NetApp NCIE-SAN ESeries NS0-505 Questions & Answers

• Question 1:

  What happens if you choose one disk that has a capacity of 300 GB and five others that have a capacity of 900 GB for a volume group? (Choose the best answer.)

  A. All disks are recognized as 900 GB in capacity.

  B. All disks are recognized as 300 GB in capacity.

  C. Each disk is recognized as its particular capacity.

  D. Mixing disk capacities is not supported in E-Series volume groups.

  Correct Answer: C

• Question 2:

  Which sequence describes the procedures for hot-adding an additional expansion enclosure to an existing E-Series configuration? (Choose the best answer.)

  A. Add one ESM cable between it and another available expansion port, disrupt the other SAS connection to add second cable, check SANtricity for addition of the new enclosure, power on expansion enclosure.

  B. Power on expansion enclosure, add one ESM cable between it and another available expansion port, check SANtricity for addition of the new enclosure, disrupt the other SAS connection to add second cable

  C. Add one ESM cable between it and another available expansion port, disrupt the other SAS connection to add second cable, power on expansion enclosure, check SANtricity for addition of the new enclosure.

  D. Power on expansion enclosure,add one ESM cable between it andanother available expansion port, disrupt the other SAS connection to add second cable, check SANtricity for addition of the new enclosure.

  Correct Answer: A

• Question 3:

  What mechanism governs control of the E-Series storage premium features? (Choose the best answer.)

  A. simple password system

  B. special USB flash drive that must be inserted into the controllers

  C. small toggle switches on the controller boards inside the system

  D. key file obtained from vendor and passed to system via SANtricity

  E. online database requiring the controllers to access the internet to activate features

  Correct Answer: D

• Question 4:

  Review the diagram.



  Is this cabling correct or incorrect, and why? (Choose the best answer.)

  A. The cabling is incorrect because the controllers are cabled from the host port.

  B. The cabling is incorrect because it usesthe top-down bottom-up cabling method.

  C. The cabling is correct because it follows the recommended E-Series cabling method.

  D. The cabling is incorrect because they have been daisy-chained.

  Correct Answer: D

• Question 5:

  What is the proper order to power-on E-Series arrays when a storage system has at least 2 trays? (Choose the best answer.)

  A. Power all expansion drive trays first, wait several minutes for the expansion drive trays to spin up, and then power on the controller drive tray

  B. Power on in any order, since the order does not matter

  C. Power up A-side power supplies first, then power up all B-side power supplies.

  D. Power on the controller drive tray first, then wait several minutes for the controller drive tray to spin up, and then power on all expansion drive trays

  Correct Answer: D

• Question 6:

  Synchronous mirroring requires what type of connection between storage systems? (Choose the best answer.)

  A. FC

  B. SAS

  C. iSCSI

  D. InfiniBand

  Correct Answer: A

• Question 7:

  What does the storage system use to preserve cache data in the event of a complete controller failure? (Choose the best answer.)

  A. Cache mirroring

  B. Flash read cache

  C. Pre-fetch caching

  D. Read caching

  E. Write caching

  Correct Answer: A

• Question 8:

  What is the `base' host connectivity provided by the E5500 Controller? (Choose the best answer.)

  A. IB

  B. SAS

  C. FC

  D. iSCSI

  E. None

  Correct Answer: C

• Question 9:

  Controller firmware package files start with which character(s)? (Choose the best answer.)

  A. SMIA

  B. CFW

  C. DLP

  D. RC

  E. N

  Correct Answer: A

• Question 10:

  An E-Series customer can find out when a specific volume was deleted by using the ______. (Choose the best answer.)

  A. Recovery Guru

  B. Major Event Log

  C. Online Help

  D. Storage Array Profile

  Correct Answer: A
