Cisco 300-175 Online Practice Questions and Exam Preparation

Cisco 300-175 Online Questions & Answers

• Question 101:

  Drag Drop

  Select and Place:





• Question 102:

  When you use a SAN boot which option do you configure?

  A. A UEFI boot target on the device that stores the operating system image
  B. A boot target LUN on the device that stores the operating system image
  C. An iSCSI boot profile
  D. A CIMC secure boot policy
  B. A boot target LUN on the device that stores the operating system image

• Question 103:

  Which two descriptions of user locales in a Cisco UCS domain are true? (Choose Two)

  A. A locale defines a default language and timezone in UCS Manager
  B. A locale can contain more than one organization
  C. A locale is same as an organization
  D. User assigned to a locale can manage an organization hierarchically within the locale
  E. A UCS user can be assigned to only one locale
  B. A locale can contain more than one organization
  D. User assigned to a locale can manage an organization hierarchically within the locale

• Question 104:

  Refer to the exhibit. Which port is used for communication between the server and the Cisco Integrated management Controller?



  A. port on the adapter card
  B. management Ethernet port
  C. LAN on the motherboard port
  D. fabric uplink port
  D. fabric uplink port

  ---

  Reference: https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/c/sw/gui/config/guide/1-2-1/b_Cisco_UCS_C-Series_Servers_Integrated_Management_Controller_Configuration_Guide_1_2_1/Cisco_UCS_CSeries_Servers_Integrated_Management_Controller_Configuration_Guide_1_2_1_chapter8.html

• Question 105:

  Which of the following supports more than two component-resident versions of firmware?

  A. mezzanine adapters
  B. I/O modules
  C. Cisco UCS fabric interconnects
  D. CIMCs
  C. Cisco UCS fabric interconnects

  ---

  https://www.cisco.com/c/en/us/support/docs/servers-unified-computing/ucs-manager/110511-ucs-fw- mgmt-00.html

  https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/ucs-manager/GUI-User-Guides/Firmware- Mgmt/3-1/b_UCSM_GUI_Firmware_Management_Guide_3_1/

  b_UCSM_GUI_Firmware_Management_Guide_3_1_chapter_011.html#task_C8E850B883D741BFBEF0F BBA409C6CB7

  The Fabric Interconnects are the only components that can store more than two versions.



• Question 106:

  Which NIC redundancy modes allow the LOMs to be discovered by the operating system or hypervisor?

  A. Dedicated mode
  B. Active/Active
  C. Active/Standby
  D. Cisco Card Mode
  A. Dedicated mode

• Question 107:

  Which two statements about the service profile configuration options in the Cisco UCS Manager GUI are true? (Choose two.)

  A. It can be generated automatically from the service profile template.
  B. It can be derived from the chassis discovery policy.
  C. It can be derived from the initial template or the updating template.
  D. it can be configured by cloning a virtual machine profile.
  E. It can be configured by using the chassis connectivity policy.
  A. It can be generated automatically from the service profile template.
  C. It can be derived from the initial template or the updating template.

  ---

  Ambiguous terminology. Service profile templates are mentioned twice. Cloning is valid, but what is a "virtual machine profile". Unknown why "chassis discovery policy" and "chassis connectivity policy" are thrown into the mix. Neither seems to apply here.

• Question 108:

  Which two protocols does the Cisco Integrated Management Controller support for managing standalone Cisco UCS C-Series servers? (Choose two.)

  A. SMASH CLP
  B. IPMIv2
  C. SoL
  D. SNMPv3
  E. Virtual KVM
  B. IPMIv2
  D. SNMPv3

  ---

  https://www.cisco.com/c/dam/en/us/products/collateral/servers-unified-computing/ucs-c-series-rack-servers/at-a-glance-c45-737177.pdf The IMC supports industry-standard protocols, including

  Redfish version 1.01,

  Intelligent Platform Monitoring Interface Version 2 (IPMI v2), and

  Simple Network Management Protocol versions 2 and 3 (SNMP v2 and v3).

  It also provides an open Extensible Markup Language (XML) API and a command-line interface (CLI).

• Question 109:

  Which PFC capacity mode is set for the interface?

  A. Default
  B. Genotiate
  C. Force-enable
  D. disable
  A. Default

• Question 110:

  Which two statements describe effects of enabling a Cisco UCS Fabric Interconnect in Ethernet end-host mode? (Choose two.)

  A. MAC address learning is disabled on the uplink ports of the fabric interconnect.
  B. MAC address learning is enabled on the server ports of the fabric interconnect.
  C. Server-to-server communication on the same VLAN is not performed locally Vie fabric interconnect, but requires an external switch.
  D. By default. unicast traffic received by the fabric uplink port to unknown destination MAC addresses is forwarded to all of the server ports.
  E. MAC address learning is disabled on all of the ports in Ethernet end-host mode.
  A. MAC address learning is disabled on the uplink ports of the fabric interconnect.
  B. MAC address learning is enabled on the server ports of the fabric interconnect.

  ---

  https://www.cisco.com/c/en/us/solutions/collateral/data-center-virtualization/unified-computing/whitepaper_c11-701962.html MAC address learning occurs only on the server ports; MAC address movement is fully supported.

  Server-to-server Layer 2 traffic is locally switched.

  In end-host mode, unknown unicast broadcasts are not flooded, switch mode is required.

  Additionally, because there is no MAC address learning on the uplink ports, the MAC address table can scale to support as many virtual machines as the number of entries available in the MAC address forwarding table.
