NI NI-CLAD Online Practice Questions and Exam Preparation

NI NI-CLAD Online Questions & Answers

• Question 101:

  Which of the following is NOT a component of an Error Cluster?

  A. Status.
  B. Code.
  C. Source.
  D. VI name
  D. VI name

• Question 102:

  Which of the following allows you to plot any set of points, evenly distributed or not?

  A. Waveform Graph
  B. Waveform Chart
  C. XY Graph
  D. Both A. and C.
  C. XY Graph

• Question 103:

  Clusters provide a user with which of the following benefits?

  A. Clusters allow a logical grouping of related data elements.
  B. Clusters increase the number of Connector Pane terminals of SubVI's.
  C. Clusters help to reduce wire clutter on the Block Diagram.
  D. Both A. and C.
  D. Both A. and C.

• Question 104:

  What is the value in after substring upon completion of the following code?



  A. world!
  B. rld!
  C. h hello world!
  B. rld!

• Question 105:

  What data type is best for storing a collection of mixed data types?

  A. Array
  B. Cluster
  C. String
  D. Enum
  B. Cluster

• Question 106:

  All eight inputs on cDAQ1Mod2 are reading data from thermocouples.

  What settings for Physical Channel and data index would allow data indicator to display the data from the fourth thermocouple?



  A. Option A
  B. Option B
  C. Option C
  D. Option D
  B. Option B

• Question 107:

  What is the result of the following Array subtraction?



  A. A 1-D Array of {-25, 25, 50}
  B. A 1-D Array of {-25, 25}
  C. A 2-D Array of {{-25, -50, -50}, {50, 25, 25}}
  D. A 1-D Array of {75, -50, 25}
  B. A 1-D Array of {-25, 25}

• Question 108:

  In what instance would you use the Probe tool rather than Highlight Execution?

  A. To see the flow of data
  B. To see the value of a wire in real-time
  C. To look into a SubVI, as the process is running
  D. To slowdown the VI and show data values in wires
  B. To see the value of a wire in real-time

• Question 109:

  After this VI has run 3 times, what value is displayed in the indicators Loop Iterations and Time?



  A. Loop Iterations = 3, Time = Seconds between the 2nd and 3rd time the VI ran.
  B. Loop Iterations = 0, Time = Seconds between the 1st and 3rd time the VI ran.
  C. Loop Iterations = 3, Time = Seconds between the 1st and 3rd time the VI ran.
  D. Loop Iterations = 0, Time = Seconds between the 2nd and 3rd time the VI ran.
  A. Loop Iterations = 3, Time = Seconds between the 2nd and 3rd time the VI ran.

• Question 110:

  Variants are used for all of the following but:

  A. Passing values between programs written with different compilers
  B. Allowing software to achieve a greater degree of generality
  C. Representing any data type
  D. Converting from fixed point to floating point data
  D. Converting from fixed point to floating point data
