Cisco 300-115 Online Practice Questions and Exam Preparation

Cisco 300-115 Online Questions & Answers

• Question 871:

  What are possible Etherchannel load balancing mechanism based on layer 3?

  A. Mac source
  B. Mac source-destination
  C. Ip Source
  D. IP Source-destination
  E. Mac destination
  C. Ip Source
  D. IP Source-destination

• Question 872:

  Which two limitations of LOCAL SPAN are true ?(Choose Two )

  A. The source and destination ports must reside in the same switch or switch stack
  B. It can monitor only traffic that ingresses or egresses on the source interface or VLAN.
  C. A SPAN session can support multiple destination ports only if they are on the same VLAN.
  D. EACH SPAN session supports only one source VLAN or interface.
  E. A switch can support only one local SPAN session at a time.
  A. The source and destination ports must reside in the same switch or switch stack
  B. It can monitor only traffic that ingresses or egresses on the source interface or VLAN.

• Question 873:

  Refer to the exhibit.



  A single server in Company 123 is connected via EtherChannel to a single upstream switch. Which EtherChannel load balancing method on the switch makes optimal use of the redundant links as traffic flows from the routers to the server?

  A. source MAC address
  B. source IP address
  C. source and destination MAC address
  D. destination MAC address
  A. source MAC address

• Question 874:

  Drag and Drop

  Drag and drop the statements about SPAN source and destination ports from the left onto the correct port types on the right

  Select and Place:





• Question 875:

  A question about local user database.

  A. Can be use as backup when other methods fail.
  B. Authorization of commands can be configured for local database user.
  C. http://certbus.com
  D. http://certbus.com
  A. Can be use as backup when other methods fail.

• Question 876:

  Which statement about HSRP, GLBP, and VRRP is true?

  A. VRRP group members communicate using multicast address 224.0.0.102.
  B. MAC address 0000.0c07.acOc indicates that default gateway redundancy is provided through GLBP.
  C. HSRP group members communicate using multicast address 224.0.0.18.
  D. GLBP uses UDP port 3222 (source and destination) for hello messages.
  D. GLBP uses UDP port 3222 (source and destination) for hello messages.

• Question 877:

  An engineer is configuring an EtherChannel between two switches using PAgP If the EtherChannel mode on switch 1 is configured to auto, which modes on switch 2 establish an operational EtherChannel?

  A. active
  B. auto
  C. desirable
  D. on
  E. passive
  C. desirable

• Question 878:

  Interfaces are assigned to a VLAN, and then the VLAN is deleted. Which state are these interfaces in after the VLAN is deleted?

  A. They remain up, but they are reassigned to the default VLAN
  B. They go down until they are reassigned to a VLAN.
  C. They go down, but they are reassigned to the default VLAN.
  D. They remain up, but they are reassigned to the native VLAN.
  B. They go down until they are reassigned to a VLAN.

• Question 879:

  Which two of the following organizationally specific LLDP TLVs are also advertised to support LLDP-MED? (Choose two.)

  A. Port VLAN ID TLV (IEEE 802.1 organizationally specific TLVs)
  B. MAC/PHY configuration/status TLV (IEEE 802.3 organizationally specific TLVs)
  C. IP Address TLV (IEEE 802.9 organizationally specific TLVs)
  D. DSCP TLV (IEEE 802.3 organizationally specific TLVs)
  E. Descriptive TLV (IEEE 802.5 organizationally specific TLVs)
  A. Port VLAN ID TLV (IEEE 802.1 organizationally specific TLVs)
  B. MAC/PHY configuration/status TLV (IEEE 802.3 organizationally specific TLVs)

  ---

  These organizationally specific LLDP TLVs are also advertised to support LLDP-MED. ?Port VLAN ID TLV ((IEEE 802.1 organizationally specific TLVs) ?MAC/PHY configuration/status TLV(IEEE 802.3 organizationally specific TLVs)

• Question 880:

  What SPAN configuration is required to enable on a switch?

  A. A monitor VLAN is created for the SPAN traffic.
  B. Configure a source and destination port
  C. Disable VTP pruning on trunk links
  B. Configure a source and destination port
