Cisco 400-051 Online Practice Questions and Exam Preparation

Cisco 400-051 Online Questions & Answers

• Question 411:

  Which statement about using the Answer File Generator to load a Cisco Unified Communications virtual machine is true?

  A. You must copy the output text to a file named platformConfig.txt.
  B. Each host should be copied to its own configuration file.
  C. The answer file can be used only when performing the new identity process to load the Cisco Unified Communications virtual machines.
  D. The configuration file should be placed inside an ISO file and mounted on the virtual machine.
  B. Each host should be copied to its own configuration file.

  ---

  References: http://www.cisco.com/c/en/us/td/docs/voice_ip_comm/cucm/install/9_0_1/CUCM_BK_I87B437D_00_installing-cucm-90/CUCM_BK_I87B437D_00_installing-cucm-90_chapter_0100.html#CUP0_TK_G0262E75_00

• Question 412:

  Which element was added to H.225 messages to enable Fast Connect in H.323 version 2?

  A. fastStart
  B. fastConnect
  C. H.245 PDU
  D. User-User Information
  E. Connection Information
  A. fastStart

  ---

  Fast start allows for H323 media connections to be started at the beginning of a call. This is helpful for ringback scenarios, and also reduces the amount of time calls take to establish media. H245 is still negotiated later, but the actual media can be done earlier through H225 messages.

• Question 413:

  In addition to SIP triggers, which two trigger types can invoke applications on Cisco Unity Express? (Choose two.)

  A. HTTP
  B. IMAP
  C. VoiceView
  D. JTAPI
  E. Cisco Unified CM telephony
  F. voice mail
  A. HTTP
  D. JTAPI

  ---

  Triggers are incoming events that invoke application which in turn starts executing the script associated with that application. For example, the incoming event can be an incoming call or an incoming HTTP request. After you have created and

  configured your application, you need to create a trigger on the Cisco Unity Express module to point to that application.

  Cisco Unity Express supports three types of triggers:

  ?SIP triggers -- Use this type of trigger to invoke applications in Cisco Unified CME and Cisco SRST mode. This type of trigger is identified by the phonenumber which is dialed to invoke the desired application. ?JTAPI triggers -- Use this type

  of trigger to invoke applications in Cisco Unified Communications Manager mode. This type of trigger is identified by the phonenumber which is dialed to invoke the desired application. ?HTTP triggers -- Use this type of trigger to invoke

  applications using an incoming HTTP request. Such a trigger is identified by the URL suffix of the incoming HTTP request. This type of trigger can only be used if an IVR license has been purchased and installed on the system.

  References: http://www.cisco.com/c/en/us/td/docs/voice_ip_comm/unity_exp/administrator/AA_and_VM/guide/vmadmin_book/syscmp.html#wp1126512

• Question 414:

  Which Location Bandwidth Manager (LBM) configuration will Cisco CallManager service use, if all present, for Enhanced Location CAC is a Unified CM cluster?

  A. LBM Group designation
  B. "Call Treatment when no path is available" Service Parameter configuration
  C. "Call Treatment when no LBM available" Service Parameter configuration
  D. Local co-resident LBM
  E. Hub_None Location
  C. "Call Treatment when no LBM available" Service Parameter configuration

• Question 415:



  Assume the IP address of Cisco Unity Express is 10.1.1.1. Which URL provides Cisco Unity Express end users with a GUI interface to access and manage their messages and mailbox settings?

  A. http://10.1.1.1/Web/Common/Login.do
  B. http://10.1.1.1/ciscopca
  C. http://10.1.1.1/user
  D. http://10.1.1.1/inbox
  E. http://10.1.1.1/
  C. http://10.1.1.1/user

  ---

  For user access cisco unity has predefined url and it is http://10.1.1.1/user

• Question 416:

  Which Cisco Unified Contact Center Express data store contains CSQ information?

  A. configuration data store
  B. repository data store
  C. agent data store
  D. historical data store
  E. script data store
  A. configuration data store

  ---

  The Database component is required for any Unified CCX deployment and manages access to the database. The Unified CCX Database contains four data stores. They are as follows: Configuration data store Repository data store Agent data store Historical data store

  The configuration data store contains Unified CCX configuration information such as resources (agents), skills, resource groups, teams, and CSQ information. The repository data store contains user prompts, grammars, and documents. The agent data store contains agent logs, statistics, and pointers to the recording files. The historical data store contains Contact Call Detail Records (CCDRs).

  References: http://www.cisco.com/c/en/us/td/docs/voice_ip_comm/cust_contact/contact_center/crs/express_9_02/design/guide/UCCX_BK_C39FDB35_00_cisco-unified-contact-center-express/UCCX_BK_C39FDB35_00_cisco-unifiedcontact-center-express_chapter_010.html

• Question 417:

  Refer to the exhibit.



  All displayed devices are registered to the same Cisco Unified Communications Manager server and the phones are engaged in an active call. Assume that the provided configurations exist at the phone line level and multicast MOH is disabled cluster wide.

  Which description of what happens when the user of IP phone B presses the Transfer soft key is true?

  A. IP phone A user hears audio source 3 from MOH server A.
  B. IP phone A user hears audio source 4 from MOH server B.
  C. IP phone A user hears audio source 3 from MOH server B.
  D. IP phone A user hears tone on-hold beep tones.
  E. IP phone A user hears no on-hold music or beep tones.
  E. IP phone A user hears no on-hold music or beep tones.

• Question 418:

  Drag and Drop

  Drag the configuration steps on the left to the correct order for configuring digits transformation for URI dialing according to CISCO best practices on the right. Not all options will be used.

  Select and Place:





• Question 419:

  A Cisco collaboration engineer is troubleshooting unexpected SIP call disconnect. Which three responses corresponding to the 5xx range (Choose three.)

  A. Forbidden
  B. Unauthorized
  C. Request timeout
  D. Service unavailable
  E. Bad gateway
  F. Internal server error
  D. Service unavailable
  E. Bad gateway
  F. Internal server error

• Question 420:

  Which three are Border device types in Cisco Unified Communications Manager logical partitioning policies? (Choose three.)

  A. MGCP gateway with FXO ports
  B. media termination points
  C. SIP IP phones
  D. MGCP gateway with Q.SIG PRI
  E. SIP trunk to Cisco Unity Connection
  F. intercluster trunk using H.225
  A. MGCP gateway with FXO ports
  E. SIP trunk to Cisco Unity Connection
  F. intercluster trunk using H.225
