Riverbed 199-01 Online Practice Questions and Exam Preparation

Riverbed 199-01 Online Questions & Answers

• Question 361:

  Is any user data sent across the out-of-band (OOB) connection of a Steelhead appliance?

  A. No data is sent across this connection
  B. Yes, only after 60 seconds
  C. Yes, when the peer Steelhead appliance requests information
  D. Yes, when the connection is setup
  E. Yes, every 30 seconds
  F. Yes, every 30 minutes
  A. No data is sent across this connection

• Question 362:

  Refer to the exhibit.



  Corp-A and Corp-B have overlapping address space and therefore the network administrator implemented NAT to overcome this. Users from Corp-A NAT to 172.16.1.0/24 and users from Corp-B NAT to 172.16.2.0/24. Users in Corp-A use the destination address of 172.16.2.0/24 to access the resources in Corp-B. The servers in Corp-B use the client IP for authentication. You deploy the Steelhead appliance using the default WAN visibility mode but noticed all the connections are passed-through. What is the likely problem?

  A. When the Steelhead appliance in Corp-B opens the outer connection, it is using the source IP of 172.16.2.x instead of 192.168.1.x
  B. On the Steelhead appliance in Corp-B, there is a missing static route for the 192.168.1.0/25 network
  C. On the Steelhead appliance in Corp-A, there is a missing static route for the 172.16.2.0/24 network
  D. When the Steelhead appliance in Corp-B opens the outer connection, it is using the source IP of 192.168.1.x instead of 172.16.1.x
  E. None of the above
  D. When the Steelhead appliance in Corp-B opens the outer connection, it is using the source IP of 192.168.1.x instead of 172.16.1.x

• Question 363:

  What is the priority bit order for WCCP MASK?

  A. Source port, source IP, destination port, destination IP
  B. Destination port, source port, destination IP, source IP
  C. Source IP, destination port, destination IP, source port
  D. Source port, destination port, source IP, destination IP
  E. There is no priority order. It is weighted through bit assignments.
  D. Source port, destination port, source IP, destination IP

• Question 364:

  WCCP uses bits to create and distribute buckets. Using HASH assignment, what are the maximum number of bits used?

  A. 4
  B. 7
  C. 8
  D. 32
  E. 256
  C. 8

• Question 365:

  True or False? To be able to use Active Directory assignments, the SteelCentral Controller for SteelHead Mobile must be joined to the domain.

  A. True
  B. False
  A. True

• Question 366:

  While looking at the Current Connections page on a client-side Steelhead, you noticed that there is more CIFS traffic on the WAN than on the LAN for some connections. What may be the problem? 1) The source data is compressed or encrypted 2) File server not located on the same subnet as the server-side Steelhead 3) The Steelhead is counting both CIFS optimized and unoptimized traffic 4) CIFS read-ahead 5) CIFS write-behind

  A. 1, 4
  B. 4, 5
  C. 1, 2, 3
  D. 1, 2, 5
  E. 3, 5
  A. 1, 4

• Question 367:

  You plan to downgrade a SteelHead from RiOS v9.0.1 (Apr 17 2015) to 8.6.3 (Aug 7 2015). The appliance was previously running v8.6.3 but was factory reset after the upgrade. Will this be successful?

  A. No, there is no longer a configuration file for v8.6.3
  B. Yes, the current v9.0.1 configuration file will be migrated
  C. Yes, the old configuration file from v8.6.3 will be loaded
  D. No, it is not possible to downgrade RiOS
  A. No, there is no longer a configuration file for v8.6.3

• Question 368:

  What is configured in an Endpoint policy? (Choose the best answer)

  A. Redundant Steelhead Mobile Controllers
  B. In-path rules
  C. Group IDs
  D. Port labels
  A. Redundant Steelhead Mobile Controllers

• Question 369:

  When a SteelHead reaches `admission control', what happens to the network traffic it is processing?

  A. Existing optimized connections continue to be optimized but new connections are passed through.
  B. All existing connections continue to be optimized and new connections are also optimized.
  C. Existing optimized connections are passed through and new connections are optimized.
  D. All connections are reset to clear the alarm.
  E. All new connections are optimized except those which are MAPI pre-population.
  A. Existing optimized connections continue to be optimized but new connections are passed through.

• Question 370:

  WCCP uses bits to create and distribute buckets. Using MASK assignment, what is the maximum number of bits used?

  A. 4
  B. 7
  C. 8
  D. 32
  E. 256
  B. 7
