Riverbed 830-01 Online Practice Questions and Exam Preparation

Riverbed 830-01 Online Questions & Answers

• Question 371:

  -- Exhibit



  -- Exhibit -Refer to the exhibit. When USER1 tried to access Server 1, the user sees the shown message on his Steelhead Mobile Client. What does this represent?

  A. The Steelhead Mobile client does not have enough licenses.
  B. The Steelhead Mobile client policy is configured with the "location awareness" feature.
  C. There are pass-through rules not allowing optimization.
  D. The Steelhead Mobile client did not initialize properly and needs to be reset.
  B. The Steelhead Mobile client policy is configured with the "location awareness" feature.

• Question 372:

  Refer to the exhibit.



  The customer would like to prevent a "black-holing" situation when using PBR when SH11 goes down. The Steelhead appliances are directly connected to the routers. What options are available to determine state level status of the Steelhead appliance? (Select 3)

  A. CDP
  B. NBAR
  C. Interface Tracking
  D. HTTP
  E. ICMP
  A. CDP
  C. Interface Tracking
  E. ICMP

• Question 373:

  The purpose of Intelligent Forwarding is to:

  A. Automatically detect Steelhead appliances in the network
  B. Help prevent network loops
  C. Assist in the creation of static routes on the Interceptor appliance
  D. Preclude the need for proper routing
  B. Help prevent network loops

• Question 374:

  What is visible on the CMC appliance home page dashboard? (Select 4)

  A. CMC appliance model
  B. CMC appliance version
  C. Logout
  D. Reset
  E. User Logged in
  A. CMC appliance model
  B. CMC appliance version
  C. Logout
  E. User Logged in

• Question 375:

  How do you clear the peer affinity information from an Interceptor?

  A. Issue the clear affinity command
  B. Restart the service
  C. Clear the fair peering flag
  D. Pause the Interceptor
  B. Restart the service

• Question 376:

  VSP on the Steelhead EX supports which features of VMware virtual machines? (Select 3)

  A. vSphere Fault Tolerance
  B. Reporting.
  C. Stopping, starting, and restarting virtual machines through vSphere.
  D. vSphere High Availability
  E. vSphere vMotion.
  F. Virtual machine configuration through vSphere.
  B. Reporting.
  C. Stopping, starting, and restarting virtual machines through vSphere.
  F. Virtual machine configuration through vSphere.

• Question 377:

  One of the Steelhead appliances in your Steelhead appliance cluster is running an older version of RiOS. You decide to schedule a change window to upgrade that Steelhead appliance's image to the current release. What should you do to ensure that the Steelhead appliance optimization still occurs and the upgraded Steelhead appliance no longer accepts new connections?

  A. Enable the "no in-path accept new" CLI command
  B. Create an in-path rule on the Steelhead appliance to bypass the connections
  C. On the Interceptor appliance, click on "Pause" for that particular Steelhead appliance
  D. Schedule a job on the Steelhead appliance to remove itself from the cluster
  E. All of the above
  C. On the Interceptor appliance, click on "Pause" for that particular Steelhead appliance

• Question 378:

  When enabling MS-SQL Layer 7 optimizations, what are the best practices to use? (Select 2)

  A. Peering rules specifying the specific MS-SQL server with an accept rule for all other traffic using port 1433
  B. Fixed-target rules specifying the specific MS-SQL server with pass-through rules for all other traffic using port 1433
  C. Auto-discovery specifying the specific MS-SQL server with pass-through rules for all other traffic using port 1433
  D. Server-side out-of-path specifying the specific MS-SQL server with an accept rule for all other traffic using port 1433
  E. No rules are needed; allow it to optimize all MS-SQL traffic
  B. Fixed-target rules specifying the specific MS-SQL server with pass-through rules for all other traffic using port 1433
  C. Auto-discovery specifying the specific MS-SQL server with pass-through rules for all other traffic using port 1433

• Question 379:

  In a quad Interceptor appliance deployment the directly connected pairs are configured in failover mode:

  IC-A and IC-B are failover buddies

  IC-C and IC-D are failover buddies

  To prevent asymmetric routing IC-A should be configured to have a neighbor relationship with which of the following peer Interceptors? (Select 2)

  A. IC-B
  B. IC-C
  C. IC-D
  D. Interceptor appliance uses auto discovery to learn about each other
  E. Neighbor relationships are unnecessary in a quad Interceptor appliance deployment
  B. IC-C
  C. IC-D

• Question 380:

  Three Steelhead appliances SH1, SH2, and SH3 are deployed as shown in the exhibit. They are all using the default auto-discovery rule for optimization. However, CLIENT99 experiences a failure when attempting to access either the HTTP or FTP service on SERVER88. CLIENT99 was able to access these services prior to the deployment of the three Steelhead appliances.



  Which of the following choices would most likely correct the problem?

  A. Remove SH2. Use only SH1 and SH3.
  B. Remove SH1. Use only SH2 and SH3.
  C. Turn on Connection Forwarding between SH1 and SH2
  D. Turn on Connection Forwarding between SH1 and SH3
  E. Turn on Connection Forwarding between SH2 and SH3
  C. Turn on Connection Forwarding between SH1 and SH2
