HP Aruba ACMA HPE6-A70 Questions & Answers

• Question 1:

  Refer to the exhibit.



  Which role must AP 1 play?

  A. Remote AP (RAP)

  B. Mesh Portal AP

  C. Instant AP (IAP)

  D. Mesh Point AP

  Correct Answer: B

• Question 2:

  Refer to the exhibit.



  The exhibit shows output from a Mobility Master (MM) dashboard. What is a valid reason for the administrator to click the akamai square under applications?

  A. to see the break down for only the roles, destinations, WLANs, and devices that use this application

  B. to download a report about the usage of this application over time

  C. to create filter rules in order to control wireless user access to this application

  D. to set up bandwidth rule in order to control wireless user access to this application

  Correct Answer: A

• Question 3:

  A customer has a large campus that requires 400 Aruba 335 APs to support a total of 20,000 wireless users and 12Gbps of traffic. Although the customer wants two controllers for redundancy, each controller must be able to support all of the APs and users on its own. Which Aruba Mobility Controller models meet the customer requirements and DO NOT unnecessarily exceed them?

  A. Aruba 7024 controllers

  B. Aruba 7210 controllers

  C. Aruba 7240 controllers

  D. Aruba 7030 controllers

  Correct Answer: B

• Question 4:

  Which IEEE standard provides the highest transmission rates in the 5.0GHz frequency band?

  A. 802.11a

  B. 802.11ac

  C. 802.11g

  D. 802.11n

  Correct Answer: D

• Question 5:

  A company has an Aruba solution with a guest WLAN named exam_guest. A network administrator creates the guest WLAN with the wizard and does not change any of the default roles. The authentication server does not send particular role assignments for authorized users. The company wants to deny guest access to specific IP rnages after the guests authenticate. For which role should the administrator create the rule to deny this traffic?

  A. exam_guest-guest-logon

  B. authorized

  C. guest-logon

  D. guest

  Correct Answer: D

• Question 6:

  A company currently uses 802.11ac Wave 1 as a wireless solution. They want to upgrade to 802.11ac

  Wave2.

  Which new feature will now be available with this upgrade?

  A. band steering

  B. multiple spatial streams

  C. 40MHz channel bonding

  D. multi-user MIMO (MU-MIMO)

  Correct Answer: D

• Question 7:

  A company has many 7220 controllers in its Aruba wireless architecture. A network administrator wants to

  use the Traffic Analysis dashboard in order to monitor which type of applications is being used by wireless

  users.

  What is required for this implementation?

  A. Airmatch and ClientMatch must be enabled.

  B. The solution must have active PEFNG licenses.

  C. Firewall policies must include application filtering rules.

  D. WLANs must use the decrypt-tunnel forwarding option.

  Correct Answer: B

• Question 8:

  A company has a Mobility Master (MM)-based solution. A network administrator wants to monitor data transfer speed ranges of all currently connected clients. Which dashboard page in the MM interface should the administrator visit?

  A. Security

  B. Performance

  C. Traffic Analysis

  D. Network

  Correct Answer: C

• Question 9:

  An Aruba solution has a WLAN that uses WPA2-Personal security. How are encryption keys dynamically managed for the wireless users?

  A. The MM generates and distributes keys to clients and access points (APs).

  B. Administrators configure identical key strings on the Mobility Controllers (MCs) and wireless client 802.1X settings.

  C. Keys are generated and distributed securely during each wireless user authentication process.

  D. Keys are derived from the preshared key configured on the WLAN and on each wireless client.

  Correct Answer: D

• Question 10:

  For which use case should network administrators set up Aruba access points (APs) as multi-zone APs?

  A. The company has multiple small branch offices where APs at each branch office must forward internet traffic locally and corporate traffic over a secure tunnel to a centralized Mobility Controller (MC).

  B. The company has some devices that support both 5GHz and 2.4GHz, and the APs must operate in both frequency bands.

  C. The company requires high availability for its wireless services, and APs must be able to be controlled by more than one Mobility Controller (MC) in case a controller fails.

  D. The company has a Mobility Manager (MM)-based solution that requires APs to terminate to multiple controllers that reside in different administrative domains.

  Correct Answer: D
