/5 are bundles into interface ae2. Both AE bundles trunk VLANs 100 and

  200. In this scenario, what is the correct configuration snippet for VLAN 100?

  A. interfaces {xe-2/1/0 {unit 0{family inter {address 10.0.10.2/24;}}}irb {unit 0{family inet {address 10.0.1.2/24;}}unit 1 family inet {address 10.0.2.2/24;}}}}bridge-domains {vlan-100{domain-type bridge;vlan-id 100; interface ge-2/2/2.100; interface ae1.100; interface ae3.100; routing-interface irb.0;}}
  B. interfaces {xe-2/1/0{unit 0{family inet {address 10.0.10.2/24;}}}ip-0/0/0{unit 0{family inet {address 10.0.1.2/24;}}unit 1{family inet {address 10.0.2.2/24;}}}}bridge-domains {vlan- 100{domain-type bridge;vlan-id 100; interface ge-2/2/2.100; interface ae1.100; interface ae3.100; interface ip-0/0/0.0;}}
  C. interfaces {xe-2/1/0 {unit 0 {family inet {address 10.0.10.2/24;}}}irb {unit 0{family inet {address 10.0.1.2/24:}}unit 1 {family inet {address 10.0.2.2/24;}}}}bridge- domains {vlan-100{domain-type bridge;vlan-id 100; interface ge-2/2/2.100; interface ae1.100; interface ae3.100;}}
  D. interfaces {xe-2/1/0 {unit 0{family inet {address 10.0.10.2/24;}}}ip-0/0/0 {unit 0 {family inet {address 10.0.1.2/24;}}unit 1 {family inet {address 10.0.2.2/24;}}}}bridge-domains {vlan-100{domain-type bridge;vlan-id 100; interface ge-2/2/2.100; interface xe-2/1/0.0; Interface ae1.100; interface ae3.100; interface ip-0/0/0.0;}}
  C. interfaces {xe-2/1/0 {unit 0 {family inet {address 10.0.10.2/24;}}}irb {unit 0{family inet {address 10.0.1.2/24:}}unit 1 {family inet {address 10.0.2.2/24;}}}}bridge- domains {vlan-100{domain-type bridge;vlan-id 100; interface ge-2/2/2.100; interface ae1.100; interface ae3.100;}}

• Question 209:

  Which three statements are true of GRE tunnels? (Choose three.)

  A. The local tunnel endpoint must have a valid route to the remote endpoint
  B. GRE tunnels must authenticate at both ends fo the tunnel
  C. Tunnel endpoints must have a route that directs traffic into a tunnel
  D. The gr interface can only route packets that are IP protocol packets
  E. All intermediary devices must have a route to the tunnel endpoints
  A. The local tunnel endpoint must have a valid route to the remote endpoint
  C. Tunnel endpoints must have a route that directs traffic into a tunnel
  E. All intermediary devices must have a route to the tunnel endpoints

• Question 210:

  You want to influence how traffic enters your network.

  Using industry best practices, which two BGP attributes would you modify to accomplish this goal? (Choose two)

  A. AS Path
  B. Local Preference
  C. Next Hop
  D. MED
  A. AS Path
  D. MED
