Cisco 350-001 Online Practice Questions and Exam Preparation

Cisco 350-001 Online Questions & Answers

• Question 521:

  You use OSPF as your network routing protocol. You use the command show ip route and you see several routes described as 0, 0 IA, 0 E1, and 0 E2. What routes are in your area?

  A. OIA
  B. OE1
  C. O E2
  D

• Question 522:

  How many bytes make up the spanning-tree bridge ID?

  A. 4
  B. 8
  C. 12
  D. 16
  B. 8

• Question 523:

  Refer to the exhibit. R1 has two eBGP sessions to ISP1 and ISP2 (one to each ISP router), and R1 receives the same prefixes through both links.

  Which configuration should be applied for the link between R1 and ISP2 to be preferred for incoming traffic (ISP2 to R1)?



  A. increase local preference on R1 for sent routes
  B. decrease local preference on R1 for sent routes
  C. increase MED on ISP2 for sent routes
  D. decrease MED on ISP2 for sent routes
  D. decrease MED on ISP2 for sent routes

• Question 524:

  What are the "bound IP addresses" used for in LDP?

  A. For each such address and mask /32, one label binding is created.
  B. As the TCP endpoint, IP addresses are used by the LDP session.
  C. These addresses are used to find the label binding to put in the LFIB, by looking up these IP addresses in the routing table.
  D. These addresses are used for penultimate hop popping (PHP) when forwarding packets to the next router directly.
  C. These addresses are used to find the label binding to put in the LFIB, by looking up these IP addresses in the routing table.

• Question 525:

  Your company is researching a new application that runs over IPv6, but part of it must still have IPv4 support. Your company uses a traditional IPv4 network. Your plan is not to run IPv6 over the whole network, but to segment parts of the network or even to operate simultaneously with IPv6 and IPv4. You must make a brief presentation about IPv6 technology to the board of technical directors.

  Which three of these items could be part of your presentation? (Choose three.)

  A. Tunnel IPv6 over IPv4 to connect far-end IPv6 networks.
  B. Explain why configuring IPv4 and IPv6 at the same time over the same LAN interface is not possible.
  C. Explain why configuring IPv4 and IPv6 at the same time over the same LAN interface is possible.
  D. What is the meaning of EUI-64 and how does it work?
  E. Tunnel IPv4 over IPv6 to connect far-end IPv4 networks.
  A. Tunnel IPv6 over IPv4 to connect far-end IPv6 networks.
  C. Explain why configuring IPv4 and IPv6 at the same time over the same LAN interface is possible.
  D. What is the meaning of EUI-64 and how does it work?

• Question 526:

  Which command is used to enable EtherChannel hashing for Layer 3 IP and Layer 4 port-based CEF?

  A. mpls ip cef
  B. port-channel ip cef
  C. mpls ip port-channel cef
  D. port-channel load balance
  E. mpls ip load-balance
  F. ip cef EtherChannel channel-id XOR L4
  G. ip cef connection exchange
  D. port-channel load balance

• Question 527:

  On a router that is configured with multiple IP SLA probes, which command can be used to manage the CPU load that was created by the periodic probing?

  A. ip sla monitor low-memory
  B. ip sla group schedule
  C. ip sla reaction-trigger
  D. ip sla enable timestamp
  B. ip sla group schedule

• Question 528:

  Policy-based routing allows network administrators to implement routing policies to allow or deny paths based on all of these factors except which one?

  A. End system
  B. Protocol
  C. Application
  D. Throughput
  D. Throughput

• Question 529:

  Refer to the exhibit. An enterprise network has an upstream connection to two different ISPs that are using eBGP and a publicly assigned PI network. ISP1 is used as the primary provider, while ISP2 is used for backup. Due to packet loss on the link to ISP1, the network engineers changed the default route on R1 to point to ISP2, but they could not establish any connection until they changed the default route to point back at ISP1.

  Which two are possible root causes of the issue? (Choose two.)



  A. "ip verify unicast source reachable-via rx" is configured on the R1 uplinks.
  B. "ip verify unicast source reachable-via any" is configured on the R1 uplinks.
  C. "ip verify unicast source reachable-via rx" is configured on the ISP1 link to R1.
  D. "ip verify unicast source reachable-via any" is configured on the ISP1 link to R1.
  E. "ip verify unicast source reachable-via rx" is configured on the ISP2 link to R1.
  F. "ip verify unicast source reachable-via any" is configured on the ISP2 link to R1.
  A. "ip verify unicast source reachable-via rx" is configured on the R1 uplinks.
  E. "ip verify unicast source reachable-via rx" is configured on the ISP2 link to R1.

• Question 530:

  Which two OSPF LSA types are new in OSPF version 3? (Choose two.)

  A. Link
  B. NSSA external
  C. Network link
  D. Intra-area prefix
  E. AS domain
  A. Link
  D. Intra-area prefix
