Cisco 300-175 Online Practice Questions and Exam Preparation

Cisco 300-175 Online Questions & Answers

• Question 271:

  Which options are valid port types when configuring fixed 10-Gb LAN interfaces on the Cisco UCS 6200 Series Fabric Interconnects? (Choose three.)

  A. monitoring port
  B. server port
  C. uplink Ethernet port
  D. FEX port
  E. Fibre Channel storage port
  A. monitoring port
  B. server port
  C. uplink Ethernet port

• Question 272:

  Which of the following is true concerning the Global Chassis Discovery policy configuration on the Cisco Unified Computing System Manager when using Cisco Unified Computing System 22XX I/O modules with Cisco UCS 62XX Fabric Interconnects?

  A. The link grouping preference should be set to discrete mode when the number of northbound links are not a power of 2.
  B. Set the action policy-count higher than the actual number of uplinks; otherwise, the Cisco Unified Computing System servers will not be discovered.
  C. For Cisco Unified Computing System implementations that mix I/O modules with different numbers of links, it is best to manually reacknowledge the chassis in order to use all available links.
  D. Automatic reacknowledgement due to chassis discovery is never disruptive.
  C. For Cisco Unified Computing System implementations that mix I/O modules with different numbers of links, it is best to manually reacknowledge the chassis in order to use all available links.

• Question 273:

  Which two tasks enable jumbo frames on a Cisco UCS system? (Choose two.)

  A. In the LAN cloud on Cisco UCS Manager, configure MTU 9000 in the uplink interfaces.
  B. In the LAN cloud on Cisco UCS Manager, enable jumbo frames in Fabric A and Fabric B.
  C. In the LAN cloud on Cisco UCS Manager, configure MTU 9000 in the VLAN.
  D. In the LAN cloud on Cisco UCS Manager, define a QoS system class with MTU 9000.
  E. In the service profile, configure MTU 9000 in the vNIC.
  F. In the service profile, configure MTU 9000 in the virtual machine.
  G. In the service profile, configure MTU 9000 in the uplink interfaces.
  D. In the LAN cloud on Cisco UCS Manager, define a QoS system class with MTU 9000.
  E. In the service profile, configure MTU 9000 in the vNIC.

• Question 274:

  You must upgrade a Cisco UCS -Series Server. Where must the Cisco UCS bundle image be located before you can begin the upgrade?

  A. the Cisco Integrated Management Controller memory of the server
  B. a USB drive connected to a Cisco UCS Fabric Interconnect
  C. a TFTP server accessible to the Cisco UCS Fabric Interconnect
  D. the flash file system of the fabric interconnect
  C. a TFTP server accessible to the Cisco UCS Fabric Interconnect

  ---

  http://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/sw/firmware-mgmt/gui/2-1/b_GUI_Firmware_Management_21/downloading_and_managing_firmware_in_cisco_ucs_man ager.html#concept_1923688E7A2E46239DCAE363E4A3DE81

• Question 275:

  HOTSPOT



  Hot Area:





• Question 276:

  Which items are hot-swappable on a UCS C-Series Server? (Choose-two)

  A. Internal Cooling Fans
  B. Power Supplies
  C. PCIe Card
  D. Mezzanine Card
  E. Riser Card
  A. Internal Cooling Fans
  B. Power Supplies

  ---

  https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/c/hw/C240M4/install/C240M4/replace.html

• Question 277:

  Which three options are valid system classes for QoS in a Cisco UCS blade system? (Choose three.)

  A. platinum
  B. silver
  C. best effort
  D. voice
  E. high-priority
  F. FCoE
  G. drop eligible
  A. platinum
  B. silver
  C. best effort

• Question 278:

  Which protocol is not supported for Cisco UCS backups and imports?

  A. FTP
  B. TFTP
  C. SCP
  D. SFTP
  E. HTTP
  E. HTTP

• Question 279:

  Refer to the exhibit. Which type of FCoE topology is displayed?



  A. direct-attach
  B. remote-attach
  C. vPC
  D. FCoE with Cisco 2232 Fabric Extenders
  B. remote-attach

  ---

  https://www.cisco.com/c/en/us/products/collateral/switches/nexus-7000-series-switches/white_paper_c11-560403.html

• Question 280:

  You plan to use AAA security services for a Cisco UCS Fabric Interconnect. Which two authentication providers can you use? (Choose two.)

  A. Kerberos
  B. RADIUS
  C. NTLM
  D. Diameter
  E. LDAP
  B. RADIUS
  E. LDAP
