Huawei H12-211 Online Questions & Answers

• Question 171:

  Which of following may be the reasons that cause Frame Relay PVC to work abnormally? (Choose three)

  A. Same DLCI number is configured on the same router
  B. LMI type mismatch
  C. Frame Relay encapsulation type mismatch
  D. Incorrect configuration of the DLCI number
  B. LMI type mismatch
  C. Frame Relay encapsulation type mismatch
  D. Incorrect configuration of the DLCI number

• Question 172:

  In the STP protocol, assume that all switches have the same priority, and the MAC address of switch 1 is 00-e0-fc-00-00-40, switch 2 The MAC address of the switch is 00-e0-fc-00-00-10, the MAC address of switch 3 is 00-e0-fc-00-00- 20, and the MAC address of switch 4 is 00-e0-fc00-00-80, then the root switch should be ().

  A. Switch 1
  B. Switch 2
  C. Switch 3
  D. Switch 4
  B. Switch 2

• Question 173:

  An authenticator router has been configured with two domains named "Area1" and "Area2",

  following which a user is created with the username "huawei" and the password "hello" for authentication.

  Which domain does this user belongs to?

  A. Area1 domain
  B. Area2 domain
  C. default domain
  D. default_admin domain
  C. default domain

• Question 174:

  Layer 2 switches are data link layer devices that identify MAC addresses of Layer 2 data frames and forward Layer 2 data frames based on MAC addresses. In addition, they record mappings between MAC addresses and interfaces in the MAC address table.

  A. True
  B. False
  A. True

• Question 175:

  As shown in the figure, the ports connected to the host by SWA and SWB are both Access ports and the PVID is 2. G0/0/1 of SWA is a Hybrid port. The PVID is 1, and the port hybird tagged vlan 2 command is configured. G0/0/1 of the SWB is a trunk port, the PVID is 1, and VLAN 2 is allowed. Passed. The correct one in the following description is ().

  A. Host A can send a data frame to Host B but cannot receive a reply from Host B.
  B. Host A cannot send data frames to Host B but can receive data frames sent by Host B.
  C. Host A and host B cannot communicate at all.
  D. Normal communication between host A and host B
  D. Normal communication between host A and host B

• Question 176:

  Which command can be used to display the mapping between network address and DLCI on the router?

  A. display fr interface
  B. display fr
  C. display map-info
  D. display fr brief
  C. display map-info

• Question 177:

  Which of the following statements about the information contained in a Database Description packet are true? (Choose three)

  A. A Database Description packet contains all information about each LSA.
  B. A Database Description packet contains only the header of an LSA.
  C. The header of an LSA is the unique identifier of the LSA.
  D. The header of an LSA is only a small portion of all the data of the LSA.
  B. A Database Description packet contains only the header of an LSA.
  C. The header of an LSA is the unique identifier of the LSA.
  D. The header of an LSA is only a small portion of all the data of the LSA.

• Question 178:

  As shown in the figure, the H frame contains an IP packet sent from Host A to Host B, and the destination MAC address of the H frame is ().



  A. MAC address of G0/0/1 interface of RTB
  B. MAC address of G0/0/1 interface of RTC
  C. Host B's MAC address
  D. RTC G0/0/0 interface MAC address
  D. RTC G0/0/0 interface MAC address

• Question 179:

  The network structure and OSPF partition are shown in the figure. In addition to R1, routers R2, R3 and R4 are OSPF ABR routers.



  A. Correct
  B. Error
  B. Error

• Question 180:

  Which of the following statements are correct about NAT? (Choose three)

  A. NAT is the abbreviation for "Network Address Translation"
  B. NAT is used for translation between private and public network addresss.
  C. When hosts inside a private network access the outside network, NAT is not required.
  D. NAT provides an effective way to solve the problem of insufficient IP addresses.
  A. NAT is the abbreviation for "Network Address Translation"
  B. NAT is used for translation between private and public network addresss.
  D. NAT provides an effective way to solve the problem of insufficient IP addresses.
