Avaya 3100 Online Practice Questions and Exam Preparation

Avaya 3100 Online Questions & Answers

• Question 21:

  You are creating a new ISDN bunk group in a production system and you want to know the capacity and features that are enabled in the installed license file of the system. Which command will provide this information?

  A. system -parameters capacity
  B. system-parameters customer-options
  C. system -parameters features
  D. system-parameters customer-license
  B. system-parameters customer-options

• Question 22:

  Your customer had a short WAN outage and you want to know If all of the gateways have re-registered with the Communication Manager server. Which Interface and command must be used?

  A. ASA with a display process-status command
  B. SMI with a process status command
  C. SMI with a status summary command
  D. ASA with a status media-gateway command
  D. ASA with a status media-gateway command

• Question 23:



  With reference to the Alarm Report shown in the exhibit, which option describes the location of the alarm that occurred on May 13 at 09:25?

  A. cabinet 1, gateway b, media module 12, port 12
  B. gateway 1, server b, extension 1212
  C. cabinet 1, carrier b, slot 12, port 12
  D. server 1, gateway b, media module 12, port 12
  E. port network 1, cabinet b, carrier 12, slot 12
  C. cabinet 1, carrier b, slot 12, port 12

• Question 24:

  A user reports that when attempting to dial an external call to local number the system does nothing ?just silence.

  You interview the user as follows.

  You: What happens if you longer after you dial your number?

  User: once I waited for about half a minute, then I heard these tones that supported the something was wrong.

  You: Did the sound stay on the same pitch or did it change pitches back and forth?

  User: Back and forth one pitch higher than the other.

  You: OK, that helps. What did you dial to get an outside line?

  User: Nine (9)

  You: Thank you, I appreciate the information, I will get back with you shortly.



  With reference to the scenario shown in the exhibit, which action should you take?

  A. Re-administer the Dial Plan to requiring 10 digits for making local external calls
  B. Determine the correct Feature Access Code to make an external call and inform the user
  C. Re-administer the feature access code for the user's situation to dial `9' to make an external call.
  D. Do nothing to the Dial Plan but delete the "*" Feature Access Code
  B. Determine the correct Feature Access Code to make an external call and inform the user

• Question 25:

  Changes performed to Communication Manager are written to volatile RAM.

  Which Communication Manager SAT command must be used to copy these changes to the hard disk, so that In case of a loss of power, the changes will be available?

  A. Save translation
  B. Copy running-configuration startup-configuration
  C. Copy translation all
  D. Save translation startup-configuration
  A. Save translation

• Question 26:

  With respect to a Communication Manager Dial Plan, which command shows Multiple Locations enabled?

  A. Display Dial Plan Analysis
  B. Display System-Parameters Customer Options
  C. Display Dial Plan Parameters
  D. Display Customer Options
  C. Display Dial Plan Parameters

• Question 27:

  A remote user Avaya softphone to work from home reports that the client desktop application will not register. After verifying that the user has configured the softphone application to "point"to the current IP address of a Communication Manager Gatekeeper using an administered extension, you ask if the user supplied a password when logging on. The user confirms that the password was used on each log-on attempt.

  You look up the user's information and note that the type field is 4620 (IP telephone) and the security code field is.



  With reference to the scenario described in the exhibit, which action should you take to ensure that the user can use the IP SoftPhone?

  A. Change the IP SoftPhone field to y.
  B. Change the Converge Path 1 value to match the value in converge path 2.
  C. Change the message Lamp Ext value to match the extension number.
  D. Change the name in the name field to match the name as administered in the LDAP directory.
  A. Change the IP SoftPhone field to y.

• Question 28:

  Your customer does not use an AAA server. You have been asked to add four new administrative users with a new user profile that has display only access and no maintenance for the same categories as profile 20. Which interface must be used?

  A. ASA with GED1
  B. ASA with terminal emulation
  C. SMI
  D. SMI or ASA
  D. SMI or ASA

• Question 29:

  With respect to Avaya Aura? into which two categories does Communication Manager fit? (Choose two.)

  A. Architecture
  B. Communication Services
  C. Application
  D. Gateway
  A. Architecture
  D. Gateway

• Question 30:

  A user reports that when attempting to dial an external call to local number the system does nothing ?just silence.

  You interview the user as follows.

  You: What happens if you longer after you dial your number?

  User: once I waited for about half a minute, then I heard these tones that supported the something was wrong.

  You: Did the sound stay on the same pitch or did it change pitches back and forth?

  User: Back and forth one pitch higher than the other.

  You: OK, that helps. What did you dial to get an outside line?

  User: Nine (9)

  You: Thank you, I appreciate the information, I will get back with you shortly.



  With reference to the scenario described in the exhibit, which statement most accurately describes the situation?

  A. The user should have been able to complete the call as dialed
  B. The system must be re-administered to correct the situation
  C. After dialing "9" the user should have dialed more digits, then the external call would have completed
  D. The user did not dial the correct access code to make an external call
  D. The user did not dial the correct access code to make an external call
