Huawei H12-211 Online Practice Questions and Exam Preparation

Huawei H12-211 Online Questions & Answers

• Question 611:

  To establish multiple PPP point-to-point connections in the Ethernet network, a PPPoE server establishes connections with multiple PPPoE clients on one Ethernet port. How does PPPoE differentiate between each connection?

  A. MAC address.
  B. IP address and MAC address
  C. MAC address and ppp-id
  D. MAC address and session-id
  D. MAC address and session-id

• Question 612:

  In Huawei devices, which method can OSPF elect the router ID? (multiple choice)

  A. If a loopback interface is configured, select the largest IP address from the IP address of the loopback interface as the router ID.
  B. If the loopback interface is not configured, select the largest IP address as the router ID among the IP addresses of other interfaces.
  C. Huawei switch may use the largest VLANIF IP address as the router ID.
  D. Use the default 127.0.0.1
  E. Manually define an arbitrary legal router ID
  A. If a loopback interface is configured, select the largest IP address from the IP address of the loopback interface as the router ID.
  B. If the loopback interface is not configured, select the largest IP address as the router ID among the IP addresses of other interfaces.
  C. Huawei switch may use the largest VLANIF IP address as the router ID.
  E. Manually define an arbitrary legal router ID

• Question 613:

  Which of the following descriptions regarding eSight is not correct?

  A. eSight is used to monitor and manage enterprise networks.
  B. eSight supports only Huawei devices
  C. eSight supports WLAN management and monitoring of hotspot coverage.
  D. eSight supports the backup of configuration files and network traffic analysis.
  B. eSight supports only Huawei devices

• Question 614:

  Refer to the configuration output.



  Which of the following statements regarding the configuration output are correct? (Choose all that apply.)

  A. The PVID on interface GigabitEthernet0/0/1 is 10.
  B. The PVID on interface GigabitEthernet0/0/1 is 1.
  C. The PVID on interface GigabitEthernet0/0/2 is 10.
  D. The PVID on interface GigabitEthernet0/0/2 is 1.
  A. The PVID on interface GigabitEthernet0/0/1 is 10.
  D. The PVID on interface GigabitEthernet0/0/2 is 1.

• Question 615:

  Refer to the graphic. GE0/0/1 and GE0/0/2 on the switch are configured as hybrid interfaces. Which of the following statements are true? (Choose all that apply)



  A. The administrative department and the finance department cannot exchange visits because the VLANs belonging to the two departments are different.
  B. The data frame sent by the administrative department carries the tag in the switch as VLAN20.
  C. The data frame sent by the finance department carries the tag in the switch as VLAN20.
  D. The switch here can be a Layer 2 switch or a Layer 3 switch because communication does not need to go through a Layer 3 gateway.
  E. If both ports GE0/0/1 and GE0/0/2 of the switch are modified to be trunk ports, the two departments can communicate normally.
  B. The data frame sent by the administrative department carries the tag in the switch as VLAN20.
  C. The data frame sent by the finance department carries the tag in the switch as VLAN20.

• Question 616:

  In the following description of eSight, the error is ().

  A. eSight can be used to monitor and manage enterprise networks
  B. eSight can only manage Huawei network devices.
  C. eSight supports WLAN device management and hotspot coverage monitoring
  D. eSight supports configuration file backup and traffic analysis.
  B. eSight can only manage Huawei network devices.

• Question 617:

  When saving the router's configuration file, which storage medium is usually stored on it?

  A. SDRAM
  B. NVRAM
  C. Flash
  D. Boot ROM
  B. NVRAM

• Question 618:

  SNMP packets are encapsulated in TCP packets.

  A. True
  B. False
  B. False

• Question 619:

  Which of the following statements are true about STP BPDUs?

  A. During initialization, each switch enabled with STP proactively sends configuration BPDUs.
  B. BPDUs are encapsulated in Ethernet frames and the destination MAC address is a multicast MAC address.
  C. After STP is enabled on a port, the switch periodically sends TCN BPDUs through the designated port.
  D. STP has two types of packets: configuration BPDU and TCN BPDU.
  D. STP has two types of packets: configuration BPDU and TCN BPDU.

• Question 620:

  Which of the following fields are included in an MPLS header? (Choose three.)

  A. Label
  B. TTL
  C. EXP
  D. Tos
  A. Label
  B. TTL
  C. EXP
