UiPath UIPATH-ADAV1 Online Practice Questions and Exam Preparation

UiPath UIPATH-ADAV1 Online Questions & Answers

• Question 191:

  What actions must be manually selected in the App/Web Recorder before recording a step?

  A. Copy text using the Get Text activity. Hover over an element using the Hover activity. Highlight an element using the Highlight activity.
  B. Copy text using the Get Text activity. Hover over an element using the Hover activity. Click on buttons, links, and other clickable elements such as icons or images. Type text in a text area such as a text box. Select or clear a check box.
  C. Select or clear a check box. Send keyboard shortcuts using your keyboard. Select an item from a drop-down.
  D. Click on buttons, links, and other clickable elements such as icons or images. Type text in a text area such as a text box. Select or clear a check box. Send keyboard shortcuts using your keyboard. Select an item from a drop-down.
  A. Copy text using the Get Text activity. Hover over an element using the Hover activity. Highlight an element using the Highlight activity.

  ---

  Explanation

  The App/Web Recorder is a tool that allows you to record your actions on an application or a web browser and generate activities automatically1. The App/Web Recorder has a toolbar that contains different actions that you can select before

  recording a step2. Some of these actions are:

  Click: This action records a click on a button, link, or any other clickable element. Type: This action records typing text in a text box or any other text area. Check: This action records selecting or clearing a check box. Send Hotkey: This action

  records sending keyboard shortcuts using your keyboard.

  Select Item: This action records selecting an item from a drop-down list or any other selector.

  These actions are automatically detected and recorded by the App/Web Recorder when you perform them on the application or web browser3. However, there are some actions that are not automatically detected and recorded by the App/

  Web Recorder, and you need to manually select them from the toolbar before recording a step. These actions are:

  Get Text: This action records copying text from a label, paragraph, or any other text element.

  Hover: This action records hovering over an element with your mouse cursor. Highlight: This action records highlighting an element with a colored border. These actions are useful for extracting data, triggering events, or identifying elements

  on the application or web browser4. To use these actions, you need to select them from the toolbar and then indicate the element on the screen that you want to apply them to5. Therefore, option A is the correct answer, as it lists the actions

  that must be manually selected in the App/Web Recorder before recording a step. Option B includes some actions that are automatically detected and recorded by the App/Web Recorder, such as Click and Type. Option C also includes some

  actions that are automatically detected and recorded by the App/Web Recorder, such as Check and Send Hotkey. Option D includes all the actions that are automatically detected and recorded by the App/Web Recorder.

• Question 192:

  How many Global Exception Handlers can be established per automation project, according to best practices?

  A. A single one for the entire project.
  B. There is no limit.
  C. One for each workflow in the project.
  D. One for each activity in the project.
  A. A single one for the entire project.

  ---

  Explanation

  According to best practices in UiPath, there should be a single Global Exception Handler for the entire project, making option A correct. The Global Exception Handler is designed to manage unhandled exceptions in a centralized manner,

  allowing for a consistent approach to error handling across the entire project. Options B, C, and D suggest multiple handlers, which contradicts the principle of centralized exception management.

  References:

  UiPath Documentation: Global Exception Handler

• Question 193:

  What role do Triggers play in the UiPath Integration Service?

  A. Manage connections between UiPath Studio and third-party applications.
  B. Provide a mechanism for starting processes on a scheduled basis from Orchestrator.
  C. Assist in the creation of automation projects by providing event-based activities.
  D. Provide a mechanism for subscribing to specific events from third-party applications, automatically starting processes in Orchestrator.
  D. Provide a mechanism for subscribing to specific events from third-party applications, automatically starting processes in Orchestrator.

  ---

  Explanation

  Triggers are a feature of UiPath Integration Service that allow you to react to key events in third-party systems, such as data updates, insertions, deletions, or custom events. By configuring triggers, you can start your UiPath processes automatically from Orchestrator when these events occur, enabling near real-time automation workflows across different applications. (UiPath Integration Service documentation1)

  References:

  1: Integration Service - Triggers - UiPath Documentation Portal

• Question 194:

  A developer is using the REFramework template to automate a process. In "SetTransactionStatus" file, there is the following sequence of activities, where the last Log Message activity was added by the developer:

  The configuration for Add Log Fields and Remove Log Fields activities are shown below:

  Add transaction log fields (Success) The developer runs the process and notices the argument values for the first transaction are:



  in_TransactionlD = "07/18/2023 10:27:29"

  io_TransactionNumber = 1

  in_TransactionField1 = "UI235-80"

  in_TransactionField2 = "Update Request"

  Which of the following Log Message Details will be displayed when executing the activity Log Message Completed for the first transaction, considering it is successful?

  A. "message": "Transaction Completed", "level": "Information", "logType": "User", "timeStamp": "10:30:19", "fileName": "SetTransactionStatus", "processVersion": "1.0.0", "jobId": "59325301-680a-4d55-a81b-56ca1f369c12", "robotName": "test.robot", "machineId": 0, "logF_TransactionField2": "" "logF_TransactionStatus": "logF_TransactionID"; "", "logF_BusinessProcessName": "Framework", "logF_TransactionNumber": "" "logF_TransactionField1": }
  B. "message": "Transaction Completed", "level": "Information", "logType": "User", "timeStamp": "10:30:19", "fileName": "SetTransactionStatus", "processVersion": "1.0.0", "jobId": "cb865477-35f8-4c0a-93e9-e4f4246223f2", "robotName": "test.robot", "machineId": 0, "logF_TransactionField2": "Update Request", "logF_TransactionID": "07/18/2023 10:27:29", "logF_BusinessProcessName": "Framework", "logF_TransactionNumber": "1", "logF_TransactionField1": "UI235-80", "logF_TransactionStatus": "Success"
  C. "message": "Transaction Completed", "level": "Information", "logType": "User", "timeStamp": "10:30:19", "fileName": "SetTransactionStatus", "processVersion": "1.0.0", "jobId": "f8a36a46-8ebc-40df-8f71-26b39087ebee", "robotName": "test.robot", "machineId": 0, "logF_BusinessProcessName": "Framework" }
  D. "message": "Transaction Completed", "level": "Information", "logType": "User", "timeStamp": "10:30:19", "fileName": "SetTransactionStatus", "processVersion": "1.0.0", "jobId": "59325301-680a-4d55-a81b-56ca1f369c12", "robotName": "test.robot", "machineId": 0, "logF_TransactionField2": empty, "logF_TransactionStatus": empty, "logF_TransactionID": empty, "logF_BusinessProcessName": "Framework", "logF_TransactionNumber": empty, "logF_TransactionField1": empty }
  B. "message": "Transaction Completed", "level": "Information", "logType": "User", "timeStamp": "10:30:19", "fileName": "SetTransactionStatus", "processVersion": "1.0.0", "jobId": "cb865477-35f8-4c0a-93e9-e4f4246223f2", "robotName": "test.robot", "machineId": 0, "logF_TransactionField2": "Update Request", "logF_TransactionID": "07/18/2023 10:27:29", "logF_BusinessProcessName": "Framework", "logF_TransactionNumber": "1", "logF_TransactionField1": "UI235-80", "logF_TransactionStatus": "Success"

  ---

  Explanation

  The Log Message activity is used to write a diagnostic message at a specified level to the output panel, the log file, and Orchestrator1. The message can include custom log fields that are added by the Add Log Fields activity and removed by the Remove Log Fields activity2. In this case, the developer has added six log fields in the Add transaction log fields (Success) sequence and removed three of them in the Remove transaction log fields sequence. Therefore, the remaining three log fields (logF_TransactionField2, logF_TransactionID, and logF_TransactionStatus) will be displayed along with the default log fields (message, level, logType, timeStamp, fileName, processVersion, jobId, robotName, and machineId) when executing the Log Message Completed activity. The values of the log fields will be taken from the corresponding arguments of the Set Transaction Status activity.

  References: Add Log Fields activity documentation from UiPath Remove Log Fields activity documentation from UiPath Log Message activity documentation from UiPath

• Question 195:

  A developer executes the following workflow in Debug mode with "Continue on Exception " enabled.

  How many times will the workflow pause the execution?

  B. 1
  C. 2
  D. 3
  B. 1

  ---

  Explanation

  The workflow will pause the execution only once when it is executed in Debug mode with "Continue on Exception" enabled. Debug mode is a mode of execution that allows the developer to test and troubleshoot the workflow by using various debugging tools, such as breakpoints, step actions, and output messages4. "Continue on Exception" is a debugging option that enables the execution to continue even if an exception is encountered, without displaying the error message or stopping at the faulty activity5. In the workflow, there are two activities that can throw exceptions: the "Throw" activity, which throws a custom exception with the message "This is an exception", and the "Write Line" activity, which writes the value of the "Var" variable to the Output panel. The "Var" variable is not initialized, so it has a null value by default. When the "Write Line" activity tries to write the null value, it throws a NullReferenceException, as explained in the previous question. However, since the "Continue on Exception" option is enabled, the execution does not stop at the "Write Line" activity, but continues to the next activity, which is the "Throw" activity. The "Throw" activity throws the custom exception, which is caught by the "Catch" section of the "Try Catch" activity. The "Catch" section contains a "Log Message" activity, which writes the exception message to the Output panel. The execution then moves to the "Finally" section, which contains a "Write Line" activity with the text "This is the end". The workflow then ends successfully. The only time the execution pauses is when it reaches the breakpoint that is set at the "Throw" activity. A breakpoint is a debugging tool that allows the developer to pause the execution at a specific activity and inspect the values of the variables and arguments, as well as the output messages6. The developer can then resume the execution by using the step actions or the continue button7. Therefore, the workflow will pause the execution only once at the breakpoint, and not at the exceptions, as they are ignored by the "Continue on Exception" option.

  References: Debugging a Workflow, Debugging Actions, Breakpoints, and Continue on Exception from UiPath documentation.

• Question 196:

  What is the main difference between an array and a list in UiPath?

  A. An array is a fixed-size collection of elements of the same type while a list is a dynamic- sized collection of elements of the same type,
  B. An array is a dynamic-sized collection of elements of the same type while a list is a fixed-size collection of elements of the same type.
  C. An array is a fixed-size collection of elements of different types while a list is a dynamic- sized collection of elements of the same type.
  D. An array is a fixed-size collection of elements of the same type while a list is a dynamic- sized collection of elements of different types.
  A. An array is a fixed-size collection of elements of the same type while a list is a dynamic- sized collection of elements of the same type,

  ---

  Explanation

  The main difference between an array and a list in UiPath (and .NET in general) is that an array is a fixed-size collection of elements of the same type, whereas a list is a dynamic- sized collection, meaning it can grow or shrink in size as

  needed. Both arrays and lists hold elements of the same type, but lists offer more flexibility in terms of adding or removing elements after the collection has been created.

  References:

  UiPath Studio Guide: The Main Data Types in Studio

• Question 197:

  DRAG DROP

  How should the computation of the signature be done for client apps that receive Orchestrator requests and need to check their authenticity?

  Instructions: Drag the Description found on the left and drop on the correct Step Sequence found on the right.

  Select and Place:





  Explanation

  The correct sequence for the computation of the signature for client apps that receive Orchestrator requests and need to check their authenticity is:

  Retrieve the X-UiPath-Signature HTTP header. This header contains the signature of the request body, encoded in Base64. (UiPath Orchestrator documentation1) To obtain the raw signature bytes, decode the value of the header from Base64. You can use any tool or library that supports Base64 decoding. (UiPath Orchestrator documentation1)

  Compute the hash using SHA256 and the signing key (UTF-8 encoded). The signing key is a secret value that is shared between Orchestrator and the client app. You can use any tool or library that supports SHA256 hashing. (UiPath Orchestrator documentation1)

  Compare the computed signature to the value from X-UiPath-Signature HTTP header. If they match, then the request is authentic and has not been tampered with. If they do not match, then the request is invalid and should be rejected.

  (UiPath Orchestrator documentation1)

• Question 198:

  A developer designed an automation to use an Asset value from Orchestrator using the Get Asset activity. The value represents email addresses of the process owners which may change.

  Which Asset Type should be used?

  A. Bool
  B. Credential
  C. Text
  D. Integer
  C. Text

  ---

  Explanation

  The Asset Type that should be used for storing email addresses of the process owners is Text. Text assets are used to store only string values, such as names, addresses, URLs, etc. Text assets can be easily retrieved and updated using the

  Get Asset and Set Asset activities in UiPath Studio. Text assets are suitable for storing email addresses, as they can contain alphanumeric characters, symbols, and special characters. Text assets can also be used in various activities that

  require string input or output, such as Send Email, Write Line, Assign, etc.

  References: About Assets and Assets in UiPath Orchestrator and their usage in project from UiPath documentation and RPA Learners.

• Question 199:

  DRAG DROP

  What are the steps to publish a project from UiPath Studio?

  Instructions: Drag the Description found on the "Left" and drop on the correct Step Sequence found on the "Right".

  Select and Place:





  Explanation

  The steps to publish a project from UiPath Studio are:

  In the Design ribbon tab, click on the "Publish" button. The Publish Project window opens. (UiPath Studio documentation1)

  Fill in the necessary publishing details, such as the project name, version, and description. You can also add release notes and select the environment where the project will run. (UiPath Studio documentation1) Choose the desired publishing option, such as Orchestrator, Local, or Custom NuGet feed. Depending on your choice, you may need to provide additional information, such as the Orchestrator URL, the local folder path, or the custom feed URL. (UiPath Studio documentation1)

  Click on the "Publish" button to initiate the publishing process. A confirmation message will appear when the project is successfully published. (UiPath Studio documentation1) Short Publishing a project from UiPath Studio means creating a package that contains all the files and dependencies required to run the automation process. The package can be deployed to different locations, such as Orchestrator, a local machine, or a custom NuGet feed. Publishing a project from UiPath Studio involves four main steps:

  clicking on the Publish button, filling in the publishing details, choosing the publishing option, and confirming the publishing process. (UiPath Automation Developer study guide2)

  References:

  1: Publishing Projects from Studio - UiPath Studio.

  2: UiPath Certified Automation Developer - Learning Plan.

• Question 200:

  A developer needs to prioritize automating several processes. To help prevent any long- term maintenance, which process attribute should be avoided?

  A. Logical decision points
  B. Repetitive business process
  C. Frequent application changes
  D. High volume work
  C. Frequent application changes

  ---

  Explanation

  Frequent application changes are a process attribute that should be avoided when prioritizing automating several processes. This is because frequent application changes can cause the automation to break or malfunction, and require constant maintenance and updates. Processes that are stable and consistent are more suitable for automation, as they reduce the risk of errors and rework.

  References: Process Selection Criteria and Process Analysis from UiPath documentation.
