HP HPE6-A80 Online Practice Questions and Exam Preparation

HP HPE6-A80 Online Questions & Answers

• Question 31:

  Refer to the exhibit.



  A customer needs a wired network upgrade and has complained about performanceissues. The architect collectedinformation about traffic now on several switch ports in different locations across the network, and the results are shown inthe exhibit. Each of these ports is a 1Gbps port.

  What can the architectconclude?

  A. All of the ports show serious congestion
  B. Port 1 shows periods of congestion; other ports are not congested.
  C. Port 3 snows periods ofcongestion; other ports are not congested.
  D. None of these ports show any periods of congestion
  D. None of these ports show any periods of congestion

• Question 32:

  A customer has critical wired endpoints. However, each endpointhas a single Ethernet connection to the network. Thecustomer wants redundancy in the switch access layer to minimize the chances that an endpoint will lose this connection.

  The architect plans to deploy two Aruba CX 6405 switches in the closet.

  Which plan provides the greatest redundancy for this scenario?

  A. The 6405 Switches are in a VSF fabric, so the individual switches do not need redundant components.
  B. The 6405 switches are in a VSX fabric, and each has a redundant management module but not a redundant power supply.
  C. The 6405 switches are not in a vsF fabric, and have redundant power supplies but not redundant management modules.
  D. The 6405 switches are not in a VSX fabric, and have redundant power supplies and redundant management modules.
  B. The 6405 switches are in a VSX fabric, and each has a redundant management module but not a redundant power supply.

• Question 33:

  A mall requires a wireless network upgrade to 802 -Max The company that owns the mall wants to provide the APs for the entire mall. However, several of the larger national chain retailers with spaces in the mall want to offer wireless services with their own SSIDs. These individual retailers also have their own wireless guest services and wireless client devices They have their own corporate infrastructure and want to handle all of this wireless traffic on their own, including terminating the traffic on their own controllers. The mall requires redundancy for its services, out the retailers do not.

  Which plan for mobility controllers (MCs) and mobility master (MW) meets the needs of this scenario?

  A. a pair of MMs for the mall company, but not MCs: MMs control one MC for each retailer with its own SSIDs
  B. two MCs for the mall company and for all of the retailers, both controlled by the same pair of MMs
  C. two MCs for the mail company controlled by a pair of MMS; one standalone MC for each retailer with its own SSIDS
  D. two MCs for the mall company and one MC for each retailer with its own SSIDs, all controlled by the same pair of MMs
  A. a pair of MMs for the mall company, but not MCs: MMs control one MC for each retailer with its own SSIDs

• Question 34:

  Referto the exhibit.



  A hospital needs an upgrade to 802.1tax for its wireless network. The wireless network supports:

  *

  wireless medical devices

  *

  medical staff voice communicators

  *

  laptops in nurse stations

  *

  medical staff tablets

  *

  visitor and patient personal devices.

  All of these devices support both the 2 4GHz and 5GH2 band. Assuming about a max throughput on50 Mbps per AP; the hospital would like. The architect has used VisualRF to plan the AP placement on one of the floors, which the hospital

  expects will need to suppod about 800 win

  to deploy APS in stairwells between floors.

  How well does the plan meet the requirements?

  A. The current AP placement meets coverage requirements, but does not meet capacity requirements.
  B. The current AP placement meets the customer requirements in terms of coverage and capacity.
  C. The current AP placement fails to account for the lead-lined wails that are common in patient and exam rooms.
  D. The current AP placement fails to provide adequate signal for the voice communicators in several areas
  C. The current AP placement fails to account for the lead-lined wails that are common in patient and exam rooms.

• Question 35:

  Refer to the exhibit.



  The exhibit shows the design for an existing network. The customer intends to replace the current Core switches with two Aruba 8400 switches. What are two points that the architect should ensure that the customer understands? (Select two.)

  A. The 8400 switches do not support VSF.
  B. The 8400 switches cannot be monitored by AirWave.
  C. The 8400 switches run different software than the 5400R switches.
  D. The 8400 switches have a smaller ARP table than the 540OR switches.
  E. The 8400 switches are fixed port switches.
  C. The 8400 switches run different software than the 5400R switches.
  D. The 8400 switches have a smaller ARP table than the 540OR switches.

• Question 36:

  Refer to the exhibit.



  This warehouse has the dimensions shown in the exhibit. The warehouse is 20 feet (6 m) high up to a steel railing on the celling. The shelves are about 16 feet (5m) high, and they hold large containers filled with fluid and metal equipment.

  The customer needs consistent wireless coverage throughout the warehouse, mostly to support the tablets that employees use to run Inventory tracking and other applications. The warehouse staff works in shifts of 20. The architect has selected AP-515S. About how many APs should the architect propose?

  A. about 13-16
  B. about 23-32
  C. about 6-8
  D. about 6-4
  C. about 6-8

• Question 37:

  A customer has an Aruba wireless network. which includes two MC 7205s and an MM at the network core. The company now wants to accommodate 50 mobile trainers These trainers travel around the world and run training events. The

  trainers often need to access materials in the company data center, but cannot reach materials when they are on the road.

  The company wants to give the mobile workforce a secure way to reach the materials they need no matter where they are.

  Including in public spaces like the hotels where they often leach. The customer also requires that the solution be as cost effective as possible while meeting the requirements.

  Which plan meets the needs of the mobile Trainers?

  A. Add 50 RAPs: add 50 Enterprise licenses to the MM, and add two 7005 MCs in the DMZ.
  B. Add 50 RAPs; add 50 Enterprise licenses and 50 VIA licenses to the MM
  C. Add so PEFV licenses to the MM. and add an additional 7205 MC to the core.
  D. Add 50 VIA licenses to the MM, and deploy two 7005 MCs in the DMZ.
  B. Add 50 RAPs; add 50 Enterprise licenses and 50 VIA licenses to the MM

• Question 38:

  For which scenario do Aruba CX 6300M Series switches meet the needs for an upgrade of the wired access layer while the Aruba CX 630QF Series switches do not?

  A. The customer wants to utilize the Aruba AP-515 support for 002 3bz connectivity.
  B. The customer wants to utilize LACP on AP515 in VSF switch configuration.
  C. The Aruba CX6300M supports 10GBase-T connectivity with AP-515.
  D. The Aruba CX 630DM support up to 75W PoE+ per port
  D. The Aruba CX 630DM support up to 75W PoE+ per port

• Question 39:

  Refer to the exhibit.



  A company needs a new wireless solution for its multi-site network. All branch sites must connect to the main site through

  secure tunnels over the Internet. The customer requires full redundancy for the Mobility Controllers (MC). Including

  stateful faiEoverand seamless roaming for the main site.

  The architect plans to propose:

  -500 RAPS

  -100 APs at the main campus

  -

  two 7205 MCs

  -

  two 7210 MCS - one MM appliance The exhibit snows the existing wired network at the main site, which has a single building with two large floors.

  Following the best-practices on design, performance and security, where should the architect plan to connect the MCs? {Potential locations are numbered in the exhibit.)

  A. two 7205 MCs at 2; two 7210 MCs at 1
  B. one 7205 MC at 3 and one at 4; two 7210 MCs at 1
  C. all of the MCs at 2
  D. two 7205 MCS at 1; two 7210 MCS at 2
  C. all of the MCs at 2

• Question 40:

  Refer to the exhibit.



  The exhibit shows the topology for a new Aruba solution. The MCs are in a ctuster and support all of the wireless traffic in

  the network The core switches route all traffic and support all VLANS. The access fayer switches do NOT use tunneiednode. or dynamic segmentation.

  The customer has indicated that it has these VLANS for user devices.

  *

  VLAN 11 for Floori employee wired devices

  *

  VLAN 12 for Floor 2 employee wired devices

  *

  VLAN 13 tor Floor 3 employee wired devices

  *

  VLAN 14 for Floor 4 employee wired devices

  *

  VLAN 15 for Floor 5 employee wired devices

  *

  VLAN 101 for all employee wireless devices

  *

  VLAN 102 for all guest wireless devices

  In which locations should the architect plan the VLANs?

  A. VLANs 11-15 on one MC. VLANs 101 and 102 on the other MC. (Other VLANs will be used on the access layer switches.)
  B. VLANs 11-15. 101. and 102 on both MCs. (Other VLANs will be used on the access layer switches.)
  C. VLANs 11-15 on the access layer switches on the corresponding floor; VLAN 101 on one MC and VLAN 102 on me other MC
  D. VLANS 11-15 on the access layer switches on the corresponding floor; VLANS 101 and 102 on both MCS.
  C. VLANs 11-15 on the access layer switches on the corresponding floor; VLAN 101 on one MC and VLAN 102 on me other MC
