Nokia 4A0-108 Online Practice Questions and Exam Preparation

Nokia 4A0-108 Online Questions & Answers

• Question 151:

  Which of the following PIM messages are sent towards the RP? (Choose two)

  A. (*, G) Join/Prune
  B. (S, G) Join/Prune
  C. Register Stop
  D. (S, G, rpt) Join/Prune
  A. (*, G) Join/Prune
  D. (S, G, rpt) Join/Prune

• Question 152:

  Four routers share a multi-access network. Router A is configured with a PIM DR priority of 10, Router B is configured with a PIM DR priority of 100, Router C and Router D are at the default value. Router D has the highest IP address. Which Router will be elected the PIM DR?

  A. Router A
  B. Router B
  C. Router C
  D. Router D
  B. Router B

• Question 153:

  Refer to the exhibit.



  The switch is not igmp-snooping/proxy capable. What will happen if host 2 issues an IGMP report to join a group?

  A. Both Router A and Router B will get this IGMP report and Router B will propagate a PIM join towards the core network
  B. Both Router A and Router B will get this IGMP report and both of them will propagate a PIM join towards the core network
  C. Only Router A will get this IGMP report and Router A will propagate a PIM join towards the core network
  D. Only Router A will get this IGMP report and as Router A is not PIM DR, so no further action
  A. Both Router A and Router B will get this IGMP report and Router B will propagate a PIM join towards the core network

• Question 154:

  Which of the following about the default MDT in Draft Rosen is TRUE?

  A. It is also known as the I-PMSI. Each MVPN has only one I-PMSI.
  B. It is also known as the S-PMSI. Each MVPN has only one S-PMSI.
  C. It is also known as the I-PMSI. Each MVPN may have multiple I-PMSIs.
  D. It is also known as the S-PMSI. Each MVPN may have multiple S-PMSIs.
  A. It is also known as the I-PMSI. Each MVPN has only one I-PMSI.

• Question 155:

  Refer to the following exhibit.



  Choose the best answer that describes the multicast LAN.

  A. There are no active sources in the network
  B. There is one active source for 239.1.1.1 and two active sources for 239.2.2.2
  C. The devices on sap 1/1/4 and sdp 1000:500 have issued joins for 239.1.1.1
  D. There is a router on sdp 1000:500
  D. There is a router on sdp 1000:500

• Question 156:

  Which of the following conditions triggers the S-PMSI construction in Draft Rosen?

  A. If multicast data exceeds the threshold set on the ingress PE, the S-PMSI is constructed.
  B. If multicast data exceeds the threshold set on the egress PE, the S-PMSI is constructed.
  C. If the number of interested receivers exceeds the threshold set on the egress PE, the S-PMSI is constructed.
  D. If the number of interested receivers exceeds the threshold set on the ingress PE, the S-PMSI is constructed.
  A. If multicast data exceeds the threshold set on the ingress PE, the S-PMSI is constructed.

• Question 157:

  Which of the following about the signaling of multicast group information in an MVPN service is TRUE when MPLS P2MP tunnels are used?

  A. BGP Auto-Discovery is used for the signaling of the PMSIs, while either mLDP or RSVP-TE P2MP is used for the signaling of customer multicast group membership.
  B. Either BGP Auto-Discovery or PIM is used for the signaling of the PMSIs, while either mLDP or RSVP-TE P2MP is used for the signaling of customer multicast group membership.
  C. BGP Auto-Discovery is used for the signaling of the PMSIs, as well as for the signaling of customer multicast group membership.
  D. BGP Auto-Discovery is used for the signaling of the PMSIs, while either BGP Auto-Discovery or PIM is used for the signaling of customer multicast group membership.
  C. BGP Auto-Discovery is used for the signaling of the PMSIs, as well as for the signaling of customer multicast group membership.

• Question 158:

  What does the term `incongruent unicast and multicast routing' refer to? (Choose the best answer)

  A. This is another term for asymmetric routing
  B. This refers to having different routing policies or routing topologies for unicast and multicast networks
  C. This refers to the case when the base routing table imports routes from two different protocols
  D. This refers to the case when unicast and multicast routing tables contain the same route entries
  B. This refers to having different routing policies or routing topologies for unicast and multicast networks

• Question 159:

  Which of the following regarding the BSR and the RP is TRUE?

  A. A router cannot be configured as a BSR-candidate and a static RP at the same time.
  B. A router cannot be a candidate-RP and a BSR-candidate at the same time.
  C. There is only one active RP in a multicast routing domain at any time.
  D. There is only one elected BSR in a multicast routing domain at any time.
  D. There is only one elected BSR in a multicast routing domain at any time.

• Question 160:

  Which of the following statements best describes the behavior seen in the network when a receiver joins a multicast channel in the PIM ASM network shown in the exhibit?



  A. Both Router B and Router C will propagate a PIM (*, G) Join to the RP when a receiver joins
  B. Only Router B will propagate a PIM (*.G) Join to the RP when a receiver joins
  C. Only Router C will propagate a PIM(\G) Join to the RP when a receiver joins
  D. Depends on the next hop for RP in Router D's RPF table
  D. Depends on the next hop for RP in Router D's RPF table
