Cisco 300-175 Online Practice Questions and Exam Preparation

Cisco 300-175 Online Questions & Answers

• Question 431:

  Which drive combination prevents you from provisioning RAID on Cisco UCS C-Series servers?

  A. SAS HDD and SATA HDD
  B. SAS SSD and SATA SSD
  C. SATA HDD and SATA SSD
  D. SAS HDD only
  E. SATA HDD only
  C. SATA HDD and SATA SSD

  ---

  https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/c/sw/raid/configuration/guide/RAID_GUIDE.pdf



• Question 432:

  Refer to the exhibit.



  A. The usNIC replaces any vNICs in the server.
  B. The kernel is bypassed when sending networking packets.
  C. Device-specific DMA translations are cached on the fabric interconnect only
  D. All network traffic goes to the OS kernel directly.
  D. All network traffic goes to the OS kernel directly.

• Question 433:

  Which three statements about what occurs when a Cisco UCS -Series Blade Server connects to the SAN across a fabric interconnect that is enabled in Fibre Channel NPV mode are true? (Choose three.)

  A. The server ports in F Port mode are pinned to the NP Ports.
  B. The E Ports are pinned to the E Ports on the fabric interconnect.
  C. Zoning is deployed on the fabric interconnect.
  D. The fabric interconnect is not assigned a Fibre Channel domain ID.
  E. Traffic that is received on the server ports in F Port mode from the server side is pinned to the NPIV-enabled uplink ports on the fabric interconnect.
  F. The fabric interconnect must have the Fibre Channel uplink port connected to the upstream switch F Port in NPIV mode that performs the Fibre Channel forwarder function.
  A. The server ports in F Port mode are pinned to the NP Ports.
  D. The fabric interconnect is not assigned a Fibre Channel domain ID.
  E. Traffic that is received on the server ports in F Port mode from the server side is pinned to the NPIV-enabled uplink ports on the fabric interconnect.

• Question 434:

  Refer to the exhibit.



  Interface Ethernet 1/30 connects to which type of switch?

  A. an FCoE switch that has NPV enabled
  B. a Fibre Channel switch that has NPV enabled
  C. a Fibre Channel switch that has NPIV enabled
  D. an FCoE switch that has NPIV enabled
  A. an FCoE switch that has NPV enabled

  ---

  Reference: https://www.cisco.com/c/en/us/td/docs/switches/datacenter/nexus5000/sw/san_switching/503_n2_1/b_Cisco_n5k_nxos_sanswitching_config_guide_rel503_n2_1/ b_Cisco_n5k_nxos_sanswitching_config_guide_rel503_n2_1_chapter_0110.html

• Question 435:

  You are using UCS version 2.4 or later and need to advertise the identity of a server by using LLDP instead of CDP. Which policy in the vNIC template accomplishes this goal?

  A. Ethernet adapter
  B. network control
  C. QoS
  D. LAN connectivity
  B. network control

• Question 436:

  HOTSPOT



  Hot Area:





• Question 437:

  Refer to the exhibit.



  Which action do you take to complete the iSCSI boot implementation?

  A. Add a DNS server to resolve the IQN name.
  B. Create an IP pool.
  C. Add a default gateway.
  D. Add in iSCSI target.
  D. Add in iSCSI target.

  ---

  Reference: https://www.cisco.com/c/en/us/support/docs/servers-unified-computing/ucs-manager/116003-iscsi-ucs-config-00.html

• Question 438:

  HOTSPOT



  Hot Area:





• Question 439:

  A network administrator has configured all required settings for the Smart Call Home feature in Cisco UCS. What must be done next?

  A. Open a TAC case to verify contract information and start the registration process.
  B. Generate a fault to initiate a message that will start the registration process.
  C. The system automatically starts the registration process and no further action is required.
  D. Send a system inventory message to start the registration process.
  D. Send a system inventory message to start the registration process.

• Question 440:

  Which description of an import operation in Cisco UCS Manager is true?

  A. You can perform an import while the system is up and running
  B. You can import only a configuration file that was exported from the same Cisco UCS Manager
  C. You can import a configuration from a higher release to a lower release
  D. You can schedule an import operation
  A. You can perform an import while the system is up and running

  ---

  https://www.cisco.com/en/US/docs/unified_computing/ucs/sw/gui/config/guide/141/UCSM_GUI_Configuration_Guide_141_chapter43.html#task_B89DEDCFCDE54E9C81E67C53FAC4DEC6 You can perform an import while the system is up

  and running.

  You can import any configuration file that was exported from Cisco UCS Manager. The file does not need to have been exported from the same Cisco UCS Manager.

  You cannot schedule an import operation.

  https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/ucs-manager/GUI-User-Guides/Admin-Management/3-1/b_Cisco_UCS_Admin_Mgmt_Guide_3_1/b_Cisco_UCS_Admin_Mgmt_Guide_3_1_chapter_01001.pdf You cannot import

  configuration from a higher release to a lower release.
