Huawei H12-211 Online Practice Questions and Exam Preparation

Huawei H12-211 Online Questions & Answers

• Question 481:

  An administrator wishes to manage the router in the remote branch office, which method can be used?

  A. Telnet
  B. FTP
  C. Console Connection
  D. DHCP
  A. Telnet

• Question 482:

  The following description of the OSPF area is correct (). (multiple choice)

  A. Configure the ip address of the loopback interface of the router before configuring the OSPF area.
  B. The area number range is from 0.0.0.0 to 255.255.255.255
  C. The number of the backbone area cannot be 2
  D. All networks should be announced in zone 0
  B. The area number range is from 0.0.0.0 to 255.255.255.255
  C. The number of the backbone area cannot be 2

• Question 483:

  If the "user-interface maximum-vty 0" command is run on a router, which of the following statements is true?

  A. A maximum of 5 VTY users can access the router at the same time.
  B. No user can log in to the router through Telnet or SSH.
  C. A maximum of 15 VTY users can access the router at the same time.
  D. A maximum of 4 VTY users can access the router at the same time.
  B. No user can log in to the router through Telnet or SSH.

• Question 484:

  In RSTP mode, both alternate and backup ports cannot forward user traffic but can receive, process, and send BPDU.

  A. True
  B. False
  A. True

• Question 485:

  What is the total length of the VLAN frame defined by IEEE 802.1Q?

  A. 4
  B. 3
  C. 2
  D. 1
  A. 4

• Question 486:

  The topology and configuration are as shown in the figure. Then, an Eth Trunk - logical link can be established between the two switches. And LSW2 is active end.



  A. Correct
  B. Error
  B. Error

• Question 487:

  The Age time of the RIP route that is viewed by the command on the router is ().

  A. RIP packet update interval
  B. RIP route aging time
  C. RIP route suppression time
  D. RIP route switching time
  B. RIP route aging time

• Question 488:

  What are the advanced ACLs on Huawei devices that can be used to filter? (multiple choice)

  A. Network traffic based on a specific source address
  B. Application-specific traffic, such as QQ
  C. Network traffic based on a specific destination address
  D. Network traffic based on a specific port number
  E. Network traffic based on a specific username
  A. Network traffic based on a specific source address
  C. Network traffic based on a specific destination address
  D. Network traffic based on a specific port number

• Question 489:

  .[Huawei]user interface vty 0 14 [Huawei ui vty0 14]acl 2000 inbound - - [Huawei ui vty0 14]user privilege level 3 - - [Huawei ui vty0 14]authentication mode password - - - - Please configure the login password(maximum length 16): huawei The configuration of Vty is as shown above, and the user privilege level is set to level 3, which is also the highest level that can be set.

  A. Correct
  B. Error
  B. Error

• Question 490:

  Which of the following parameters must be specified when configuring static mapping for Frame Relay network? (Choose two)

  A. Local DLCI
  B. Remote DLCI
  C. Local network layer protocol address
  D. Remote network layer protocol address
  A. Local DLCI
  D. Remote network layer protocol address
