Huawei H12-211 Online Practice Questions and Exam Preparation

Huawei H12-211 Online Questions & Answers

• Question 231:

  The network topology is as shown in the figure. The cost of all links in the network is the default value. When the RTA forwards the packet to the RTE, about routing. The correct description is () (multiple choice).



  A. If the routers in the network are running OSPF, the RTA will use the S1/0/0 interface to forward data to the RTE.
  B. If the routers in the network are running RIPv2, the RTA will use the S1/0/0 interface to forward data to the RTE.
  C. If the routers in the network are running OSPF, the RTA will use the E0/0/1 interface to forward data to the RTE.
  D. If the routers in the network are running RIPv2, the RTA will use the S2/0/0 interface to forward data to the RTE.
  B. If the routers in the network are running RIPv2, the RTA will use the S1/0/0 interface to forward data to the RTE.
  C. If the routers in the network are running OSPF, the RTA will use the E0/0/1 interface to forward data to the RTE.

• Question 232:

  Which of the following encapsulation modes are supported by IPsec VPN? (Choose two.)

  A. Routing mode
  B. Tunnel mode
  C. Transport mode
  D. Switching mode
  B. Tunnel mode
  C. Transport mode

• Question 233:

  While inspecting packets in the network, a network administrator discovers a frame with the destination MAC address of 01-00-5E-A0-B1-C3. What can the administrator determine from this?

  A. The MAC address is a unicast address.
  B. The MAC address is a broadcast address
  C. The MAC address is a multicast address.
  D. The MAC address is incorrect
  C. The MAC address is a multicast address.

• Question 234:

  Network administrators use ping to check network connectivity. Which of the following protocols might be used in the process? (multiple choice)

  A. ICMP
  B. TCP
  C. ARP
  D. UDP
  A. ICMP
  C. ARP

• Question 235:

  Interface G0/0/1 on RTA contains a MAC address of 00e0-fc03-aa73 and is configured with the IPv6 address 2001::2E0:FCFF:FE03:AA73. Which method is most likely to have been used to configure the interface IPv6 address?

  A. DHCPv6
  B. Auto-link
  C. ARP
  D. EUI-64
  D. EUI-64

• Question 236:

  Which of the following statements regarding the router ID in OSPF are incorrect? (Choose three)

  A. The router IDs of OSPF routers in the same area must be the same, but can be different in different areas.
  B. The router ID must be the IP address of an OSPF router interface.
  C. The router ID must be configured manually.
  D. A router running OSPF must have a router ID for it to operate properly.
  A. The router IDs of OSPF routers in the same area must be the same, but can be different in different areas.
  B. The router ID must be the IP address of an OSPF router interface.
  C. The router ID must be configured manually.

• Question 237:

  How many domains can be configured on a Huawei router?

  A. 30
  B. 31
  C. 32
  D. 33
  A. 30

• Question 238:

  [RTA]acl 2002

  [RTA-acl-basic-2002]rule deny source 172.16.1.1 0.0.0.0 [RTA-acl-basic-2002]rule deny source 172.16.0.0 0.255.0.0 Which of the following entries will be matched on the router PTA using the ACL matching routing entries shown above?

  (multiple choice)

  A. 172.16.1.1/32
  B. 172.16.1.0/24
  C. 192.17.0.0/24
  D. 172.18.0.0/16
  A. 172.16.1.1/32
  D. 172.18.0.0/16

• Question 239:

  The administrator found that the above message popped up on the device. The correct statement about this information is ().

  Warning:Auto-Config is working.Before configuring the device,stop Auto-Config.If you perform Configurations when Auto-Config is running,the DHCP,routing,DNS,and VTY configurations will be

  lost.Do

  You want to stop Auto-config?[Y/N]:

  A. If you need to enable automatic configuration, the administrator needs to choose Y
  B. If you do not need to enable automatic configuration, the administrator needs to select N
  C. When the device is first started, the auto configuration function is enabled.
  D. When the device is first started, the auto configuration function is disabled.
  C. When the device is first started, the auto configuration function is enabled.

• Question 240:

  A RIP router receives the routing update information from its neighbor. Which of the following statements regarding routing update are correct? (Choose three)

  A. The received route that is not in the routing table will be added only when its hop count value is less than 16.
  B. The received route that already exists in the routing table will be updated only when the next hop is the router's neighbor and the cost value is smaller.
  C. The received route that already exists in the routing table will be updated only when the next hop is not the router's neighbor and the cost value is smaller.
  D. The received route that already exists in the routing table will be updated only when the next hop is the router's neighbor and the cost value has been changed.
  A. The received route that is not in the routing table will be added only when its hop count value is less than 16.
  C. The received route that already exists in the routing table will be updated only when the next hop is not the router's neighbor and the cost value is smaller.
  D. The received route that already exists in the routing table will be updated only when the next hop is the router's neighbor and the cost value has been changed.
