Avaya Avaya Aura 3100 Questions & Answers

• Question 1:

  You execute the list history command.

  Which type of information do you expect to find in the history report?

  A. ASG session establishment/rejection data

  B. Processor occupancy statistics

  C. Security violation status summary

  D. Log Ins/logoffs, administrative and maintenance action commands

  Correct Answer: D

• Question 2:

  Which signaling protocol registers with Communication Manager?

  A. SIP

  B. H.225

  C. H.323

  D. SIP1

  Correct Answer: C

  Reference:http://downloads.avaya.com/css/P8/documents/100017155(p. 4, see topic 3.3)

• Question 3:

  In Communication Manager, in which way are alarms classified?

  A. By the number of times the alarms are recorded

  B. As a function of their effect on the system's operation

  C. Whether the alarms are on-board or off-board

  D. By the number of errors that appear

  Correct Answer: B

  Reference:http://downloads.avaya.com/css/P8/documents/100059436(p. 38, alarm levels)

• Question 4:

  Which two features are ports of COS? (Choose two.)

  A. Data Privacy

  B. Bridged Call Appearance

  C. ISDN-PRI

  D. Console Permissions

  Correct Answer: BC

• Question 5:

  Which type of traffic does a DID trunk support?

  A. Incoming and outgoing calls between the telephone system and the local central office

  B. Customer-provided equipment to the telephone system

  C. Incoming calls routed directly to internal extensions

  D. Outgoing calls between telephone system and the local central office

  Correct Answer: C

• Question 6:

  What does the Class of Service (COS) setting control?

  A. The applications that a user can access and use

  B. The capabilities or limits of calling privileges

  C. The level of service that the user will receive

  D. The pre-defined features that a user can access and use

  Correct Answer: A

  Reference:http://www.globalknowledge.net/mea-shared- content/documents/645372/645385/WP_AV_Avaya_Aura_CM_COS.pdf(p. 4)

• Question 7:

  Which statement is true about the Station Lock feature?

  A. The feature permits only incoming calls, and using a FAC and security code permits emergency or outgoing calls.

  B. The feature permits only outgoing calls, and using a FAC and security code permits Incoming and outgoing calls.

  C. The feature permits Incoming calls, and the telephone can be unlocked only from designated telephone(s) by inputting a security code.

  D. The feature overrides the COR of a station.

  Correct Answer: C

• Question 8:

  On the add trunk-group x form, what must match the DAC in the Dial Plan Analysis form?

  A. FNPA

  B. TAC

  C. COS

  D. Ext

  Correct Answer: D

• Question 9:

  Which Call Pickup Group allows the administrator the ability to combine different Pickup Groups?

  A. Directed Call Pickup

  B. Pickup Group

  C. Expanded Pickup Group

  D. Extended Pickup Group

  Correct Answer: D

  Reference:https://downloads.avaya.com/css/P8/documents/100108861(p. 5)

• Question 10:

  Which concept is associated with Terminal Translation Initialization ?

  A. Class of Service (COS)

  B. Class of Restriction (COR)

  C. Extension to Cellular (EC)

  D. Administration without Hardware (AWOH)

  Correct Answer: D

  Reference:http://downloads.avaya.com/css/P8/documents/100059342(p. 119)
