Cisco 200-105 Online Practice Questions and Exam Preparation

Cisco 200-105 Online Questions & Answers

• Question 651:

  Which command can you enter to assign an interface to the default VLAN?

  A. Switch(config-if)# switchport access vlan 1
  B. Switch(config-if)# switchport trunk native vlan 1
  C. Switch(config-if)# vlan 1
  D. Switch(config)# int vlan 1
  A. Switch(config-if)# switchport access vlan 1

• Question 652:

  Refer to the exhibit. Which problem is indicated by this error?



  A. Two or more networks have been defined in the OSPF process
  B. The same EIGRP process has already been defined on another router
  C. Two or more devices on the network have the same router ID
  D. Two or more interfaces have been assigned to the same network
  C. Two or more devices on the network have the same router ID

• Question 653:

  Which statement about the IP SLAs ICMP Echo operation is true?

  A. The frequency of the operation is specified in milliseconds.
  B. It is used to identify the best source interface from which to send traffic to a destination.
  C. It is configured in enable mode.
  D. It is used to determine the one-way delay between devices.
  B. It is used to identify the best source interface from which to send traffic to a destination.

  ---

  This module describes how to configure an IP Service Level Agreements (SLAs) Internet Control Message Protocol (ICMP) Echo operation to monitor end-to-end response time between a Cisco router and devices using IPv4 or IPv6. ICMP Echo is useful for troubleshooting network connectivity issues. This module also demonstrates how the results of the ICMP Echo operation can be displayed and analyzed to determine how the network IP connections are performing. ICMP Echo Operation The ICMP Echo operation measures end-to-end response time between a Cisco router and any devices using IP. Response time is computed by measuring the time taken between sending an ICMP Echo request message to the destination and receiving an ICMP Echo reply. In the figure below ping is used by the ICMP Echo operation to measure the response time between the source IP SLAs device and the destination IP device. Many customers use IP SLAs ICMP-based operations, in-house ping testing, or ping-based dedicated probes for response time measurements.



  The IP SLAs ICMP Echo operation conforms to the same IETF specifications for ICMP ping testing and the two methods result in the same response times. Configuring a Basic ICMP Echo Operation on the Source Device SUMMARY STEPS

  1.

  enable

  2.

  configure terminal

  3.

  ip sla operation-number

  4.

  icmp-echo {destination-ip-address | destination-hostname} [source-ip {ip-address | hostname} | source-interface interface-name]

  5.

  frequency seconds

  6.

  end

• Question 654:

  What is the status of port-channel if LACP is misconfigured?

  A. Forwarding
  B. Enabled
  C. Disabled
  D. Errdisabled
  C. Disabled

• Question 655:

  Workstation A has been assigned an IP address of 192.0.2.24/28. Workstation B has been assigned an IP address of 192.0.2.100/28. The two workstations are connected with a straight-through cable. Attempts to ping between the hosts are unsuccessful.

  What are two things that could be attempted that would allow communications between the hosts? (Choose two.)

  A. Replace the straight-through cable with a crossover cable.
  B. Change the subnet mask of the hosts to /25.
  C. Change the subnet mask of the hosts to /26.
  D. Change the address of Workstation A to 192.0.2.15.
  E. Change the address of Workstation B to 192.0.2.111.
  A. Replace the straight-through cable with a crossover cable.
  B. Change the subnet mask of the hosts to /25.

• Question 656:

  What is the alternative notation for the IPv6 address B514:82C3:0000:0000:0029:EC7A:0000:EC72?

  A. B514 : 82C3 : 0029 : EC7A : EC72
  B. B514 : 82C3 :: 0029 : EC7A : EC72
  C. B514 : 82C3 : 0029 :: EC7A : 0000 : EC72
  D. B514 : 82C3 :: 0029 : EC7A : 0 : EC72
  D. B514 : 82C3 :: 0029 : EC7A : 0 : EC72

• Question 657:

  What is the default encapsulation type for Cisco WAN serial interfaces?

  A. Frame Relay
  B. HDLC
  C. PPP
  D. SDLC
  B. HDLC

• Question 658:

  What SNMP message alerts the manager to a condition on the network?

  A. response
  B. get
  C. trap
  D. capture
  C. trap

• Question 659:

  After you configure a new router to connect to a host through the GigabitEthernet0/0 port of the router, you log in to the router and observe that the new link is down.

  Which action corrects the problem?

  A. Use a crossover cable between the host and R1.
  B. Use a straight through cable between the host and R1.
  C. Configure the host to use R1 as the default gateway.
  D. Use a rollover cable between the host and R1.
  A. Use a crossover cable between the host and R1.

• Question 660:

  Which command do you enter to determine whether LACP is in use on a device?

  A. Show etherchannel summary
  B. Show port-channel summary
  C. Show etherchannel load-balance
  D. Show ip protocols
  B. Show port-channel summary
