Exam Details

  • Exam Code
    :6103
  • Exam Name
    :Avaya ERS 8000 and Avaya VSP 9000 Implementation
  • Certification
    :Avaya Certifications
  • Vendor
    :Avaya
  • Total Questions
    :60 Q&As
  • Last Updated
    :Dec 01, 2024

Avaya Avaya Certifications 6103 Questions & Answers

  • Question 41:

    Refer to the exhibit.

    The EDM is used to see the configured routes within your system.

    Based on the information in the exhibit, what is the problem with the route to the 10.0.0.0 network?

    A. The route has a metric of 1.

    B. The route is inactive.

    C. The route is not configured.

    D. The route has no next hop.

  • Question 42:

    The attempt to manage an Ethernet Routing Switch (ERS) 8000 using a VRRP address was unsuccessful. What is causing this problem?

    A. The virtual router identifier is 0.

    B. The datacenter interface is set as a critical IP interface.

    C. A real IP address is required for management access not a VRRP address.

    D. The incorrect MAC offset is configured for the VRRP address.

  • Question 43:

    After experiencing issues with XFPs, the show sys pluggable-optical-modules info CLI command is used to find the switch that does not recognize the XFPs.

    What is another method that can be used to view the XFP compatibility?

    A. Check for port alarms.

    B. Show the DWDM-XFP {detail}.

    C. Ensure that the config sys is set for pluggable-optical-module info.

    D. Select Edit, Port, General, DDI/SFP from the Enterprise Device Manager.

  • Question 44:

    The Key Health Indicators (KHI) feature of Avaya Virtual Services Platform 9000 provides a subset of health information that allows for quick assessment of the overall operational state of the device. The show khi forwarding commands are the way to view this health information.

    What kinds of slots are the show khi forwarding commands valid for?

    A. CP slots

    B. IO slots

    C. SF slots

    D. GbE slots

  • Question 45:

    On an ERS 8000 system that is configured for use with IPv6, which command would show whether or not the VRRP instance is configured correctly on a particular interface?

    A. show ipv6 interface all

    B. show ipv6 interface vrrp

    C. show system vrrp interface

    D. show ipv6 vrrp address

  • Question 46:

    Flight Recorder can be used on the Virtual Services Platform (VSP) 9000 to help Identify problems. When can a Flight Recorder snapshot be taken?

    A. when the VSP has to be booted into the diagnostic mode

    B. only after a warning message is logged

    C. anytime

    D. every hour

  • Question 47:

    To confirm that RSMLT will work on a set of VLANs, which network design aspect should be considered?

    A. RSMLT is enabled on a SMLT VLAN.

    B. RSMLT is enabled on the VLAN group.

    C. Router 1 always owns the network.

    D. RSMLT is enabled on all SMLT VLANs.

  • Question 48:

    A port on the Virtual Services Platform (VSP) 9000 is down because of a link_flap condition as shown in the following output:

    VSP-9012:1#show interfaces gigabitEthernet state 10/8 ================================================================ Port State ================================================================ PORT NUM ADMINSTATUS PORTSTATE REASON DATE -------------------------------------------------------------------------------------------------- 10/8 up down LINK-FLAP 10/28/10 00:22:50

    What is the most likely cause?

    A. The spanning tree protocol has detected a loop and placed the port in a blocked state.

    B. There is a physical problem, such as a cable problem.

    C. One side of the connection is configured for auto-negotiation and the other side is a fixed speed.

    D. The port is receiving a large number of destination unknown broadcast packets.

  • Question 49:

    On the VSP 9000 and ERS 8000, the Switch Fabric (SF) modules are installed to intelligently switch or route traffic coming into the chassis.

    What determines the SF module function on the VSP 9000?

    A. campus size

    B. module type

    C. software version

    D. slot location

  • Question 50:

    A technician is implementing a new network that contains eight Ethernet Routing Switch (ERS) 8000 switches, and also uses advanced features. One of the eight switches will run Shortest Path Bridging.

    Which two licenses are needed in this situation? (Choose two.)

    A. one advanced feature license for seven ERS 8000 chassis

    B. one Premier license using for the one needing SPB support

    C. one advanced feature license for the network

    D. one premier feature license for the network

    E. one site license per ERS 8600
