Cisco 350-029 Online Practice Questions and Exam Preparation

Cisco 350-029 Online Questions & Answers

• Question 401:

  Which two of the following are designated fields for MAC tunneling protocol (802.1ah)?

  A. Control Word
  B. Tunnel Label
  C. 802.1q VLAN TAG
  D. ISL
  E. Service Ethertype
  F. PseudoLAN TAG
  E. Service Ethertype
  F. PseudoLAN TAG

• Question 402:

  The origin is a mandatory attribute that defines the origin of the path information.

  Which three options are valid origin attributes? (Choose three.)

  A. IBGP: NLRI is learned via intra-AS BGP.
  B. EBGP: NLRI is learned via inter-AS BGP.
  C. IGP: NLRI is interior to the AS of origination.
  D. EGP: NLRI is learned via EGP.
  E. INCOMPLETE. NLRI is unknown or learned some other way.
  C. IGP: NLRI is interior to the AS of origination.
  D. EGP: NLRI is learned via EGP.
  E. INCOMPLETE. NLRI is unknown or learned some other way.

• Question 403:

  Which two statements about MPLS Label Distribution Protocol (LDP) are true? (Choose two)

  A. LDP hello packets are sent to TCP 646.
  B. LDP session packets are sent to TCP 646.
  C. LDP session packets are sent to TCP 711.
  D. LDP hello packets are sent to TCP 711.
  E. LDP hello packets are sent to UDP 711.
  F. LDP hello packets are sent to UDP 646.
  B. LDP session packets are sent to TCP 646.
  F. LDP hello packets are sent to UDP 646.

• Question 404:

  Drag and drop the appropriate default next-hop behavior on the left to the corresponding BGP routing prefix update on the right.

  Select and Place:





• Question 405:

  Refer to the exhibit.



  The service provider is an MPLS and IPv4 enabled network. Which two approaches can enable IPv6 tunneling between site A and site B over the backbone? (Choose two.)

  A. IPv6 customer premise (6CP) over MPLS
  B. IPv6 VPN provider edge (6VPE) over MPLS
  C. IPv6 virtual forwarding (6VF) over MPLS
  D. IPv6 forwarding instance (6FI) over MPLS
  E. IPv6 provider edge router (6PE) over MPLS
  B. IPv6 VPN provider edge (6VPE) over MPLS
  E. IPv6 provider edge router (6PE) over MPLS

• Question 406:

  Which two IOS commands are equivalents for putting a Cisco 7500 OC-12 RPR interface card into wrapped mode? Select all that apply

  A. shutdown [a | b]
  B. srp shutdown [a | b]
  C. srp ips request manual-switched [a | b]
  B. srp shutdown [a | b]
  C. srp ips request manual-switched [a | b]

• Question 407:

  Which statements about the Route Target Rewrite feature are not true? (Choose two.)

  A. After the route target replacement policy is applied to the target router, the BGP session need not be refreshed manually to put the policy into operation.
  B. Route Target Rewrite allows the administration of the routing policy to stay local to the AS.
  C. Route target replacement is always done by the ASBR.
  D. Route target rewrites are supported for VRF export maps.
  E. Route target replacement can be done on incoming and outgoing BGP updates.
  A. After the route target replacement policy is applied to the target router, the BGP session need not be refreshed manually to put the policy into operation.
  C. Route target replacement is always done by the ASBR.

  ---

  The MPLS VPN--Route Target Rewrite feature allows the replacement of route targets on incoming and outgoing Border Gateway Protocol (BGP) updates. Typically, Autonomous System Border Routers (ASBRs) perform the replacement of route targets at autonomous system boundaries. Route Reflectors (RRs) and provider edge (PE) routers can also perform route target replacement.

  The main advantage of the MPLS VPN - Route Target Rewrite feature is that it keeps the administration of routing policy local to the autonomous system.

• Question 408:

  GMPLS is based upon Non-Packet-based devices

  A. True
  B. False
  A. True

• Question 409:

  When will the primary processor core dump run in case of a switchover?

  A. never takes place
  B. periodically
  C. during switchover
  D. after switchover
  E. before switchover
  D. after switchover

  ---

  In networking devices with redundant processors, the Post-Switchover Core Dump feature uses better software communication techniques between redundant processors to allow the switchover to occur before dumping core information. Not having to wait for dump operations effectively decreases the switchover time between processors. The newly active primary processor runs the core dump operation after switchover ReferencE. http://www.cisco.com/en/US/docs/ios/12_0st/12_0st18/feature/guide/coredump.html

• Question 410:

  Drag the command on the left to the correct step on the right to perform Frame Relay interworking with Ethernet over MPLS on a Cisco IOS router.

  Select and Place:
