When bi-directional network address translation (NAT) is used between the Steelhead appliances, optimization is not working. A workaround to this is: (Select 2)
A. Use fixed-target rules on the server-side Steelhead appliance
B. Enable server-side out-of-the-path on the server-side Steelhead appliance
C. Enable destination oobtransparency
D. Enable Full Transparency
E. There is no work around for a double NAT'd situation
Assuming auto-discovery is used, WCCP redirect-in statements would normally be placed on which router interfaces? (Select 2)
A. The interface that the Steelhead appliances are connected to
B. The interface on the WAN side
C. The interface on the LAN side
D. The loopback interface
When deploying policy-based routing for multiple Steelhead appliances in a cluster, the router should be configured to: (Select 2)
A. Set IP next-hop address to the virtual IP address of the Steelhead appliance cluster
B. Set IP next-hop addresses for each Steelhead appliance
C. Check the state level information on each Steelhead appliance via SLA or CDP
D. Auto-detect the Steelhead appliance clustering protocol
E. Check the state level information on the virtual IP address of the Steelhead appliance cluster
You choose to deploy a Steelhead appliance logically in-path using policy-based routing (PBR) as the traffic redirection method. Additionally, you want to mark the Type of Service (ToS) value for active FTP as AF21 using route-maps. Which route-map specified Type of Service (ToS) value is correct? (Hint: Use the calculator)
A. EF21
B. 0x48
C. 0x58
D. 0xb8
E. 18
What is the primary purpose of Connection Forwarding in WCCP deployments with multiple Steelhead appliances in a single cluster? (Select 2)
A. For handling Removal Query process
B. For handling Redirect Assignment process
C. For handling Here-I-Am packets process
D. For handling the I-See-U packets process
E. Connection Forwarding is not recommend in WCCP deployments
A customer wants to mark the IP precedence value for a passive FTP data connection as flash (flash = CS3). Which of the following are true? (Hint: Use the calculator)
A. Specify qos dscp rule at client-side Steelhead appliance with a dest-port of 20 and with a DSCP value of 23
B. Specify qos dscp rule at client-side Steelhead appliance with a dest-port of 20 and with a DSCP value of 24
C. Specify qos dscp rule at server-side Steelhead appliance with a dest-port of 20 and with a DSCP value of 26
D. Specify qos dscp rule at client-side Steelhead appliance with a dest-port of 20 and with a DSCP value of 26
E. Specify qos dscp rule at server-side Steelhead appliance with a dest-port of 20 and with a DSCP value of 24
What is the priority bit order for WCCP MASK?
A. Source port, source IP, destination port, destination IP
B. Destination port, source port, destination IP, source IP
C. Source IP, destination port, destination IP, source port
D. Source port, destination port, source IP, destination IP
E. There is no priority order. It is weighted through bit assignments.
WCCP uses bits to create and distribute buckets. Using HASH assignment, what are the maximum number of bits used?
A. 4
B. 7
C. 8
D. 32
E. 256
WCCP uses bits to create and distribute buckets. Using MASK assignment, what is the maximum number of bits used?
B. 7
C. 8
D. 32
E. 256
The WCCP protocol has a methodology of load balancing with two or more Steelhead appliances. What is the maximum number of buckets used for the HASH assignment?
A. 8
B. 32
C. 64
D. 128
E. 256
