Huawei H31-161 Online Questions & Answers

• Question 31:

  As shown in the figure, RTA, RTB, RTC are interconnected over IS-IS, RTA,

  RTD, RTE, and RTC are interconnected over OSPF. Both IS-IS and OSPF use the default costs. RSVPTE is enabled on all routers and the interfaces between these routers. The Loopback0 interface of RTC is 192.168.0.3/32 and is

  advertised in both OSPF and ISIS areas. 192.168.0.3/32 is also the LSR ID of MPLS. Configurations of the MPLS and tunnel on RTA:

  #

  mpls lsr-id 192.168.0.1

  mpls

  mpls te

  mpls rsvp-te

  mpls te cspf interface Tunnel1/0/0 tunnel-protocol mpls te destination 192.168.0.3 mpls te tunnel-id 1 mpls te path metric-type igp mpls te igp metric absolute 1 mpls te commit #

  Which path will be selected when the tunnel becomes Up? What is the metric of this tunnel?

  A. RTA--RTB--RTC; 1
  B. RTA--RTD--RTE--RTC; 1
  C. RTA--RTB--RTC; 20
  D. RTA--RTD--RTE--RTC; 3
  B. RTA--RTD--RTE--RTC; 1

• Question 32:

  RTA is a leaf router that directly connects to host A through interface GigabitEthernet 1/0/0. The interface is configured as follows: interface GigabitEthernet1/0/0 undo shutdown ip address 192.168.4.2 255.255.255.0 pim sm igmp enable igmp version 3igmp ssm-mapping enable igmp static-group 232.1.1.1 Configurations in the IGMP view are as follows: igmp

  ssm-mapping 232.1.1.0 255.255.255.0 10.10.1.1 ssm-mapping 232.1.2.0 255.255.255.0 10.10.1.1 Host A sends an IGMPv2 Report message to group 232.1.2.2. Which entry can be displayed by the display igmp ssm-mapping group command?

  A. (10.10.1.1, 232.1.1.1)
  B. (10.10.1.1, 232.1.2.2)
  C. (10.10.1.1, 232.1.1.1) and (10.10.1.1, 232.1.2.2)
  D. No entry
  C. (10.10.1.1, 232.1.1.1) and (10.10.1.1, 232.1.2.2)

• Question 33:

  Which functions does the bearer network NMS mainly provide?

  A. Monitoring network traffic
  B. Switchover time of a device's active/standby system
  C. Monitoring device load(CPU and Memory)
  D. Packet loss delay
  A. Monitoring network traffic
  C. Monitoring device load(CPU and Memory)
  D. Packet loss delay

• Question 34:

  Which statement about the Hub s MPLS VPN networking is false?

  A. The Hub PE can receive the VPN_IPv4 routes advertised by all Spoke PEs.
  B. When an MP-IBGB neighbor relationship is established between two spoke PEs, the value of the Import VPN Target attribute of one Spoke PE can be the same as tat of the Export VPN Target attribute of the other Spoke PE.
  C. The Hub PE advertises the routes learned from one Spoke PE to other Spoke PEs. Therefore, Spoke sites can access other through the Hub site.
  D. All Spoke PEs can receive the VPN-IPv4 routes advertised by the Hub PE.
  B. When an MP-IBGB neighbor relationship is established between two spoke PEs, the value of the Import VPN Target attribute of one Spoke PE can be the same as tat of the Export VPN Target attribute of the other Spoke PE.

• Question 35:

  As shown in the figure, the mapping between links and administrative groups is as follows:

  0x0F for A -> B; 0xFF for B -> C; 0xF0 for A -> C; 0xC3 for B -> D; and 0x3C for C -> D.

  It is expected to configure a tunnel (affinity: 0x0C; mask: 0xFF) on node A to connect to RTD. Which path will be created along with the tunnel?

  A. A -> C -> D
  B. A -> B -> D
  C. A -> C -> B -> D
  D. A -> B -> C -> D
  E. No path will be created.
  D. A -> B -> C -> D

• Question 36:

  BGP often uses AS PATH to control inter-area routes. Which of the following regular expressions helps ensure that routes within AS 100 and neighboring ASs are received from only one EBGP neighbor?

  A. 100_([0-9]+)$
  B. ^100_([0-9]+)$
  C. ^100_([0-9]*)$
  D. ^100_([0-9]*)
  C. ^100_([0-9]*)$

• Question 37:

  Exhibit.



  RTA is an edge router of the MPLS backbone network. It provides the access services for users under Layer 2 switches and different users by subinterface . User A access VLAN 12 and has subscribed to the His, VoIP, and IPTV services. According to 802 1p priorities, the value indicates the His service, 1 indicates the VoIp service, and 4 indicates the IPTV service. RTA is configured on he access side as follows.



  What is the descending order of service priorities?

  A. VoIP, IPTV, HSI
  B. HSI, VoIP, IPTV
  C. IPTV, VoIP, HSI
  D. HSI, IPTV, VoIP
  D. HSI, IPTV, VoIP

• Question 38:

  In the access architecture of an IP bearer network, the OSPF protocol is enabled between two access routers, two firewalls (in transparent mode), and two Layer 3 switches. Softswitches work in active/standby mode. VRRP is enabled between the softswitches to provide a gateway. In normalcases, SW1 is the master router and SW2 is the backup router. Considering the reliability of the access network, how would you plan the cost value of each link in the OSPF area?

  A. a=b=c=d
  B. c>a+b+d
  C. d>a+b+c
  D. a=b>c=d
  C. d>a+b+c

• Question 39:

  The VRRP is enabled on the firewall dual-system Intranet users use NAT to access extranet FTP services Which of the following statements are true?

  A. The NAT cannot be used in easy IP mode.
  B. VRIDs of the VRRP must be bound with the NAT during NAT configuration in the outbound direction between domain.
  C. VRIDs of the VRRP do not need to be bound with the NAI during NAI configuration in the outbound direction between domains.
  D. The FTP Nat Alg function must be enabled on the firewall
  A. The NAT cannot be used in easy IP mode.
  B. VRIDs of the VRRP must be bound with the NAT during NAT configuration in the outbound direction between domain.
  D. The FTP Nat Alg function must be enabled on the firewall

• Question 40:

  For the Eudemon firewall, the nat-policy command is configured in which mode?

  A. System mode
  B. Interface mode
  C. Interzone mode
  D. Intrazone mode
  A. System mode
