Cisco 300-175 Online Practice Questions and Exam Preparation

Cisco 300-175 Online Questions & Answers

• Question 61:

  Which solution enables Cisco devices to be monitored with automated support capabilities?

  A. Cisco Intelligent Monitoring Agent
  B. Cisco Intersight
  C. connected Service Assurance
  D. Two-Tier Smarrt Agent
  B. Cisco Intersight

• Question 62:

  Drag Drop This questions concerns the installation of a Cisco Unified Computing System blade server hard drive. Drag the options on the left to the right side in the correct order when performing the installation. Note: Not all of the steps on the left will be used.

  Select and Place:





• Question 63:

  Which three AAA protocols are supported for communication with external AAA providers? (Choose three.)

  A. TACACS+
  B. RADIUS
  C. AD
  D. LDAP
  E. ACS
  F. 802.1X
  A. TACACS+
  B. RADIUS
  D. LDAP

  ---

  https://www.cisco.com/en/US/docs/unified_computing/ucs/sw/gui/config/guide/141/ UCSM_GUI_Configuration_Guide_141_chapter7.html#concept_95086D8A9B594FD29A3BD8AF5D2DA1

  FC Cisco UCS supports two methods to authenticate user logins:

  Through user accounts local to Cisco UCS Manager

  Remotely through one of the following protocols:

  LDAP

  RADIUS

  TACACS+

• Question 64:

  Scenario

  In this scenario, you will refer to screenshots about Cisco UCS B-Series servers and UCS Manager.

  Instructions

  To access the multiple-choice questions, click on the numbered boxes on the left of the top panel. There are four multiple-choice questions with this task. Be sure to answer all four questions before selecting the Next button.





  Refer to the screenshot in Exhibit 5. Which of the following user roles allows the permission Clear All Logs?

  A. read-only
  B. user
  C. operator
  D. system
  C. operator

  ---

  http://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/sw/gui/config/guide/2-0/b_UCSM_GUI_Configuration_Guide_2_0/b_UCSM_GUI_Configuration_Guide_2_0_chapter_0 1 001.html

• Question 65:

  You need to upgrade the firmware on 15 Cisco UCS C-Series Rack Servers. Ten of the servers are integrated in a Cisco UCS cluster, and the other five servers are used in standalone mode The Cisco UCS C-Series Rack-Mount Server Software Bundle is available. Which set of statements about the upgrade process is true?

  A. You cannot upgrade the firmware on the servers in standalone mode. You must cluster the servers first over LAN or via cluster interfaces. After the firmware upgrade, you can revert the five servers to standalone mode.
  B. You cannot use the Cisco UCS C-Series Rack-Mount Server Software Bundle with Cisco UCS C-Series Servers in standalone mode. You must download and use the Cisco UCS C-Series Rack-Mount Standalone Server Software package.
  C. First, you must integrate the standalone servers into the Cisco UCS system. Then, you can upgrade the firmware on all 15 servers from Cisco UCS Manager. Finally, you can revert the five servers to standalone mode.
  D. You can upgrade the firmware on all of the Cisco UCS-C Series Rack Servers by using the Cisco UCS C-Series Rack-Mount Standalone Server Software. You can upgrade the 10 servers that are integrated in a Cisco UCS cluster in Cisco UCS Manager, and you can upgrade the five standalone servers one by one.
  C. First, you must integrate the standalone servers into the Cisco UCS system. Then, you can upgrade the firmware on all 15 servers from Cisco UCS Manager. Finally, you can revert the five servers to standalone mode.

  ---

  https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/c-series_integration/ucsm3-1/b_C-Series-Integration_UCSM3-1/b_C-Series-Integration_UCSM3-1_chapter_0100.html

• Question 66:

  You are creating service profiles for a Cisco UCS system by using the service profile wizard. You discover that you forgot to create the UUID pool. What should you do?

  A. From the wizard, click Create UUID Suffix Pool.
  B. Pause the running wizard and then start a temporary wizard to create a profile with the same name and the missing UUID pool Resume the wizard, and then select the new UUID pool.
  C. Continue running the wizard. The service profile uses the burned-in UUID in the BIOS of the server.
  D. Stop the wizard, and then restart the wizard.
  A. From the wizard, click Create UUID Suffix Pool.

  ---



  https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/sw/gui/config/guide/2-0/b_UCSM_GUI_Configuration_Guide_2_0/b_UCSM_GUI_Configuration_Guide_2_0_chapter_011111.pdf



• Question 67:

  Which solution would you most likely use to achieve simultaneous traffic switching in a high- availability configuration in a Cisco UCS with blades?

  A. multiple UCS chassis
  B. two Cisco UCS Fabric Interconnects
  C. redundant UCS blades
  D. additional CPUs to provide additional virtual machines
  B. two Cisco UCS Fabric Interconnects

• Question 68:

  Refer to the exhibit, which script ing tool do you use to create the script?



  A. Python-API
  B. Bach
  C. NX-API
  D. Broadcom shell
  A. Python-API

• Question 69:

  Which statement is true about the default host firmware policy in Cisco UCS Manager?

  A. It contains the most recent firmware entries for all components on a chassis
  B. It requires a user acknowledgment to reboot and install the firmware package
  C. It is configured for an immediate reboot without user acknowledgment- in order to install the firmware package.
  D. It is created when you downgrade Cisco UCS Manager
  B. It requires a user acknowledgment to reboot and install the firmware package

• Question 70:

  You are disassociating a service profile from a server. You must associate the service profile to another server. Which two pokes in the service prevent the service profile can prevent the service profile from being associated to a different server? (Choose two.)

  A. server pool policy qualification
  B. LAN connectivity
  C. SAN connectivity
  D. power management
  E. maintenance
  A. server pool policy qualification
  E. maintenance
