Cisco 300-101 Online Practice Questions and Exam Preparation

Cisco 300-101 Online Questions & Answers

• Question 521:

  Refer to exhibit.



  If the IGP in AS65000 is RIPv2, which networks are displayed when you enter show ip route on router R2?

  A. VLSM subnts in 10.0.0.0/16 and the major network 10.2.0.0/16 only
  B. VLSM subnets in 10.0.0.0/16 and the major network 10.2.0.0/16 only
  C. VLSM subnets in 10.0.0.0/16 only
  D. major networks 10.1.0.0/16 and 10.2.0.0/16 only
  E. VLSM subnets in 10.0.0.0/16 and the major networks 10.1.0.0/16 10.2.0.0/16
  D. major networks 10.1.0.0/16 and 10.2.0.0/16 only

• Question 522:

  A network administrator creates a static route that points directly to a multi-access interface, instead of the next-hop IP address. The administrator notices that Cisco Express Forwarding ARP requests are being sent to all destinations. Which issue might this configuration create?

  A. Low bandwidth usage
  B. High memory usage
  C. Cisco Express Forwarding routing loop
  D. High bandwidth usage
  E. IP route interference
  C. Cisco Express Forwarding routing loop

• Question 523:

  Which two statements about IP access-lists are true? (Choose two)

  A. They support wildcard masks to limit the address bits to which entries are applied.
  B. Extended access lists must include port numbers
  C. IP access list without at least one deny statement permit all traffic by default
  D. They end with an implicit permit
  E. Entries are applied to traffic in the order in which they appear
  A. They support wildcard masks to limit the address bits to which entries are applied.
  E. Entries are applied to traffic in the order in which they appear

• Question 524:

  Which statement about stateless and stateful IPv6 auto configuration are true?

  A. Both stateless and stateful autoconfiguration require additional setup
  B. Stateless autoconfiguration requires no additional setup, whereas stateful autoconfiguration requires additional setup
  C. Stateless autoconfiguration requires additional setup, whereas stateful autoconfiguration requires no additional setup
  D. Both stateless and stateful autoconfiguration require no additional setup
  B. Stateless autoconfiguration requires no additional setup, whereas stateful autoconfiguration requires additional setup

• Question 525:

  A network access serve using TACACAS+ for AAA operations receives an error message from the TACACS+ server. which action does the network access server take next ?

  A. It attempts to authenticate the user against RADIUS
  B. It restarts and attempts to reconnect to the TACACS+ server
  C. It rejects the user access request the
  D. It checks the method list for an additional AAA option
  D. It checks the method list for an additional AAA option

• Question 526:

  Congestion in the network. What is the effect on UDP?

  A. Sender will have to buffer more data..
  B. Receiver will have to buffer more data. Before sending packets to higher layers
  C. There will be latency
  D. PlaceHolder
  C. There will be latency

• Question 527:

  Router R1, a branch router, connects to the Internet using DSL. Some traffic flows through a GRE and IPsec tunnel, over the DSL connection, and into the core of an Enterprise network. The branch also allows local hosts to communicate directly with public sites in the Internet over this same DSL connection. Which of the following answers defines how the branch NAT config avoids performing NAT for the Enterprise directed traffic but does perform NAT for the Internet-directed traffic?

  A. By not enabling NAT on the IPsec tunnel interface
  B. By not enabling NAT on the GRE tunnel interface
  C. By configuring the NAT-referenced ACL to not permit the Enterprise traffic
  D. By asking the ISP to perform NAT in the cloud
  C. By configuring the NAT-referenced ACL to not permit the Enterprise traffic

• Question 528:

  How is authentication handled with OSPFv3?

  A. OSPFv3 for IPv6 authentication is supported by SHA-1 authentication.
  B. OSPFv3 for IPv6 authentication is supported by MD5 authentication
  C. OSPFv3 for IPv6 authentication is supported by IPv6 IPsec
  D. OSPFv3 for IPv6 authentication is supported by IPv4 IPsec
  C. OSPFv3 for IPv6 authentication is supported by IPv6 IPsec

• Question 529:

  Which two commands must you configure on a DMVPN hub to enable phase 3? (Choose two)

  A. ip nhrp interest
  B. ip nhrp redirect
  C. ip nhrp shortcut
  D. ip network-id
  E. ip nhrp map
  F. ip redirects
  B. ip nhrp redirect
  C. ip nhrp shortcut

• Question 530:

  You have been asked to evaluate how EIGRP is functioning in a customer network.



  What type of route filtering is occurring on R6?

  A. Distribute-list using an ACL
  B. Distribute-list using a prefix-list
  C. Distribute-list using a route-map
  D. An ACL using a distance of 255
  A. Distribute-list using an ACL
