• Question 391:

  A SteelHead blocks all traffic when the appliance is powered off. What reasons could cause this behavior? (Choose two.)

  A. This behavior is by design.
  B. Router, switch and SteelHead interfaces have auto MDI/MDIX but incorrect cables have been used.
  C. Fail-to-block is enabled.
  D. The bypass NIC battery has failed.
  E. Router, switch and SteelHead interfaces are hard coded and incorrect cables have been used.
  B. Router, switch and SteelHead interfaces have auto MDI/MDIX but incorrect cables have been used.
  C. Fail-to-block is enabled.

• Question 392:

  The default setting for "allow failure" in the Interceptor appliance version 2.0 is: (Select 2)

  A. Is configurable
  B. Is not configurable
  C. Enabled by default
  D. Disabled by default
  A. Is configurable
  D. Disabled by default

• Question 393:

  When upgrading from Steelhead EX v1.0 to Steelhead EX v2.0, what happens to existing VM slots on the appliance?

  A. The VM slots are immediately available as enabled VMs.
  B. The VM slots need to be manually added by managing VSP using the VMware vSphere client.
  C. The VM slots need to be manually added by using the VNC console access provided within Steelhead EX v2.0.
  D. The VM slots need to be manually converted to the new format using the tools available in the Steelhead EX Web UI.
  D. The VM slots need to be manually converted to the new format using the tools available in the Steelhead EX Web UI.

• Question 394:

  A customer already has a SteelHead appliance in their datacenter and wants to add Steelhead Mobile. Their current deployment has their VPN gateway in parallel with their server-side SteelHead. The customer doesn't want to interrupt VPN clients by moving the SteelHead in-path with the VPN gateway, so they will test using a fixed-target rule to the SteelHead in-path interface. Take a look at this diagram:



  Will the client traffic be optimized to the server 192.168.1.10?

  A. No, the fixed-target rule should be directed to the SteelCentral Controller for SteelHead Mobile IP address.
  B. No, the SteelHead Mobile client will report `asymmetry' and fail to optimize.
  C. Yes, the WAN router will redirect traffic to the SteelHead using PBR.
  D. Yes, the fixed-target rule will direct traffic to the SteelHead correctly.
  B. No, the SteelHead Mobile client will report `asymmetry' and fail to optimize.

• Question 395:

  The WCCP protocol has a methodology of load balancing with two or more Steelhead appliances. What is the maximum number of buckets used for the HASH assignment?

  A. 8
  B. 32
  C. 64
  D. 128
  E. 256
  E. 256

• Question 396:

  Which physical Steelhead interface communicates with the Interceptor appliance?

  A. AUX
  B. Primary
  C. wan0_0
  D. B and C
  E. A, B, and C
  D. B and C

• Question 397:

  Which command will display current alarm status information?

  A. show stats alarm
  B. stats show alarm
  C. show alarm all
  D. alarm show all
  E. show all
  A. show stats alarm

• Question 398:

  What is configured in an Endpoint policy? (Choose the best answer)

  A. Redundant Steelhead Mobile Controllers
  B. In-path rules
  C. Group IDs
  D. Port labels
  A. Redundant Steelhead Mobile Controllers

• Question 399:

  The client-side Steelhead appliance has been configured for OOB Destination Transparency, what should the source IP/port be for the OOB connection?

  A. Client IP/random port
  B. Client-side Steelhead appliance in-path IP/random port
  C. Client IP/port 708
  D. Client-side Steelhead appliance in-path IP/port 708
  E. None of the above
  B. Client-side Steelhead appliance in-path IP/random port

• Question 400:

  Connection Pooling works with:

  A. Port and Full Transparency
  B. Correct Addressing and Port Transparency
  C. Correct Addressing only
  D. Correct Addressing, Port and Full Transparency
  E. Full Transparency only
  D. Correct Addressing, Port and Full Transparency
