HP2-Z34 Real Exam Questions and Verified Answers

Question 1 Single choice

Refer to the exhibit

An administrator is establishing an MPLS domain to allow communication between 10.1.0.0/16.10 2 0 0/16. and 10.3 0.0/16. The solution will use OSPF routing and LDP.
On which PE and P devices should these protocols be configured?

A
All P and PE devices should be configured with MPLS, but only P devices need OSPF and only PE devices need LDP.
B
All P and PE devices should be configured with MPLS, LDP. and OSPF.
C
All P and PE devices should be configured with MPLS, but only PE devices need OSPF and LDP.
D
All P and PE devices should be configured with MPLS and LDP. but only PE devices need OSPF.

Show answer and explanation

Correct answer: A

Question 2 Single choice

An HP Comware switch supports FCoE in Fibre Channel Forwarder (FCF) mode. A switch interface Ten1/0/1 connects to a server FCoE Converged Network Adapter (CNA). The CNA will carry normal data
2. which is associated with VLAN
20.

How does the administrator assign FCoE traffic for this CNA to VSAN 2?

A
by accessing the VSAN 2 configuration view and specifying Ten1/0/1 as a member port of the VSAN
B
by accessing the VLAN 20 configuration view and specifying Ten1/0/1 as a member port of the VLAN
C
by setting Ten1/0/1 to FCoE mode and specifying VSAN 2 as the port access VSAN
D
by binding a VFC interface to Ten 1/0/1 and specifying VSAN 2 as the VFC interface trunk VSAN

Show answer and explanation

Correct answer: A

Question 3 Single choice

Refer to the exhibit

An administrator wants these switches to establish a TRILL region TRILL is enabled globally and nicknames are set.

What must the administrator do so that each TRILL switch (RBridge) finds the best path to all other TRILL switches?

A
Configure IS-IS on VLAN 1 on all the switches.
B
Enable TRILL with the correct link-type on each switch-to-switch port
C
Configure DRB priorities on all switch-to-switch links.
D
Create a Virtual Service Instance (VSI) on each switch and define the other switches as TRILL peers.

Show answer and explanation

Correct answer: B

Question 4 Single choice

When is it recommended to block VRRP hellos between routers in the same VRRP instance?

A
when the VRRP master and VRRP backup router are part of the same IRF virtual device
B
when providing two VRRP master routers to be deployed in different data centers
C
when the VRRP master and VRRP backup router are part of a TRILL domain
D
when the VRRP master and VRRP backup router are top of the rack (ToR) switches

Show answer and explanation

Correct answer: A

Question 5 Single choice

Refer to the exhibits Exhibit 1

This data center topology is being set up to use SPBM. VMs in the same subnet should be able to communicate at Layer 2 and be isolated at Layer 2 from other subnets. VS110010 was created for VLAN 10 as shown in Exhibit 2. The administrator is configuring a service instance for the VLAN 10 traffic on Switch 1 interface Ten1/0/1.

What is the correct encapsulation mode?

A
s-vid101
B
ta99ed
C
default
D
s-vid10

Show answer and explanation

Correct answer: D

Question 6 Single choice

Several VPN instances have been set up on an HP Comware switch.

What should the administrator do to ensure that no VPN instance uses up too many switch resources?

A
Apply a service policy to each instance to assign that instance a percentage of resources
B
Bind each instance to a specific port group or ASIC
C
Set a maximum number of routes that each instance can have in its routing table.
D
Set a CPU weight for each VPN instance to control how much of the CPU the instance can use.

Show answer and explanation

Correct answer: A

Question 7 Single choice

An administrator configures an HP Comware switch to support FCoE in Fibre Channel Forwarder (FCF) mode A switch interface connects to a server FC host bus adapter (HBA).

What is the correct configuration for this port?

A
bound to a VFC interface, which is in F mode
B
bound to a VFC interface, which is in E mode
C
FC port >n F mode
D
FC port in NP mode

Show answer and explanation

Correct answer: B

Question 8 Single choice

Refer to the exhibit

These switches form an SPBM region.

What is required for load balancing to occur across the links between these switches?

A
IS-IS cost for each backbone link must be the same (with IS-IS ECMP enabled).
B
B-VLANs must be configured to use different ECT algorithms.
C
Tandem multicast mode must be enabled globally
D
B-VLANs must be assigned to different MSTP instances.

Show answer and explanation

Correct answer: C

Question 9 Single choice

An administrator is implementing MDC and wants to create a redundant solution where each MDC uses two physical HP Comware switches.

What is the correct setup process?

A
Set up the MDCs on both switches. Configure Intelligent Resilient Framework (IRF) between the two switches on each MDC separately.
B
Combine the two switches in an Intelligent Resilient Framework (IRF) virtual device Set up the MDCs on this device.
C
Set up the MDCs on both switches. Use the Admin MDC to configure Intelligent Resilient Framework (IRF) on the two switches
D
Enable MDC on both switches in resiliency mode Configure the MDCs on each device using the same MDC IDs on each Connect the devices.

Show answer and explanation

Correct answer: D

Question 10 Single choice

Refer to the exhibit

An administrator is setting up this data center topology to use SPBM VMs in the same subnet should be able to communicate at Layer 2 and be isolated at Layer 2 from other subnets.
On which Switch 1 interfaces should the administrator enable SPBM?

A
interfaces Ten1/0/1-Ten1/0/48 and interfaces Forty1/0749-1/0750
B
interfaces Forty 1/0749-1/075 only
C
VLAN interfaces 101 and 103
D
VLAN interfaces 10, 20, and 30

Show answer and explanation

Correct answer: C
