HP HPE6-A29 Online Practice Questions and Exam Preparation

HP HPE6-A29 Online Questions & Answers

• Question 21:

  An administrator encounters a situation in which an email address is the only requirement of authentication for a user and the Aruba controller is configured for captive portal. What can the administrator conclude?

  A. The EAP method option is configured
  B. The enable termination option is configured
  C. The enable user logon option is configured
  D. The enable guest logon option is configured
  D. The enable guest logon option is configured

• Question 22:

  An Aruba based network has a Master and three local controllers. No APs terminate on the Master controller. IDS is desired, so the administrator wants to install the "RFProtect license." On which controller should the license be installed?

  A. master controller since it performs the IDS analysis
  B. the local controllers since the APs terminate there
  C. all of the controllers
  D. this isn't the correct license for this purpose
  C. all of the controllers

• Question 23:

  A client attaches to a secure jack interface set to untrusted. But when the client tries to access the captive portal page, the following message appears, "Web Authentication is not enabled." What might be wrong?

  A. The client has the browser provisioned with proxy settings.
  B. The controller port needs to be set to trusted.
  C. A "aaa" profile needs to be selected on the Wired Access page.
  D. A Captive Portal profile needs to be assigned to the initial role.
  E. Web Authentication cannot be used in this way.
  D. A Captive Portal profile needs to be assigned to the initial role.

• Question 24:

  When an Aruba 6000 controller has two M3 modules installed, for which uses may the modules be used?

  A. hot standby operations
  B. VRRP backup
  C. higher AP density per switch chassis
  D. Active-Active masters
  B. VRRP backup
  C. higher AP density per switch chassis

• Question 25:

  A Remote AP was properly functioning before losing its internet connection and now cannot communicate with the controller. What SSID is the AP broadcasting?

  A. The SSID in Operational mode Always and Forwarding mode Backup
  B. The SSID in Operational mode Split Tunnel and Forwarding mode Bridge
  C. The SSID in Operational mode Always and Forwarding mode Tunnel
  D. The SSID in Operational mode Standard and Forwarding mode Tunnel
  E. The SSID in Operational mode Persistent and Forwarding mode Bridge
  E. The SSID in Operational mode Persistent and Forwarding mode Bridge

• Question 26:

  With Fast-Failover disabled, to which IP address should the Aruba AP terminate its GRE tunnel for layer 2 controller redundancy to work and to support failover of access points?

  A. VRRP IP address
  B. management IP of an Aruba controller
  C. management IP of the backup Aruba controller
  D. HSRP IP address
  E. Loopback IP address of backup Aruba controller
  A. VRRP IP address

• Question 27:

  Masters communicate configuration information with locals using which tunnel type?

  A. GRE
  B. IP in IP
  C. Provision Tunnel Protocol
  D. IPSec
  E. PPTP
  D. IPSec

• Question 28:

  An administrator supports a large campus WLAN infrastructure. A section of the warehouse building on the campus is no longer used. The administrator moves the Aruba Aps from the unused building section to a new location in the network. However, when the administrator connects the Aps to their new network location some of the Aps cannot find a local controller to establish a connection.

  What should the administrator do on these Aps to solve this problem?

  A. When booting access the Aps boot mode and define the correct AP group name.
  B. After booting access the Aps CLI and erase its configuration with the erase startup- configuration command.
  C. When booting access the Aps boot mode and execute the purgeenv command.
  D. After booting access the Aps CLI and define the master controller's IP address with the ipconfig command.
  A. When booting access the Aps boot mode and define the correct AP group name.

• Question 29:

  An Aruba controller is configured with the correct IP address and gateway information, and is connected to the corporate LAN through a core Layer 3 switch. Control Plane Security (CPSec) is not enabled on the network. An access point is provisioned with the AP name and group, and connected to a different Layer 2 switch on the corporate LAN that has IP connectivity to the core layer 3 switch. The AP powers on and Layer 2 connects to the network, but the wireless radios do not power on.

  What could cause this condition? (Select two)

  A. The AP's MAC address needs to be configured in the Aruba controller whitelist.
  B. The AP and controller are in different subnets.
  C. The Layer 2 switches have ACLs that block IPSec traffic.
  D. The Layer 2 switches are configured to block IPSec traffic.
  E. A DHCP server is not configured for the segment to which the AP is connected.
  C. The Layer 2 switches have ACLs that block IPSec traffic.
  E. A DHCP server is not configured for the segment to which the AP is connected.

• Question 30:

  A customer has a remote AP deployment, where each remote AP has an IPSEC VPN tunnel with L2TP to the controller. 1 of the remote APs is stuck in the user table and hasn't yet transitioned to the AP active table in the controller. The customer suspects that the AP is not setting up its VPN connection successfully. Which of the following commands might be useful in troubleshooting this? (Choose three.)

  A. Logging level debugging security process localdb
  B. Logging level debugging security process l2tp
  C. Logging level debugging security process dot1x
  D. Logging level debugging security process crypto
  E. Logging level debugging security process vpn
  A. Logging level debugging security process localdb
  B. Logging level debugging security process l2tp
  D. Logging level debugging security process crypto
