VMware VCPN610 Online Practice Questions and Exam Preparation

VMware VCPN610 Online Questions & Answers

• Question 71:

  Which component automates the consumption of third-party services and provides mapping to virtual machines using a logical policy?

  A. NSX Manager
  B. Cloud Management Platform (CMP)
  C. Service Composer
  D. NSX Data Security
  C. Service Composer

• Question 72:

  Your company has a policy regarding the use of distributed virtual port groups for application deployments that requires all port configurations to maintain a finite maximum. What two configuration options will assure that only a finite, specific number of ports can be configured on a distributed virtual port group? (Choose two.)

  A. Configure the Port binding option value for Ephemeral.
  B. Configure the Port allocation option value for Elastic.
  C. Configure the Port binding option value for Static Binding.
  D. Configure the Port allocation option value for Fixed.
  C. Configure the Port binding option value for Static Binding.
  D. Configure the Port allocation option value for Fixed.

• Question 73:

  Which statement describes proper packet processing of layer 3 traffic in an NSX for vSphere topology?

  A. All packets are processed by the distributed router. No packets are processed by the Logical Router Control VM.
  B. Only packets requiring routing to another VM on the same host are processed by the distributed router. Other packets are processed by the Logical Router Control VM.
  C. Only packets requiring routing to another VM on a different host are processed by the distributed router. Other packets are processed by the Logical Router Control VM.
  D. All packets requiring routing are processed by performing a lookup in the Logical Router Control VM and then forwarded.
  A. All packets are processed by the distributed router. No packets are processed by the Logical Router Control VM.

• Question 74:

  What is the packet size of the VXLAN standard test packet when using the Ping test on the logical switches?

  A. 1500
  B. 1550
  C. 1575
  D. 1600
  B. 1550

• Question 75:

  If a Security Group is the Source for a General Logical Firewall Rule, which Virtual Machines will be affected by the rule?

  A. Each Virtual Machine defined in the Security Group.
  B. Each Virtual Machine defined in the Source and Destination fields of the Logical Firewall Rule.
  C. Each Virtual Machine identified in the Applied To field of the Logical Firewall Rule.
  D. Each Virtual Machine identified in the Destination field of the Logical Firewall Rule.
  C. Each Virtual Machine identified in the Applied To field of the Logical Firewall Rule.

• Question 76:

  You have deployed a vShield Endpoint for antivirus and malware detection on an NSX network and need to monitor audit messages for the endpoint. Which log file are the audit messages recorded in?

  A. vmkwarning.log on the ESXi host
  B. vmware.log on the virtual machine
  C. cloudnet_cpp.log on the NSX Controller
  D. messages.log on the NSX Manager
  B. vmware.log on the virtual machine

• Question 77:

  A company has augmented its Data Center infrastructure by using vCloud Hybrid Service during peak hours. The company wants to extend their existing subnets into the cloud while workloads retain their existing IP addresses. The virtual machines in these subnets use an NSX Edge Gateway as their default gateway.

  Which solution should this company use?

  A. Layer 2 VPN
  B. MPLS VPN
  C. IPSec VPN
  D. SSL VPN
  A. Layer 2 VPN

• Question 78:

  A vSphere administrator wants to setup an NSX Edge Service Gateway to provide traveling employees secure access to company servers located in specific network segments within the corporate Data Centers. The solution has to be as scalable as possible.

  Which Virtual Private Network solution will satisfy the administrator's requirements?

  A. SSL VPN
  B. MPLS VPN
  C. Layer 2 VPN
  D. IPSec VPN
  A. SSL VPN

• Question 79:

  -- Exhibit



  -- Exhibit -An administrator is troubleshooting a NSX controller cluster issue and runs the control-cluster command:

  What information can be determined from the output provided in the exhibit?

  A. This is the control cluster majority leader controller
  B. There are two controllers in the cluster
  C. This is not the control cluster majority leader controller
  D. The persistence_server role is not functioning correctly
  C. This is not the control cluster majority leader controller

• Question 80:

  Which two Virtual Private Networks are supported by the NSX Edge Service Gateway? (Choose two.)

  A. Layer 2 VPN
  B. GRE VPN
  C. IPSec VPN
  D. Layer 3 VPN
  A. Layer 2 VPN
  C. IPSec VPN
