F5 303 Online Practice Questions and Exam Preparation

F5 303 Online Questions & Answers

• Question 281:

  In an iApp, which configuration protects against accidental changes to an application Services configuration?

  A. Components
  B. Strict Updates
  C. Name
  D. Template
  B. Strict Updates

• Question 282:

  An LTM Specialist discovers an issue with the custom http monitor that returns in a false positive status.

  The end users cannot get the right website, but thehttp monitor marks the pool member UP.

  What is causing the false positive result?



  A. The end user should use another type of browser.
  B. The response is chunked.
  C. The response is compressed.
  D. The Content-Type has value "iso-8859-200".
  D. The Content-Type has value "iso-8859-200".

• Question 283:

  Refer to the exhibit.



  A pool is contoured with four members. A user has a currentconnection established with 10.18.1.40. The virtual server has a persistence Profile configured.

  A. 10.18.1.10
  B. 10.18.1.20
  C. 10.18.1.40
  D. 10.18.1.30
  C. 10.18.1.40

• Question 284:

  An LTMSpecialist must reconfigure a BIG-IP LTM system that load balances traffic to web application servers. The application developer inform the LTM Specialist that TLS must be used to communicate with the application servers. Which additional profile isrequired as part of virtual server configuration?

  A. SPDV profile
  B. Server SSL
  C. Client SSL
  D. Rewrite profile
  B. Server SSL

• Question 285:

  On the VCMP system, a BIG-IP host administrator imports a new ISO image into the host's /shared/images folder. The new ISO images that reside on the vCMP host are available for installation on the guest. How should the BIG-IP Administrator install one image from within the guest?

  A. Install the new software on the host and wait for it to automatically be installed on all guests.
  B. Run the following command on guest tmsh install sys software block-device-image image_name volume < volume_name>
  C. Run the following command on guest tmsh install sys software image image_name volume < volume_name>
  D. Run the following command on host tmsh install sys software block-device-image image_name volume < volume_name>
  D. Run the following command on host tmsh install sys software block-device-image image_name volume < volume_name>

• Question 286:

  A virtual server for a set of web services is constructed on an LTM device. The LTM Specialist has created an iRule and applied this iRule to the virtual server: when HTTP_REQUEST { switch [HTTP::uri] { "/ws1/ws.jsp" { log local0. "[HTTP::uri]-Redirected to JSP Pool" pool JSP } default { log local0. "[HTTP::uri]-Redirected to Non-JSP Pool" pool NonJSP } } } However, the iRule is NOT behaving as expected. Below is a snapshot of the log: /WS1/ws.jsp-Redirected to JSP Pool /WS1/ws.jsp-Redirected to JSP Pool /WS1/ws.jsp-Redirected to JSP Pool /WS1/WS.jsp-Redirected to Non-JSP Pool /ws1/WS.jsp-Redirected to Non-JSP Pool /WS1/ws.jsp-Redirected to JSP Pool /ws1/ws.jsp-Redirected to Non-JSP Pool What should the LTM Specialist do to resolve this?

  A. Use the followinG. switch -lc [HTTP::uri]
  B. Use the followinG. switch [string tolower [HTTP::uri]]
  C. Set the "Case Sensitivity" option of each member to "None".
  D. Select the "Process Case-Insensitivity" option for the virtual server.
  B. Use the followinG. switch [string tolower [HTTP::uri]]

• Question 287:

  There is a fault with an LTM device load balanced trading application that resides on directly connected VLAN vlan-301. The application virtual server is 10.0.0.1:80 with trading application backend servers on subnet 192.168.0.0/25. The LTM Specialist wants to save a packet capture with complete payload for external analysis.

  Which command should the LTM Specialist execute on the LTM device command line interface?

  A. tcpdump -vvv -w /var/tmp/trace.cap 'net 192.168.0.0/25'
  B. tcpdump -vvv -s 0 -w /var/tmp/trace.cap 'net 192.168.0.0/25'
  C. tcpdump -vvv -nni vlan-301 -w /var/tmp/trace.cap 'net 192.168.0.0/25'
  D. tcpdump -vvv -s 0 -nni vlan-301 -w /var/tmp/trace.cap 'net 192.168.0.0/25'
  D. tcpdump -vvv -s 0 -nni vlan-301 -w /var/tmp/trace.cap 'net 192.168.0.0/25'

• Question 288:

  An LTM device has been configured to log the reasons for generating TCP RST packets.

  The following log entry occurs:

  "01230140:3: RST sent from 192.168.1.100:80 to 192.168.1.124:39272, [0x112d82a:1721] {peer} TCP RST from remote system."

  Which condition will trigger this log entry?

  A. A virtual server connection limit has been reached.
  B. The host at the other end terminated the TCP connection.
  C. The LTM device reset the connection because no pool members are available.
  D. The LTM device has reached the maximum number of allowed attempts to send the data segment to the affected TCP connection.
  B. The host at the other end terminated the TCP connection.

• Question 289:

  An LTM Specialist defines a receive string in the HTTP monitor and then assigns it to the HTTP pool. The monitor has an interval of 5 seconds and a timeout of 16 seconds. If the receive string is NOT seen in the the HTTP payload after 20 seconds, how does the LTM device mark the monitor status?

  A. offline
  B. unknown
  C. available
  D. unavailable
  E. forced offline
  A. offline

• Question 290:

  Refer to the exhibit.



  A company uses a complex piece of client software that connects to one or more virtual servers (VS) hosted on an LTM device. The client software is experiencing issues. An LTM Specialist must determine the cause of the problem.

  The LTM Specialist is seeing a client source IP of 168.210.232.5 in the tcpdump. However, the client source IP is actually 10.123.17.12. Why does the IP address of 10.123.17.12 fail to appear in the tcpdump?

  A. The LTM device performed NAT on the individual's IP address.
  B. The Secure Network Address Translation (SNAT) pool on the virtual server is activated.
  C. Network Address Translation (NAT) has occurred in the path between the client and the LTM device.
  D. The individual's data stream is being routed to the LTM device by a means other than the default route.
  C. Network Address Translation (NAT) has occurred in the path between the client and the LTM device.
